B1001SYGWA/S530-E2
Everlight LED Light Bar green diffuse 4,5mcd 2,0V DIP-20
Enter your company's part number here. Your part number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
Enter your personal project number here to assign the item to a project. Your part project number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
437 Pcs. in stock
Planned delivery time
Ø 14 Weeks
Life Cycle Status
The life cycle indicates which market phase the item is in. We distinguish between:
• Active (green)
• NRND = Not Recommended for New Designs (yellow)
• LTB = Last Time Buy (yellow)
• EOL = End of Life (red)
Active
Available (from stock)
Data Sheet
ECAD Model
Prices
Manufacturer bundle 19 Pcs.
Manufacturer's packaging unit (Mfr. PU) means the smallest original packaging unit of the manufacturer.
Price per 1 Pcs.
Quantity and Options
(at least 19 or multiple of 19)
All prices net plus VAT. We do not deliver to private customers.
Fact Sheet
- Type
- LED Light Bar
- Lighting Colour
- green
- Luminous Intensity Max.
- 4.5 mcd
- (Uf) Forward Voltage
- 2 V
- (If) Forward Current
- 25 mA
- Peak Emission Wavelength
- 575 nm
- Manufacturer Package
- DIP-20
- RoHS-Conform
Specifications
Open all
Operating conditions
- Operating Temperature, min. (TA)
- -40 °C
- Operating Temperature, max. (TA)
- 85 °C
- Storage Temperature Min.
- -40 °C
- Storage Temperature Max.
- 100 °C
Electrical Properties
- (Uf) Forward Voltage
- 2 V
- (If) Forward Current
- 25 mA
- (Ur) Reverse Voltage
- 5 V
- Lighting Colour
- green
- Luminous Intensity Max.
- 4.5 mcd
- Peak Emission Wavelength
- 575 nm
- Lens Tranparency
- diffuse
