1551XBK

Hammond 1551 Small housing 80mm x 80mm x 20mm black IP54

Manufacturer Part No.
1551XBK
Schukat Part No.
HA1551XBK
Manufacturer
Enter your company's part number here. Your part number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
Enter your personal project number here to assign the item to a project. Your part project number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.

0 Pcs. in stock

Planned delivery time
Ø 3 Weeks
Life Cycle Status
The life cycle indicates which market phase the item is in. We distinguish between: • Active (green) • NRND = Not Recommended for New Designs (yellow) • LTB = Last Time Buy (yellow) • EOL = End of Life (red)
Active
Available on order
Replacement / Follow-up View entire series
Data Sheet
ECAD Model
Downloads

Prices

Manufacturer bundle 1 Pcs.
Manufacturer's packaging unit (Mfr. PU) means the smallest original packaging unit of the manufacturer.
Price per 1 Pcs.

Quantity and Options

(at least 5 or multiple of 5)
All prices net plus VAT. We do not deliver to private customers.

Fact Sheet

Type
Small housing
Assembly Type
Screw mounting
Dimension: Length
80 mm
Dimension: Width
80 mm
Dimension: Height
20 mm
Colour
black
Material
ABS (Acrylonitrile Butadiene Styrene)
Protection Class IP
IP54
RoHS-Conform

Specifications

Open all

General

Manufacturer
  • Hammond
Series
  • 1551
Product group
  • G4113
Material
  • ABS (Acrylonitrile Butadiene Styrene)
Colour
  • black
Type
  • Small housing
Assembly Type
  • Screw mounting
Features
  • - Miniature enclosures in black, grey (similar to RAL 7035), translucent clear, translucent blue, translucent red, translucent smoke
    - Cams in interior to mount a printed circuit
    - Corner screw connection of both enclosure parts
    - Protection class IP54

Dimensions and Weights

Dimension: Length
  • 80 mm
Dimension: Width
  • 80 mm
Dimension: Height
  • 20 mm

Safety/Certifications

Protection Class IP
  • IP54
