EL2200
Everlight OPIC Output Optocouppler 1,4 V 50 mA 1 DIP8
Enter your company's part number here. Your part number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
Enter your personal project number here to assign the item to a project. Your part project number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
45 Pcs. in stock
Planned delivery time
Ø 24 Weeks
Life Cycle Status
The life cycle indicates which market phase the item is in. We distinguish between:
• Active (green)
• NRND = Not Recommended for New Designs (yellow)
• LTB = Last Time Buy (yellow)
• EOL = End of Life (red)
Active
Available (from stock)
Data Sheet
ECAD Model
Prices
Manufacturer bundle 45 Pcs.
Manufacturer's packaging unit (Mfr. PU) means the smallest original packaging unit of the manufacturer.
Price per 1 Pcs.
Quantity and Options
(at least 15 or multiple of 15)
All prices net plus VAT. We do not deliver to private customers.
Fact Sheet
- (Uf) Forward Voltage
- 1.4 V
- (If) Forward Current
- 50 mA
- Number of Channels
- 1
- Transmission Speed
- 5 Mbd
- Manufacturer Package
- DIP8
- RoHS-Conform
Specifications
Open all
Operating conditions
- Operating Temperature Min.
- -40 °C
- Operating Temperature Max.
- 85 °C
Electrical properties
- (Uf) Forward Voltage
- 1.4 V
- (If) Forward Current
- 50 mA
- (Ur) Reverse Voltage
- 5 V
- Transmission Speed
- 5 Mbd
- Number of Channels
- 1
- Supply Voltage Min.
- 4.5 V
- Supply Voltage Max.
- 20 V
Safety/Certifications
- Approvals
- DEMKO
- FIMKO
- NEMKO
- SEMKO
- UL
- VDE
