VGG106004-6UFLWA

Evervision LCD Graphic Module TFT 1024x600 LED white 500 cd/m2

VGG106004-6UFLWA
Manufacturer Part No.
VGG106004-6UFLWA
Schukat Part No.
VGG106004-6UFLWA
Manufacturer
Evervision
Enter your company's part number here. Your part number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
Enter your personal project number here to assign the item to a project. Your part project number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.

Item no longer available!

Planned delivery time
---
Life Cycle Status
The life cycle indicates which market phase the item is in. We distinguish between: • Active (green) • NRND = Not Recommended for New Designs (yellow) • LTB = Last Time Buy (yellow) • EOL = End of Life (red)
EOL 25.11.2023
Discontinued by manufacturer with replacement
Replacement / Follow-up View entire series
Data Sheet
Open PDF
ECAD Model
Downloads

Prices

Manufacturer bundle 60 Pcs.
Manufacturer's packaging unit (Mfr. PU) means the smallest original packaging unit of the manufacturer.
Price per 1 Pcs.

Quantity and Options

(at least 1 or multiple of 1)
All prices net plus VAT. We do not deliver to private customers.

Fact Sheet

Touch Panel
No Touch
Resolution (Pixel)
1024x600
Display Interface
LVDS
Supply Voltage Min.
3 V
Supply Voltage Max.
3.6 V
(Uf) Forward Voltage
12.8 V
(If) Forward Current
140 mA
Backlight Type
LED
Backlight Colour
white
Backlight Brightness
500 cd/m2
RoHS-Conform

Specifications

Open all

General

Manufacturer
  • Evervision
Type
  • LCD Graphic Module
Series
  • VGG_UFLW_
Product group
  • W6885
  • W6885
Module Width
  • 165 mm
Module Height
  • 104 mm
Module Thickeness
  • 3.5 mm

Operating conditions

Operating Temperature Min.
  • -20 °C
Operating Temperature Max.
  • 70 °C
Storage Temperature Min.
  • -30 °C
Storage Temperature Max.
  • 80 °C

Electrical Properties

(Uf) Forward Voltage
  • 12.8 V
(If) Forward Current
  • 140 mA
Backlight Type
  • LED
Display Interface
  • LVDS
Resolution (Pixel)
  • 1024x600
Touch Panel
  • No Touch
Screen Diagonal
  • 7 ''
Display-Technology
  • TFT
Supply Voltage Min.
  • 3 V
Backlight Colour
  • white
Supply Voltage Max.
  • 3.6 V
Backlight Brightness
  • 500 cd/m2
Expected Lifetime
  • 50,000 h
Pixel Width
  • 0.15 mm
Pixel Heigth
  • 0.144 mm
