67-31E/RSC-AV1W2B9Z5/2T
Everlight SMD/SMT LED red clear round 1.800mcd 120° 2,75V PLCC
Manufacturer Part No.
67-31E/RSC-AV1W2B9Z5/2T
Schukat Part No.
EL67-31E/RSC-AV1
Manufacturer
Enter your company's part number here. Your part number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
Enter your personal project number here to assign the item to a project. Your part project number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
2.450 Pcs. in stock
Planned delivery time
Ø 14 Weeks
Life Cycle Status
The life cycle indicates which market phase the item is in. We distinguish between:
• Active (green)
• NRND = Not Recommended for New Designs (yellow)
• LTB = Last Time Buy (yellow)
• EOL = End of Life (red)
Active
Available (from stock)
Data Sheet
ECAD Model
Prices
Manufacturer bundle 2000 Pcs.
Manufacturer's packaging unit (Mfr. PU) means the smallest original packaging unit of the manufacturer.
Price per 1 Pcs.
Quantity and Options
(at least 50 or multiple of 50)
All prices net plus VAT. We do not deliver to private customers.
Fact Sheet
- Lighting Colour
- red
- Luminous Intensity Max.
- 1,800 mcd
- Viewing Angle
- 120 °
- (Uf) Forward Voltage
- 2.75 V
- (If) Forward Current
- 50 mA
- Peak Emission Wavelength
- 632 Nm
- Dominant Wavelength Max.
- 617.5 Nm
- (Pd) Power Dissipation
- 200 mW
- RoHS-Conform
Specifications
Open all
Operating conditions
- Operating Temperature Min.
- -40 °C
- Operating Temperature Max.
- 85 °C
- Storage Temperature Min.
- -40 °C
- Storage Temperature Max.
- 90 °C
Electrical Properties
- (Uf) Forward Voltage
- 2.75 V
- (If) Forward Current
- 50 mA
- (Ur) Reverse Voltage
- 5 V
- Lighting Colour
- red
- Viewing Angle
- 120 °
- Luminous Intensity Max.
- 1,800 mcd
- Dominant Wavelength Max.
- 617.5 Nm
- Peak Emission Wavelength
- 632 Nm
- (Pd) Power Dissipation
- 200 mW
- Lens Colour
- colorless
- Lens Tranparency
- clear
- Lens Shape
- round
