Results (369)
Not discontinued
In stock
RoHS compliant
Datasheet
New
| Show Selected | Image | Part No. | Indiv. Part No. | Manufacturer | Price | Availability | Quantity | Series | Data Sheet | RoHS | Manufacturer | Type | Application | Assembly Type | Rated voltage at 50/60Hz | Rated current | Approvals | Protection class front side | Dimension: Length | Dimension: Width | Dimension: Height | Operating Temperature Min. | Operating Temperature Max. | Leakage current, max. | Inductance | Cx | Cy | Climate category |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
51 | Manufacturers Part No. FN394-6-05-11(FN394-6-05-11) Schaffner IEC filter FN 394 Panel mounting 250V 6A IP40 | Customer Part No. Customer Project No. | 4 Pcs. Planned Delivery Time Ø 16 Weeks Available (from stock) | (at least 1 or mul. of 1) | Schaffner | IEC filter | Panel mounting | 250.0 V | 6.0 A | CE ENEC14 UK CA UL cCSA | IP40 | 65.0 mm | 50.0 mm | 69.5 mm | -25.0 °C | 85.0 °C | 560 µA | 0.45 mH | 220 nF | 3,3 nF | ||||||||
52 | Manufacturers Part No. FN394E-1-05-11(FN394E-1-05-11) Schaffner IEC filter FN 394 Panel mounting 250V 1A IP40 | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 16 Weeks Available on order | (at least 20 or mul. of 20) | Schaffner | IEC filter | Panel mounting | 250.0 V | 1.0 A | CE ENEC14 UK CA UL cCSA | IP40 | 65.0 mm | 50.0 mm | 69.5 mm | -25.0 °C | 85.0 °C | 560 µA | 7.5 mH | 220 nF | 3,3 nF | ||||||||
53 | Manufacturers Part No. FN394E-6-05-11(FN394E-6-05-11) Schaffner IEC filter FN 394 Panel mounting 250V 6A IP40 | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 16 Weeks Available on order | (at least 20 or mul. of 20) | Schaffner | IEC filter | Panel mounting | 250.0 V | 6.0 A | CE ENEC14 UK CA UL cCSA | IP40 | 65.0 mm | 50.0 mm | 69.5 mm | -25.0 °C | 85.0 °C | 560 µA | 0.45 mH | 220 nF | 3,3 nF | ||||||||
54 | Manufacturers Part No. FN402-0.5-02(FN402-0.5-02) Schaffner Printed circuit board filter FN 402 Printed circuit board assembly 250V 0,5A | Customer Part No. Customer Project No. | 442 Pcs. Planned Delivery Time Ø 16 Weeks Available (from stock) | (at least 1 or mul. of 1) | Schaffner | Printed circuit board filter | Printed circuit board assembly | 250.0 V | 0.5 A | ENEC14 IEC UL cCSA | 45.0 mm | 28.0 mm | 16.5 mm | -25.0 °C | 100.0 °C | 373 µA | 40.0 mH | 100 nF | 2,2 nF | |||||||||
55 | Manufacturers Part No. FN402-1-02(FN402-1-02) Schaffner Printed circuit board filter FN 402 Printed circuit board assembly 250V 1A | Customer Part No. Customer Project No. | 39 Pcs. Planned Delivery Time Ø 16 Weeks Available (from stock) | (at least 1 or mul. of 1) | Schaffner | Printed circuit board filter | Printed circuit board assembly | 250.0 V | 1.0 A | ENEC14 IEC UL cCSA | 45.0 mm | 28.0 mm | 16.5 mm | -25.0 °C | 100.0 °C | 373 µA | 10.0 mH | 100 nF | 2,2 nF | |||||||||
56 | Manufacturers Part No. FN402-1.6-02(FN402-1.6-02) Schaffner Printed circuit board filter FN 402 Printed circuit board assembly 250V 1,6A | Customer Part No. Customer Project No. | 17 Pcs. Planned Delivery Time Ø 16 Weeks Available (from stock) | (at least 1 or mul. of 1) | Schaffner | Printed circuit board filter | Printed circuit board assembly | 250.0 V | 1.6 A | ENEC14 IEC UL cCSA | 45.0 mm | 28.0 mm | 16.5 mm | -25.0 °C | 100.0 °C | 373 µA | 6.0 mH | 100 nF | 2,2 nF | |||||||||
57 | Manufacturers Part No. FN402-2.5-02(FN402-2.5-02) Schaffner Printed circuit board filter FN 402 Printed circuit board assembly 250V 2,5A | Customer Part No. Customer Project No. | 78 Pcs. Planned Delivery Time Ø 16 Weeks Available (from stock) | (at least 1 or mul. of 1) | Schaffner | Printed circuit board filter | Printed circuit board assembly | 250.0 V | 2.5 A | ENEC14 IEC UL cCSA | 45.0 mm | 28.0 mm | 16.5 mm | -25.0 °C | 100.0 °C | 373 µA | 2.0 mH | 100 nF | 2,2 nF | |||||||||
58 | Manufacturers Part No. FN402-4-02(FN402-4-02) Schaffner Printed circuit board filter FN 402 Printed circuit board assembly 250V 4A | Customer Part No. Customer Project No. | 20 Pcs. Planned Delivery Time Ø 16 Weeks Available (from stock) | (at least 1 or mul. of 1) | Schaffner | Printed circuit board filter | Printed circuit board assembly | 250.0 V | 4.0 A | ENEC14 IEC UL cCSA | 45.0 mm | 28.0 mm | 16.5 mm | -25.0 °C | 100.0 °C | 373 µA | 1.0 mH | 100 nF | 2,2 nF | |||||||||
59 | Manufacturers Part No. FN402-6.5-02(FN402-6.5-02) Schaffner Printed circuit board filter FN 402 Printed circuit board assembly 250V 6,5A | Customer Part No. Customer Project No. | 19 Pcs. Planned Delivery Time Ø 16 Weeks Available (from stock) | (at least 1 or mul. of 1) | Schaffner | Printed circuit board filter | Printed circuit board assembly | 250.0 V | 6.5 A | ENEC14 IEC UL cCSA | 45.0 mm | 28.0 mm | 16.5 mm | -25.0 °C | 100.0 °C | 373 µA | 1.0 mH | 100 nF | 2,2 nF | |||||||||
60 | Manufacturers Part No. FN402B-0.5-02(FN402B-0.5-02) Schaffner Printed circuit board filter FN 402 Printed circuit board assembly 250V 0,5A Medical | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 16 Weeks Available on order | (at least 20 or mul. of 20) | Schaffner | Printed circuit board filter | Medical | Printed circuit board assembly | 250.0 V | 0.5 A | ENEC14 IEC UL cCSA | 45.0 mm | 28.0 mm | 16.5 mm | -25.0 °C | 100.0 °C | 2 µA | 40.0 mH | 100 nF | |||||||||
61 | Manufacturers Part No. FN402B-1-02(FN402B-1-02) Schaffner Printed circuit board filter FN 402 Printed circuit board assembly 250V 1A Medical | Customer Part No. Customer Project No. | 60 Pcs. Planned Delivery Time Ø 16 Weeks Available (from stock) | (at least 1 or mul. of 1) | Schaffner | Printed circuit board filter | Medical | Printed circuit board assembly | 250.0 V | 1.0 A | ENEC14 IEC UL cCSA | 45.0 mm | 28.0 mm | 16.5 mm | -25.0 °C | 100.0 °C | 2 µA | 10.0 mH | 100 nF | |||||||||
62 | Manufacturers Part No. FN402B-1.6-02(FN402B-1.6-02) Schaffner Printed circuit board filter FN 402 Printed circuit board assembly 250V 1,6A Medical | Customer Part No. Customer Project No. | 20 Pcs. Planned Delivery Time Ø 16 Weeks Available (from stock) | (at least 1 or mul. of 1) | Schaffner | Printed circuit board filter | Medical | Printed circuit board assembly | 250.0 V | 1.6 A | ENEC14 IEC UL cCSA | 45.0 mm | 28.0 mm | 16.5 mm | -25.0 °C | 100.0 °C | 2 µA | 6.0 mH | 100 nF | |||||||||
63 | Manufacturers Part No. FN402B-2.5-02(FN402B-2.5-02) Schaffner Printed circuit board filter FN 402 Printed circuit board assembly 250V 2,5A Medical | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 16 Weeks Available on order | (at least 20 or mul. of 20) | Schaffner | Printed circuit board filter | Medical | Printed circuit board assembly | 250.0 V | 2.5 A | ENEC14 IEC UL cCSA | 45.0 mm | 28.0 mm | 16.5 mm | -25.0 °C | 100.0 °C | 2 µA | 2.0 mH | 100 nF | |||||||||
64 | Manufacturers Part No. FN402B-4-02(FN402B-4-02) Schaffner Printed circuit board filter FN 402 Printed circuit board assembly 250V 4A Medical | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 16 Weeks Available on order | (at least 20 or mul. of 20) | Schaffner | Printed circuit board filter | Medical | Printed circuit board assembly | 250.0 V | 4.0 A | ENEC14 IEC UL cCSA | 45.0 mm | 28.0 mm | 16.5 mm | -25.0 °C | 100.0 °C | 2 µA | 1.0 mH | 100 nF | |||||||||
65 | Manufacturers Part No. FN402B-6.5-02(FN402B-6.5-02) Schaffner Printed circuit board filter FN 402 Printed circuit board assembly 250V 6,5A Medical | Customer Part No. Customer Project No. | 20 Pcs. Planned Delivery Time Ø 16 Weeks Available (from stock) | (at least 1 or mul. of 1) | Schaffner | Printed circuit board filter | Medical | Printed circuit board assembly | 250.0 V | 6.5 A | ENEC14 IEC UL cCSA | 45.0 mm | 28.0 mm | 16.5 mm | -25.0 °C | 100.0 °C | 2 µA | 1.0 mH | 100 nF | |||||||||
66 | Manufacturers Part No. FN9222B-10-06(FN9222B-10-06) Schaffner IEC filter FN 9222 Panel mounting 250V 10A Medical IP40 | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 14 Weeks Available on order | (at least 120 or mul. of 120) | Schaffner | IEC filter | Medical | Panel mounting | 250.0 V | 10.0 A | CE CQC ENEC14 UK CA UL cCSA | IP40 | 48.0 mm | 22.4 mm | 38.25 mm | -25.0 °C | 85.0 °C | 0.23 mH | 0,1 µF | |||||||||
67 | Manufacturers Part No. FN9222B-15-06(FN9222B-15-06) Schaffner IEC filter FN 9222 Panel mounting 250V 15A Medical IP40 | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 14 Weeks Available on order | (at least 120 or mul. of 120) | Schaffner | IEC filter | Medical | Panel mounting | 250.0 V | 15.0 A | CE CQC ENEC14 UK CA UL cCSA | IP40 | 48.0 mm | 22.4 mm | 38.25 mm | -25.0 °C | 85.0 °C | 0.08 mH | 0,1 µF | |||||||||
68 | Manufacturers Part No. FN9222B-3-06(FN9222B-3-06) Schaffner IEC filter FN 9222 Panel mounting 250V 3A Medical IP40 | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 14 Weeks Available on order | (at least 120 or mul. of 120) | Schaffner | IEC filter | Medical | Panel mounting | 250.0 V | 3.0 A | CE CQC ENEC14 UK CA UL cCSA | IP40 | 48.0 mm | 22.4 mm | 38.25 mm | -25.0 °C | 85.0 °C | 2.5 mH | 0,1 µF | |||||||||
69 | Manufacturers Part No. FN9222B-6-06(FN9222B-6-06) Schaffner IEC filter FN 9222 Panel mounting 250V 6A Medical IP40 | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 14 Weeks Available on order | (at least 120 or mul. of 120) | Schaffner | IEC filter | Medical | Panel mounting | 250.0 V | 6.0 A | CE CQC ENEC14 UK CA UL cCSA | IP40 | 48.0 mm | 22.4 mm | 38.25 mm | -25.0 °C | 85.0 °C | 0.78 mH | 0,1 µF | |||||||||
70 | Manufacturers Part No. FN9222-1-06(FN9222-1-06) Schaffner IEC filter FN 9222 Panel mounting 250V 1A IP40 | Customer Part No. Customer Project No. | 133 Pcs. Planned Delivery Time Ø 14 Weeks Available (from stock) | (at least 1 or mul. of 1) | Schaffner | IEC filter | Panel mounting | 250.0 V | 1.0 A | CE CQC ENEC14 UK CA UL cCSA | IP40 | 48.0 mm | 22.4 mm | 38.25 mm | -25.0 °C | 85.0 °C | 0,31 mA | 12.0 mH | 0,1 µF | 2,2 nF | ||||||||
71 | Manufacturers Part No. FN9222-10-06(FN9222-10-06) Schaffner IEC filter FN 9222 Panel mounting 250V 10A IP40 | Customer Part No. Customer Project No. | 127 Pcs. Planned Delivery Time Ø 14 Weeks Available (from stock) | (at least 1 or mul. of 1) | Schaffner | IEC filter | Panel mounting | 250.0 V | 10.0 A | CE CQC ENEC14 UK CA UL cCSA | IP40 | 48.0 mm | 22.4 mm | 38.25 mm | -25.0 °C | 85.0 °C | 0,31 mA | 0.23 mH | 0,1 µF | 2,2 nF | ||||||||
72 | Manufacturers Part No. FN9222-15-06(FN9222-15-06) Schaffner IEC filter FN 9222 Panel mounting 250V 15A IP40 | Customer Part No. Customer Project No. | 257 Pcs. Planned Delivery Time Ø 14 Weeks Available (from stock) | (at least 1 or mul. of 1) | Schaffner | IEC filter | Panel mounting | 250.0 V | 15.0 A | CE CQC ENEC14 UK CA UL cCSA | IP40 | 48.0 mm | 22.4 mm | 38.25 mm | -25.0 °C | 85.0 °C | 0,31 mA | 0.08 mH | 0,1 µF | 2,2 nF | ||||||||
73 | Manufacturers Part No. FN9222-3-06(FN9222-3-06) Schaffner IEC filter FN 9222 Panel mounting 250V 3A IP40 | Customer Part No. Customer Project No. | 39 Pcs. Planned Delivery Time Ø 14 Weeks Available (from stock) | (at least 1 or mul. of 1) | Schaffner | IEC filter | Panel mounting | 250.0 V | 3.0 A | CE CQC ENEC14 UK CA UL cCSA | IP40 | 48.0 mm | 22.4 mm | 38.25 mm | -25.0 °C | 85.0 °C | 0,31 mA | 2.5 mH | 0,1 µF | 2,2 nF | ||||||||
74 | Manufacturers Part No. FN9222-6-06(FN9222-6-06) Schaffner IEC filter FN 9222 Panel mounting 250V 6A IP40 | Customer Part No. Customer Project No. | 49 Pcs. Planned Delivery Time Ø 14 Weeks Available (from stock) | (at least 1 or mul. of 1) | Schaffner | IEC filter | Panel mounting | 250.0 V | 6.0 A | CE CQC ENEC14 UK CA UL cCSA | IP40 | 48.0 mm | 22.4 mm | 38.25 mm | -25.0 °C | 85.0 °C | 0,31 mA | 0.78 mH | 0,1 µF | 2,2 nF | ||||||||
75 | Manufacturers Part No. FN9222B-1-06(FN9222B-1-06) Schaffner IEC filter FN 9222 Panel mounting 250V 1A Medical IP40 | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 14 Weeks Available on order | (at least 120 or mul. of 120) | Schaffner | IEC filter | Medical | Panel mounting | 250.0 V | 1.0 A | CE CQC ENEC14 UK CA UL cCSA | IP40 | 48.0 mm | 22.4 mm | 38.25 mm | -25.0 °C | 85.0 °C | 12.0 mH | 0,1 µF |
