SLD-150-56

MEAN WELL AC/DC LED power supply unit CP 151,2W not dimmable

SLD-150-56
Manufacturer Part No.
SLD-150-56
Schukat Part No.
SLD-150-56
Manufacturer
MEAN WELL
Enter your company's part number here. Your part number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
Enter your personal project number here to assign the item to a project. Your part project number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.

0 Pcs. in stock

Next Stock Receipt
Week 18/2026
8 Pcs.
Planned delivery time
Ø 7 Weeks
Life Cycle Status
The life cycle indicates which market phase the item is in. We distinguish between: • Active (green) • NRND = Not Recommended for New Designs (yellow) • LTB = Last Time Buy (yellow) • EOL = End of Life (red)
Active
Available (from stock)
Replacement / Follow-up View entire series
Data Sheet
Open PDF
ECAD Model
Downloads

Prices

Manufacturer bundle 48 Pcs.
Manufacturer's packaging unit (Mfr. PU) means the smallest original packaging unit of the manufacturer.
Price per 1 Pcs.

Quantity and Options

(at least 1 or multiple of 1)
All prices net plus VAT. We do not deliver to private customers.

Fact Sheet

Operating mode
CP
Output Power
151.2 W
Output Current Min.
2.680 A
Output Current Max.
4.170 A
Output Voltage Min.
24 V
Output Voltage Max.
56 V
Interfaces
not dimmable
RoHS-Conform

Specifications

Open all

General

Manufacturer
  • MEAN WELL
Series
  • SLD-150
Product group
  • L4571
Application
  • Lighting
Operating mode
  • CP
Package/Case
  • Enclosed Plastic
Dimension: Length
  • 330 mm
Dimension: Width
  • 35 mm
Dimension: Height
  • 22 mm
Weight
  • 310 g
Label
  • MM-Zeichen; SELV; DEKRA
Dimmable
Interfaces
  • not dimmable
Manufacturer's warranty (years)
  • 5
Product description
  • SLD-150 series is a 150W AC/DC LED driver featuring with dual modes for constant voltage and constant current applications. SLD-150 operates from 120-305VAC and offers models with different rated voltage ranging between 12V and 56V. The 12V and 24V are suitable for constant voltage LED strip or household device and 56V is support for constant current application. Thanks to the high efficiency up to 93%, with the fanless design, the entire series is able to operate for -25C° - +85C° case temperature under free air convection. SLD-150 design with low profile and slim housing which is good for signage and decoration lighting applications.
Features
  • DC compatible
  • Independent Control Gear
Application note
  • Power supply for the operation of LED light sources. These products are not designed for operation in no-load condition. Waste electronic equipment is recyclable material and does not belong in household waste. If the device is at the end of its service life, dispose of it at the collection points of the disposal system in accordance with the applicable legal regulations. Disposal with household waste is prohibited.

Operating conditions

MTBF
  • 298,800 h
Operating expectation
  • 50,000 h
Operating Temperature Min.
  • -25 °C
Operating Temperature Max.
  • 85 °C
Storage Temperature Min.
  • -40 °C
Storage Temperature Max.
  • 80 °C

Input

Mains frequency min.
  • 47 Hz
Mains frequency max.
  • 63 Hz
Input voltage min. AC
  • 120 V
Input voltage max. AC
  • 305 V
Input voltage min. DC
  • 170 V
Input voltage max. DC
  • 431 V
Input current
  • 1 A
Efficiency
  • 93 %
Leakage current, max.
  • 0.35 mA
Inrush current, max.
  • 65 A
Max. number on B16 circuit breaker
  • 5
Max. number on C16 circuit breaker
  • 8
Power factor correction (PFC)
Power factor
  • 0.95
Connection type, input
  • Push-In Terminal

Output

Number of outputs
  • 1
Output Power
  • 151.2 W
Output Voltage Min.
  • 24 V
Output Voltage Max.
  • 56 V
Selectable output current
Output Current Min.
  • 2.680 A
Output Current Max.
  • 4.170 A
Output current tolerance
  • -5.5 %
Current ripple
  • 5 %
Overload protection
Type of overload protection
  • Constant Current Limitting
Short-circuit protection
Overvoltage protection
Overtemperature protection
Connection type, output
  • Push-In Terminal

Safety/Certifications

Protection class
  • II
Isolation voltage I/P-O/P
  • 3,860 V
Approvals
  • CCC
  • CE
  • EAC
  • EN
  • ENEC
  • UKCA
Standards (EMC)
  • EN 55015
Standards (safety)
  • EN 60335-1
  • EN 61347-1
  • EN 61347-2-13
