99-235RGBW/S3127/TR8
Everlight SMD/SMT LED red, green, blue (RGB) diffuse 270mcd/270mcd/270mcd 120°/120°/120° 2,625V/2,625V/2,7V
NEW
Manufacturer Part No.
99-235RGBW/S3127/TR8
Schukat Part No.
99-235RGBWS3127TR8
Manufacturer
Enter your company's part number here. Your part number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
Enter your personal project number here to assign the item to a project. Your part project number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
0 Pcs. in stock
Next Stock Receipt
Week 20/2026
3.150 Pcs.
3.150 Pcs.
Planned delivery time
Ø 14 Weeks
Life Cycle Status
The life cycle indicates which market phase the item is in. We distinguish between:
• Active (green)
• NRND = Not Recommended for New Designs (yellow)
• LTB = Last Time Buy (yellow)
• EOL = End of Life (red)
Active
Available (from stock)
Data Sheet
ECAD Model
Prices
Manufacturer bundle 2000 Pcs.
Manufacturer's packaging unit (Mfr. PU) means the smallest original packaging unit of the manufacturer.
Price per 1 Pcs.
Quantity and Options
(at least 5 or multiple of 5)
All prices net plus VAT. We do not deliver to private customers.
Fact Sheet
- Type
- LED
- Lighting Colour
- red, green, blue (RGB)
- Luminous Intensity Max. (colour1/colour2/colour3)
- 270mcd / 270mcd / 270mcd
- Viewing Angle (colour1/colour2/colour3)
- 120° / 120° / 120°
- (Uf) Forward Voltage (1/2/3)
- 2,625V / 2,625V / 2,7V
- (If) Forward Current (colour1/colour2/colour3)
- 50mA / 30mA / 30mA
- Peak Emission Wavelength (colour1/colour2/colour3)
- 632nm / 518nm / 468nm
- Dominant Wavelength Max. (1/2/3)
- 624nm / 525nm / 470nm
- (Pd) Power Dissipation (colour1/colour2/colour3)
- 120mW / 110mW / 110mW
- RoHS-Conform
Specifications
Open all
Operating conditions
- Operating Temperature, min. (TA)
- -40 °C
- Operating Temperature, max. (TA)
- 85 °C
- Barrier Layer Temperature, max. (TJ)
- 115 °C
- Storage Temperature Min.
- -40 °C
- Storage Temperature Max.
- 90 °C
Electrical Properties
- (Uf) Forward Voltage (colour1)
- 1.8 V
- (Uf) Forward Voltage (colour2)
- 2.625 V
- (Uf) Forward Voltage (colour3)
- 2.7 V
- (Uf) Forward Voltage (1/2/3)
- 2,625V / 2,625V / 2,7V
- (If) Forward Current (colour1)
- 50 mA
- (If) Forward Current (colour2)
- 30 mA
- (If) Forward Current (colour3)
- 30 mA
- (If) Forward Current (colour1/colour2/colour3)
- 50mA / 30mA / 30mA
- Lighting Colour
- red, green, blue (RGB)
- Viewing Angle (colour1)
- 120 °
- Viewing Angle (colour2)
- 120 °
- Viewing Angle (colour3)
- 120 °
- Viewing Angle (colour1/colour2/colour3)
- 120° / 120° / 120°
- Luminous Intensity Max. (colour1)
- 270 mcd
- Luminous Intensity Max. (colour2)
- 270 mcd
- Luminous Intensity Max. (colour3)
- 270 mcd
- Luminous Intensity Max. (colour1/colour2/colour3)
- 270mcd / 270mcd / 270mcd
- Dominant Wavelength Max. (colour1)
- 624 nm
- Dominant Wavelength Max. (colour2)
- 525 nm
- Dominant Wavelength Max. (colour3)
- 470 nm
- Dominant Wavelength Max. (1/2/3)
- 624nm / 525nm / 470nm
- Peak Emission Wavelength (colour1)
- 632 nm
- Peak Emission Wavelength (colour2)
- 518 nm
- Peak Emission Wavelength (colour3)
- 468 nm
- Peak Emission Wavelength (colour1/colour2/colour3)
- 632nm / 518nm / 468nm
- (Pd) Power Dissipation (colour1)
- 120 mW
- (Pd) Power Dissipation (colour2)
- 110 mW
- (Pd) Power Dissipation (colour3)
- 110 mW
- (Pd) Power Dissipation (colour1/colour2/colour3)
- 120mW / 110mW / 110mW
- (Ur) Reverse Voltage (colour1)
- 5 V
- (Ur) Reverse Voltage (colour2)
- 5 V
- (Ur) Reverse Voltage (colour3)
- 5 V
- (Ur) Reverse Voltage (1/2/3)
- 5V / 5V / 5V
- Lens Colour
- colorless
- Lens Tranparency
- diffuse
