IXFK360N15T2

Littelfuse THT Power MOSFET N-Channel 360ATc(25°C) 1.670W 4mOhm  TO-264

IXFK360N15T2
Manufacturer Part No.
IXFK360N15T2
Schukat Part No.
IXFK360N15T2
Manufacturer
Enter your company's part number here. Your part number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
Enter your personal project number here to assign the item to a project. Your part project number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.

0 Pcs. in stock

Planned delivery time
Ø 26 Weeks
Life Cycle Status
The life cycle indicates which market phase the item is in. We distinguish between: • Active (green) • NRND = Not Recommended for New Designs (yellow) • LTB = Last Time Buy (yellow) • EOL = End of Life (red)
Active
Available on order
Replacement / Follow-up View entire series
Data Sheet
ECAD Model
Downloads

Prices

Manufacturer bundle 25 Pcs.
Manufacturer's packaging unit (Mfr. PU) means the smallest original packaging unit of the manufacturer.
Price per 1 Pcs.

Quantity and Options

(at least 300 or multiple of 25)
All prices net plus VAT. We do not deliver to private customers.

Fact Sheet

Number of Channels
1
Polarity
N-Channel
(Id) Continuous Drain Current
360 A Tc (25°C)
(Pd) Power Dissipation
1,670 W
(RDS(on)) Drain-Source Widerstand max. Q1
4 mOhm
Manufacturer Package
TO-264
RoHS-Conform

Specifications

Close all

General

Manufacturer
  • Littelfuse
Type
  • Power MOSFET
Series
  • GigaMOS™ HiperFET™
Product group
  • U8344
Packaging
  • Tube
Assembly Type
  • THT
Pin Count
  • 3
Manufacturer Package
  • TO-264
Configuration
  • Single
Technology
  • TrenchT2™
Material
  • Si
Betriebsmodus
  • Enhancement

Operating conditions

Barrier Layer temperature, min. (TJ)
  • -55 °C
Barrier Layer Temperature, max. (TJ)
  • 175 °C
Storage Temperature Min.
  • -55 °C
Storage Temperature Max.
  • 175 °C

Electrical Properties

(Uds) Max. Drain-Source Voltage
  • 150 V
(Id) Continuous Drain Current
  • 360 A Tc (25°C)
(Id) Continuous Drain Current Temperatur Q1
  • Tc (25°C)
(Ugs) Gate-Source Voltage
  • ±20V
(Ugs th) Gate-Source Threshold Voltage
  • 5 V
(Ugs th) Gate-Source Schwellspannung min. Q1
  • 2.5 V
(Ugs th) Gate-Source Schwellspannung max. Q1
  • 5 V
Number of Channels
  • 1
Polarity
  • N-Channel
(Pd) Power Dissipation
  • 1,670 W
(Pd) Verlustleistung Temperatur
  • Tc (25°C)
(RDS(on)) Drain-Source Widerstand max. Q1
  • 4 mOhm
(RDS(on)) Drain-Source Widerstand max.
  • 4 mOhm  VGS (10V), ID (60A)
  • 4 mOhm  VGS (10V), ID (60A)
(Qg) Gate Charge
  • 715 nC
Vorwärtstranskonduktanz min. Q1
  • 140 s
Anstiegszeit Q1
  • 170 ns
Typische Ausschaltverzögerungszeit Q1
  • 115 ns
Abfallzeit Q1
  • 265 ns
