BVEI4221285
Hahn Print transformer BVEI442 EI38 6VA 230V 9V 667mA not short circuit proof
Enter your company's part number here. Your part number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
Enter your personal project number here to assign the item to a project. Your part project number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
Item no longer available!
Back Order
0 Pcs.
0 Pcs.
Planned delivery time
--- Life Cycle Status
The life cycle indicates which market phase the item is in. We distinguish between:
• Active (green)
• NRND = Not Recommended for New Designs (yellow)
• LTB = Last Time Buy (yellow)
• EOL = End of Life (red)
EOL 18.02.2020
Article discontinued
Data Sheet
ECAD Model
Prices
Manufacturer bundle 30 Pcs.
Manufacturer's packaging unit (Mfr. PU) means the smallest original packaging unit of the manufacturer.
Price per 1 Pcs.
Quantity and Options
(at least 30 or multiple of 30)
All prices net plus VAT. We do not deliver to private customers.
Fact Sheet
- Type
- Print transformer
- Series
- BVEI442
- Core
- EI38
- Performance
- 6 VA
- Primary voltage
- 230 V
- Secondary voltage
- 9 V
- RoHS-Conform
Specifications
Open all
Dimensions and weights
- Dimension: Length
- 41 mm
- Dimension: Width
- 35.1 mm
- Dimension: Height
- 28 mm
Operating conditions
- Permissible excess temperature
- 50 K K
Technical features
- Number of inputs
- 1
- Primary voltage
- 230 V
- Number of outputs
- 1
- Secondary voltage
- 9 V
- Secondary current
- 667 mA
- Open circuit voltage
- < 2 x UN sek
- Test voltage
- 4 kV
- Performance
- 6 VA
- Temperature resistance class
- T 70/B
- Final temperature in intended use
- 120 °C
Safety/Certifications
- Approvals
- ENEC10
- UL
- VDE 0570
- cCSA
