Manufacturer Part No.
16 95 02 SB
Schukat Part No.
KNIP1695-02SB
Manufacturer
Enter your company's part number here. Your part number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
Enter your personal project number here to assign the item to a project. Your part project number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.

0 Pcs. in stock

Planned delivery time
Ø 2 Weeks
Life Cycle Status
The life cycle indicates which market phase the item is in. We distinguish between: • Active (green) • NRND = Not Recommended for New Designs (yellow) • LTB = Last Time Buy (yellow) • EOL = End of Life (red)
Active
Available on order
Replacement / Follow-up View entire series
Data Sheet
ECAD Model
Downloads

Prices

Manufacturer bundle 6 Pcs.
Manufacturer's packaging unit (Mfr. PU) means the smallest original packaging unit of the manufacturer.
Price per 1 Pcs.

Quantity and Options

(at least 1 or multiple of 1)
All prices net plus VAT. We do not deliver to private customers.

Fact Sheet

Type
Stripping Tool
Series
ErgoStrip®
Cutting Parameters, (diameter), min.
8 mm
Cutting Parameters, (diameter), max.
13 mm
Capacity, min.
0.2 mm²
Capacity, max.
4 mm²
Dimension: Length
135 mm
Dimension: Width
85 mm
Dimension: Height
37 mm
Weight
75 g

Specifications

Open all

General

Manufacturer
  • Knipex
Type
  • Stripping Tool
Series
  • ErgoStrip®
Product group
  • T4422 Knipex Insulation Strippers
Dimension: Length
  • 135 mm
Dimension: Width
  • 85 mm
Dimension: Height
  • 37 mm
Application
  • Stripping and dismantling

Weight
  • 75 g
Material: Base
  • Plastic, Glass Fiber Reinforced
Material: Handles
  • Multicomponent Shell
Features
  • - Ergonomic and multifunctional, double-shell pistol grip design
    - Space-saving stripping due to slim tool ends
    - Simplified insertion of single conductors for stripping due to positioning bars
    - Comfortable handling and secure grip
    - With opening spring and ratchet


Field of application

Cable type
  • coaxial cable
  • damp-proof cable
  • datacable
  • round cable
Cutting Parameters, (diameter), min.
  • 8 mm
Cutting Parameters, (diameter), max.
  • 13 mm
Capacity, min.
  • 0.2 mm²
Capacity, max.
  • 4 mm²
