RIM78-050-0.5

HN-Power DC/DC switching regulator (non-isolated) buck 5,00V 0,5A SIP3

RIM78-050-0.5RIM78-050-0.5RIM78-050-0.5
TOP
Manufacturer Part No.
RIM78-050-0.5
Schukat Part No.
RIM78-050-0.5
Manufacturer
HN-Power
Enter your company's part number here. Your part number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
Enter your personal project number here to assign the item to a project. Your part project number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.

161 Pcs. in stock

Next Stock Receipt
Week 39/2026
320 Pcs.
Planned delivery time
Ø 8 Weeks
Life Cycle Status
The life cycle indicates which market phase the item is in. We distinguish between: • Active (green) • NRND = Not Recommended for New Designs (yellow) • LTB = Last Time Buy (yellow) • EOL = End of Life (red)
Active
Available (from stock)
Replacement / Follow-up View entire series
Data Sheet
Open PDF
ECAD Model
Downloads

Prices

Manufacturer bundle 40 Pcs.
Manufacturer's packaging unit (Mfr. PU) means the smallest original packaging unit of the manufacturer.
Price per 1 Pcs.

Quantity and Options

(at least 1 or multiple of 1)
All prices net plus VAT. We do not deliver to private customers.

Fact Sheet

Operating mode
buck
Package/Case
SIP3
Output Power
7.5 W
Output voltage
5 V
Output current
0.500 A
RoHS-Conform

Specifications

Close all

General

Manufacturer
  • HN-Power
Series
  • RIM78
Product group
  • M5422
Application
  • ITE
  • Industry
Operating mode
  • buck
Package/Case
  • SIP3
Dimension: Length
  • 11.68 mm
Dimension: Width
  • 7.5 mm
Dimension: Height
  • 9.65 mm
Packaging
  • Tube
Weight
  • 2 g
Manufacturer's warranty (years)
  • 1
Product description
  • The RIM78-XXX-0.5 series from HN Electronic Components is the modern and energy-efficient alternative to traditional linear voltage regulators. These compact, non-isolated DC/DC step-down converters deliver a stable output of up to 0.5 A, require no heat sink and offer an impressive efficiency of up to 94 per cent. Thanks to their SIL-3-rated plastic housing, electronics built entirely using SMD technology and pin compatibility with LM78XX regulators, these modules are an ideal replacement for inefficient linear solutions – without the need for layout changes. -Up to 6 kV isolation possible -Wide-range inputs -Improved load and mains regulation -Point-of-load architecture supported

Operating conditions

MTBF
  • 4,000,000 h
Operating Temperature Min.
  • -40 °C
Operating Temperature Max.
  • 85 °C
Storage Temperature Min.
  • -40 °C
Storage Temperature Max.
  • 125 °C

Input

Input voltage min. DC
  • 7 V
Input voltage max. DC
  • 28 V
Efficiency
  • 80 %
Connection type, input
  • THT

Output

Output Power
  • 7.5 W
Output voltage
  • 5 V
Output Voltage Max.
  • 5 V
Output voltage tolerance
  • -3.3 %
Ripple & Noise
  • 60 mVp-p
Output current
  • 0.500 A
Short-circuit protection
Overtemperature protection
Connection type, output
  • THT

Safety/Certifications

Approvals
  • CE
  • EN
Standards (safety)
  • EN 60950-1
