343.443-58V
Hansor Polymer Technology Automotive fuse 343.400-58V 58VDC 100A purple
Manufacturer Part No.
343.443-58V
Schukat Part No.
343.443-58V
Manufacturer
Enter your company's part number here. Your part number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
Enter your personal project number here to assign the item to a project. Your part project number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
50 Pcs. in stock
Planned delivery time
Ø 14 Weeks
Life Cycle Status
The life cycle indicates which market phase the item is in. We distinguish between:
• Active (green)
• NRND = Not Recommended for New Designs (yellow)
• LTB = Last Time Buy (yellow)
• EOL = End of Life (red)
Active
Available (from stock)
Data Sheet
ECAD Model
Prices
Manufacturer bundle 100 Pcs.
Manufacturer's packaging unit (Mfr. PU) means the smallest original packaging unit of the manufacturer.
Price per 1 Pcs.
Quantity and Options
(at least 1 or multiple of 1)
All prices net plus VAT. We do not deliver to private customers.
Fact Sheet
- Notice
- Cross-references:
• Here you will find suitable fuse holders. - Type
- Automotive fuse
- Series
- 343.400-58V
- Design
- Flat plug fuse
- Colour
- purple
- Rated current
- 100 A
- Rated voltage V DC
- 58 V DC
- Switching capacity
- 1.000 A
- RoHS-Conform
Specifications
Open all
Dimensions and Weights
- Dimension: Length
- 19.3 mm
- Dimension: Width
- 5 mm
- Dimension: Height
- 19.05 mm
Technical Features
- Rated current
- 100 A
- Switching capacity
- 1.000 A
- Rated voltage V DC
- 58 V DC
- Contact resistance, max.
- 6 mOhm
Safety/Certifications
- Standards
- SAE J1888, SAE J2576, ISO 8820-3
