BVEI3034003
Hahn Print transformer BVEI303 EI30 1,9VA 230V 6V 316mA absolutely short circuit proof
NEW
Enter your company's part number here. Your part number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
Enter your personal project number here to assign the item to a project. Your part project number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
0 Pcs. in stock
Planned delivery time
Ø 3 Weeks
Life Cycle Status
The life cycle indicates which market phase the item is in. We distinguish between:
• Active (green)
• NRND = Not Recommended for New Designs (yellow)
• LTB = Last Time Buy (yellow)
• EOL = End of Life (red)
Active
Available on order
Data Sheet
ECAD Model
Prices
Manufacturer bundle 300 Pcs.
Manufacturer's packaging unit (Mfr. PU) means the smallest original packaging unit of the manufacturer.
Price per 1 Pcs.
Quantity and Options
(at least 1000 or multiple of 1)
All prices net plus VAT. We do not deliver to private customers.
Fact Sheet
- Series
- BVEI303
- Core
- EI30
- Performance
- 1.9 VA
- Primary Voltage
- 230 V
- Secondary Voltage
- 6 V
- RoHS-Conform
Specifications
Open all
Dimensions and Weights
- Dimension: Length
- 33.2 mm
- Dimension: Width
- 28.2 mm
- Dimension: Height
- 24.3 mm
- Weight
- 81 g
Operating conditions
- Permissible excess temperature
- 70 K
Technical Features
- Number of inputs
- 1
- Primary Voltage
- 230 V
- Number of outputs
- 1
- Secondary Voltage
- 6 V
- Secondary Current
- 316 mA
- Test voltage
- 4 kV
- Performance
- 1.9 VA
- Temperature Resistance Class
- Ta 70/F
- Final temperature in intended use
- 140 °C
- End temperature in the event of a short circuit, max.
- 190 °C
Safety/Certifications
- Approvals
- ENEC10
- UL
- VDE
- cCSA
Documents
BV-EI-303 4003-TRAFO-HAHN-DB-Rev-00-ENTWURF.pdf
