0 Pcs. in stock
Back Order
2.000 Pcs.
2.000 Pcs.
Planned delivery time
Ø 10 Weeks
Life Cycle Status
The life cycle indicates which market phase the item is in. We distinguish between:
• Active (green)
• NRND = Not Recommended for New Designs (yellow)
• LTB = Last Time Buy (yellow)
• EOL = End of Life (red)
Active
Available on order
Data Sheet
ECAD Model
Prices
Manufacturer bundle 2000 Pcs.
Manufacturer's packaging unit (Mfr. PU) means the smallest original packaging unit of the manufacturer.
Price per 1 Pcs.
Quantity and Options
(at least 2000 or multiple of 2000)
All prices net plus VAT. We do not deliver to private customers.
Fact Sheet
- Manufacturer Package
- LGA-48
- CPU Architecture
- Xtensa
- CPU clock frequency Max.
- 240 MHz
- Program Memory Size
- 4,487 KB
- Memory Size
- 520 KB
- Number of I/O Pins
- 31 I/O
- Transmission Protocol
- IEEE 802.11 b/g/n; 2.4 GHz; HT20/40; up to 150 Mbps
- Supply Voltage Min.
- 3 V
- Supply Voltage Max.
- 3.6 V
- Interfaces
- CAN (TWAI)_1x
I2C_2x
I2S_2x
SPI_4x
UART_3x - RoHS-Conform
Specifications
Open all
Operating conditions
- Operating Temperature Min.
- -40 °C
- Operating Temperature Max.
- 85 °C
Electrical Properties
- CPU Architecture
- Xtensa
- Number of Processor Core
- 2
- Transmission Protocol
- IEEE 802.11 b/g/n; 2.4 GHz; HT20/40; up to 150 Mbps
- Bluetooth
- BR/EDR + Bluetooth LE v4.2
- Security
- 1k OTP, AES, SHA, RSA, ECC, RNG, Secure Boot, Flash Encryption
- Transmission Frequency
- 2.4 GHz
- CPU clock frequency Max.
- 240 MHz
- Data Rate Max.
- 150 Mb/s
- Supply Voltage Min.
- 3 V
- Supply Voltage Max.
- 3.6 V
- Flash
- 4 MB
- Flash SPI
- Quad
- SRAM
- 520 KB
- ROM
- 448 KB
- PSRAM
- 0 MB
- Interfaces
- CAN (TWAI)_1x
- I2C_2x
- I2S_2x
- SPI_4x
- UART_3x
- Real-Time Clock
- Number of PWM Channels
- 16
- Number of ADC Channels
- 1(8) 1(10)
- ADC Resolution
- 12 bit
- Ethernet Speed
- RMII
- Crypto Engine
- USB OTG
- Program Memory Size
- 4,487 KB
- Memory Size
- 520 KB
- Number of I/O Pins
- 31 I/O
