IXFK150N30P3
Littelfuse THT Power MOSFET N-Channel 150A 1,300W 19mOhm TO-264AA
Enter your company's part number here. Your part number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
Enter your personal project number here to assign the item to a project. Your part project number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
Item no longer available!
Planned delivery time
--- Life Cycle Status
The life cycle indicates which market phase the item is in. We distinguish between:
• Active (green)
• NRND = Not Recommended for New Designs (yellow)
• LTB = Last Time Buy (yellow)
• EOL = End of Life (red)
EOL 01.07.2025
Article discontinued
Data Sheet
ECAD Model
Prices
Manufacturer bundle 25 Pcs.
Manufacturer's packaging unit (Mfr. PU) means the smallest original packaging unit of the manufacturer.
Price per 1 Pcs.
Quantity and Options
(at least 25 or multiple of 25)
All prices net plus VAT. We do not deliver to private customers.
Fact Sheet
- Number of Channels
- 1
- Polarity
- N-Channel
- (Id) Continuous Drain Current
- 150 A
150 A - (Pd) Power Dissipation
- 1.3 W
- (RDS(on)) Drain-Source Resistance Max.
- 19 mOhm
- Manufacturer Package
- TO-264AA
- RoHS-Conform
Specifications
Open all
Operating conditions
- Operating Temperature Min.
- -55 °C
- Operating Temperature Max.
- 150 °C
- Storage Temperature Min.
- -55 °C
- Storage Temperature Max.
- 150 °C
Electrical Properties
- (Uds) Max. Drain-Source Voltage
- 300 V
- 300 V
- (Uds) Max. Drain-Source Voltage Q1
- 300 V
- (Id) Continuous Drain Current
- 150 A
- 150 A
- (Id) Continuous Drain Current Q1
- 150 A
- (Ugs) Gate-Source Voltage
- 20 V
- 20 V
- (Ugs) Gate-source voltage Q1
- 20 V
- Number of Channels
- 1
- Polarity
- N-Channel
- (Pd) Power Dissipation
- 1.3 W
- (RDS(on)) Drain-Source Resistance Max.
- 19 mOhm
Documents
PCN_47-IDM_EN.pdf
PCN_LFPCN-DMI-BTA-2024-002_01_EN.pdf
PCN_LFPCN-DMI-BTA-2024-003_01_EN.pdf
PCN_LFPCN-DMI-BTA-2024-003_02_EN.pdf
