LOP-600-24

MEAN WELL AC/DC industrial power supply unit Open Frame 600W 24V 25A 2*MOPP

LOP-600-24LOP-600-24LOP-600-24LOP-600-24
Manufacturer Part No.
LOP-600-24
Schukat Part No.
LOP-600-24
Manufacturer
MEAN WELL
Enter your company's part number here. Your part number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
Enter your personal project number here to assign the item to a project. Your part project number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.

317 Pcs. in stock

Planned delivery time
Ø 14 Weeks
Life Cycle Status
The life cycle indicates which market phase the item is in. We distinguish between: • Active (green) • NRND = Not Recommended for New Designs (yellow) • LTB = Last Time Buy (yellow) • EOL = End of Life (red)
Active
Available (from stock)
Replacement / Follow-up View entire series
Data Sheet
Open PDF
ECAD Model
Downloads

Prices

Manufacturer bundle 36 Pcs.
Manufacturer's packaging unit (Mfr. PU) means the smallest original packaging unit of the manufacturer.
Price per 1 Pcs.

Quantity and Options

(at least 1 or multiple of 1)
All prices net plus VAT. We do not deliver to private customers.

Fact Sheet

Notice
Cross-references:
Here you will find suitable redundancy modules.
Here you will find suitable surge protection devices.
Here you will find suitable inrush current limiters.
Here you will find suitable EMC & noise suppression components.
Here you will find suitable equipment fans.
Package/Case
Open Frame
Output Power
600 W
Output voltage
24 V
Output current
25.000 A
Efficiency
94 %
Medical protection classification
2*MOPP
RoHS-Conform

Specifications

Close all

General

Manufacturer
  • MEAN WELL
Series
  • LOP-600
Product group
  • L6770
Application
  • Household
  • ITE
  • Industry
  • Medical
Package/Case
  • Open Frame
Dimension: Length
  • 127 mm
Dimension: Width
  • 76.2 mm
Dimension: Height
  • 33.5 mm
Weight
  • 480 g
Label
  • TÜV
Manufacturer's warranty (years)
  • 3
Product description
  • The LOP-600 is a highly reliable, energy efficient 600W open frame, low profile power supply. With a high power density of 30.3W/M³ in a standard 5" x 3" size, it offers a universal input voltage range of 80-264VAC, making it suitable for global applications. The series offers a comprehensive selection of standard voltages, including 12V/15V/18V/24V/27V/36V/48V/54V, and is available in a complete range of models. Key features of the LOP-600 include: low standby power (<0.5W), high efficiency (up to 95%) capable of delivering 400W with natural air cooling and 600W with additional fan. It has an overload capacity of 150% at 3 seconds, a wide operating temperature range of -40 to +80°C, complies with OVOIII and is suitable for Class I (with FG) or Class Il (without FG) systems. The product has received several safety certifications, including 62368-1/60601-1/61558-1/60335-1, and is designed to meet 2xMOPP and an extremely low touch leakage current <70 uA, making it suitable for BF class medical devices. Thanks to the high product safety and excellent EMC performance, it is versatile and applicable in various fields such as ITE, medical technology, industrial control, home automation and more. It is a cost-effective, slim open-frame power supply.
Features
  • Adjustable output voltage
  • DC compatible
  • DC-OK-Signal
  • Fan Connector
  • Peak Power
  • Remote Sense
Application note
  • These power supply units are intended for installation in end devices.
Notice

Operating conditions

MTBF
  • 310,900 h
Operating expectation
  • 30,000 h
Operating Temperature Min.
  • -40 °C
Operating Temperature Max.
  • 80 °C
Storage Temperature Min.
  • -40 °C
Storage Temperature Max.
  • 85 °C

Input

Mains connection/phases
  • I
Mains frequency min.
  • 47 Hz
Mains frequency max.
  • 63 Hz
Input voltage min. AC
  • 80 V
Input voltage max. AC
  • 264 V
Input voltage min. DC
  • 113 V
Input voltage max. DC
  • 370 V
Input current
  • 3.2 A
Efficiency
  • 94 %
No load power, less than
  • 0.5 W
Leakage current, max.
  • 0.5 mA
Inrush current, max.
  • 80 A
Power factor correction (PFC)
Power factor
  • 0.95
Connection type, input
  • Connector

Output

Number of outputs
  • 1
Output Power
  • 600 W
Output power convection cooled
  • 400.8 W
Output voltage
  • 24 V
Ausgangsspannungstoleranz[%]
  • -2 - 2
Ripple & Noise
  • 200 mVp-p
Output current
  • 25.000 A
Overload protection
Type of overload protection
  • Hiccup
Short-circuit protection
Overvoltage protection
Overtemperature protection
Connection type, output
  • Connector

Safety/Certifications

Protection class
  • I/II
Isolation voltage I/P-O/P
  • 4,000 V
Isolation voltage I/P-FG
  • 2,000 V
Isolation voltage O/P-FG
  • 1,500 V
Overvoltage category
  • 3
Approvals
  • AS/NZ
  • CCC
  • CE
  • EAC
  • EN
  • IEC
  • RCM
  • UKCA
  • UL
Standards (EMC)
  • EN 55014
  • EN 55032 Class A
  • EN 55032 Class B
Standards (safety)
  • ANSI/AAMI ES 60601-1
  • EN 60335-1
  • EN 60601-1
  • EN 61558-1
  • EN 61558-2-16
  • EN 62368-1
  • IEC 60335-1
  • IEC 61558-1
  • IEC 61558-2-16
  • IEC 62368-1
  • UL 62368-1
Medical protection classification
  • 2*MOPP
