Results (573)
RoHS compliant
Datasheet
New
In stock
Sale
Not discontinued
| Show Selected | Image | Part No. | Indiv. Part No. | Manufacturer | Price | Availability | Quantity | Series | Data Sheet | RoHS | Type | Manufacturer | Characteristic | Specifications | Rated voltage V AC | Rated voltage V DC | Voltage drop | Rated current | Rated breaking capacity | Operating temperature range, min. | Operating temperature range, max. | Dimension: Length | Dimension: Width | Dimension: Height | Qualification | Approvals |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
176 |  | Manufacturers Part No. 152000.0,63GT-5K(152000.0.63GT-5K) SIBA SMD fuse 152000 superquickacting 50A 32VDC 0,63A 1,55x0,85mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 14 Weeks Available on order | (at least 5000 or mul. of 5000) | SMD fuse | SIBA | super quick acting | 32.0 V DC | 331.0 mV | 0.63 A | 50 A | 1.55 mm | 0.85 mm | 0.45 mm | VDE cULus | ||||||||||
177 | | Manufacturers Part No. 152000.2,5GT-5K(152000.2.5GT-5K) SIBA SMD fuse 152000 superquickacting 50A 32VDC 2,5A 1,55x0,85mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 14 Weeks Available on order | (at least 5000 or mul. of 5000) | SMD fuse | SIBA | super quick acting | 32.0 V DC | 151.0 mV | 2.5 A | 50 A | 1.55 mm | 0.85 mm | 0.45 mm | VDE cULus | ||||||||||
178 | | Manufacturers Part No. 152000.0,5GT-5K(152000.0.5GT-5K) SIBA SMD fuse 152000 superquickacting 50A 32VDC 0,5A 1,55x0,85mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 14 Weeks Available on order | (at least 5000 or mul. of 5000) | SMD fuse | SIBA | super quick acting | 32.0 V DC | 361.0 mV | 0.5 A | 50 A | 1.55 mm | 0.85 mm | 0.45 mm | VDE cULus | ||||||||||
179 | | Manufacturers Part No. 152000.1,6GT-5K(152000.1.6GT-5K) SIBA SMD fuse 152000 superquickacting 50A 32VDC 1,6A 1,55x0,85mm | Customer Part No. Customer Project No. | 5.000 Pcs. Planned Delivery Time Ø 14 Weeks Available (from stock) | (at least 100 or mul. of 100) | SMD fuse | SIBA | super quick acting | 32.0 V DC | 159.0 mV | 1.6 A | 50 A | 1.55 mm | 0.85 mm | 0.45 mm | VDE cULus | ||||||||||
180 | | Manufacturers Part No. 152000.1GT-5K(152000.1GT-5K) SIBA SMD fuse 152000 superquickacting 50A 32VDC 1A 1,55x0,85mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 14 Weeks Available on order | (at least 5000 or mul. of 5000) | SMD fuse | SIBA | super quick acting | 32.0 V DC | 223.0 mV | 1.0 A | 50 A | 1.55 mm | 0.85 mm | 0.45 mm | VDE cULus | ||||||||||
181 | | Manufacturers Part No. 152000.3,15GT-5K(152000.3.15GT-5K) SIBA SMD fuse 152000 superquickacting 50A 32VDC 3,15A 1,55x0,85mm | Customer Part No. Customer Project No. | 3.400 Pcs. Planned Delivery Time Ø 14 Weeks Available (from stock) | (at least 100 or mul. of 100) | SMD fuse | SIBA | super quick acting | 32.0 V DC | 120.0 mV | 3.15 A | 50 A | 1.55 mm | 0.85 mm | 0.45 mm | VDE cULus | ||||||||||
182 | | Manufacturers Part No. 154000.1,5GT-5K(154000.1.5GT-5K) SIBA SMD fuse 154000 superquickacting 50A 63VDC 1,5A 3,2x1,6mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 14 Weeks Available on order | (at least 5000 or mul. of 5000) | SMD fuse | SIBA | super quick acting | 63.0 V DC | 207.0 mV | 1.5 A | 50 A | 3.2 mm | 1.6 mm | 0.55 mm | |||||||||||
183 | | Manufacturers Part No. 154000.2GT-5K(154000.2GT-5K) SIBA SMD fuse 154000 superquickacting 50A 63VDC 2A 3,2x1,6mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 14 Weeks Available on order | (at least 5000 or mul. of 5000) | SMD fuse | SIBA | super quick acting | 63.0 V DC | 181.0 mV | 2.0 A | 50 A | 3.2 mm | 1.6 mm | 0.55 mm | |||||||||||
184 | | Manufacturers Part No. 154000.1GT-5K(154000.1GT-5K) SIBA SMD fuse 154000 superquickacting 50A 63VDC 1A 3,2x1,6mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 14 Weeks Available on order | (at least 5000 or mul. of 5000) | SMD fuse | SIBA | super quick acting | 63.0 V DC | 262.0 mV | 1.0 A | 50 A | 3.2 mm | 1.6 mm | 0.55 mm | |||||||||||
185 | | Manufacturers Part No. 154000.2,5GT-5K(154000.2.5GT-5K) SIBA SMD fuse 154000 superquickacting 50A 63VDC 2,5A 3,2x1,6mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 14 Weeks Available on order | (at least 5000 or mul. of 5000) | SMD fuse | SIBA | super quick acting | 63.0 V DC | 161.0 mV | 2.5 A | 50 A | 3.2 mm | 1.6 mm | 0.55 mm | |||||||||||
186 | | Manufacturers Part No. 154000.3GT-5K(154000.3GT-5K) SIBA SMD fuse 154000 superquickacting 50A 63VDC 3A 3,2x1,6mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 14 Weeks Available on order | (at least 5000 or mul. of 5000) | SMD fuse | SIBA | super quick acting | 63.0 V DC | 173.0 mV | 3.0 A | 50 A | 3.2 mm | 1.6 mm | 0.55 mm | |||||||||||
187 | | Manufacturers Part No. 154000.4GT-5K(154000.4GT-5K) SIBA SMD fuse 154000 superquickacting 50A 63VDC 4A 3,2x1,6mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 14 Weeks Available on order | (at least 5000 or mul. of 5000) | SMD fuse | SIBA | super quick acting | 63.0 V DC | 147.0 mV | 4.0 A | 50 A | 3.2 mm | 1.6 mm | 0.55 mm | |||||||||||
188 | | Manufacturers Part No. 154000.5GT-5K(154000.5GT-5K) SIBA SMD fuse 154000 superquickacting 50A 63VDC 5A 3,2x1,6mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 14 Weeks Available on order | (at least 5000 or mul. of 5000) | SMD fuse | SIBA | super quick acting | 63.0 V DC | 131.0 mV | 5.0 A | 50 A | 3.2 mm | 1.6 mm | 0.55 mm | |||||||||||
189 | | Manufacturers Part No. 3413.0002.11(3413.0002.11) Schurter SMD fuse USFF1206 superquickacting 10A 125VAC 63VDC 0,05A 3,2x1,6mm | Customer Part No. Customer Project No. | 650 Pcs. Planned Delivery Time Ø 9 Weeks Available (from stock) | (at least 10 or mul. of 10) | SMD fuse | Schurter | super quick acting | 125.0 V AC | 63.0 V DC | 430.0 mV | 0.05 A | 10 A | -55.0 °C | 90.0 °C | 3.2 mm | 1.6 mm | 1.75 mm | CE IEC UK CA cULus | |||||||
190 | | Manufacturers Part No. 3413.0002.22(3413.0002.22) Schurter SMD fuse USFF1206 superquickacting 10A 125VAC 63VDC 0,05A 3,2x1,6mm | Customer Part No. Customer Project No. | 0 Pcs. Available (from stock) | (at least 100 or mul. of 100) | SMD fuse | Schurter | super quick acting | 125.0 V AC | 63.0 V DC | 430.0 mV | 0.05 A | 10 A | -55.0 °C | 90.0 °C | 3.2 mm | 1.6 mm | 1.75 mm | CE IEC UK CA cULus | |||||||
191 | | Manufacturers Part No. 3413.0006.11(3413.0006.11) Schurter SMD fuse USFF1206 superquickacting 10A 125VAC 63VDC 0,125A 3,2x1,6mm | Customer Part No. Customer Project No. | 450 Pcs. Planned Delivery Time Ø 9 Weeks Available (from stock) | (at least 10 or mul. of 10) | SMD fuse | Schurter | super quick acting | 125.0 V AC | 63.0 V DC | 260.0 mV | 0.125 A | 10 A | -55.0 °C | 90.0 °C | 3.2 mm | 1.6 mm | 1.75 mm | CE IEC UK CA cULus | |||||||
192 | | Manufacturers Part No. 3413.0006.22(3413.0006.22) Schurter SMD fuse USFF1206 superquickacting 10A 125VAC 63VDC 0,125A 3,2x1,6mm | Customer Part No. Customer Project No. | 1.500 Pcs. Planned Delivery Time Ø 9 Weeks Available (from stock) | (at least 100 or mul. of 100) | SMD fuse | Schurter | super quick acting | 125.0 V AC | 63.0 V DC | 260.0 mV | 0.125 A | 10 A | -55.0 °C | 90.0 °C | 3.2 mm | 1.6 mm | 1.75 mm | CE IEC UK CA cULus | |||||||
193 | | Manufacturers Part No. 3413.0008.11(3413.0008.11) Schurter SMD fuse USFF1206 superquickacting 10A 125VAC 63VDC 0,16A 3,2x1,6mm | Customer Part No. Customer Project No. | 490 Pcs. Planned Delivery Time Ø 9 Weeks Available (from stock) | (at least 10 or mul. of 10) | SMD fuse | Schurter | super quick acting | 125.0 V AC | 63.0 V DC | 95.0 mV | 0.16 A | 10 A | -55.0 °C | 90.0 °C | 3.2 mm | 1.6 mm | 1.75 mm | CE IEC UK CA cULus | |||||||
194 | | Manufacturers Part No. 3413.0008.22(3413.0008.22) Schurter SMD fuse USFF1206 superquickacting 10A 125VAC 63VDC 0,16A 3,2x1,6mm | Customer Part No. Customer Project No. | 2.000 Pcs. Planned Delivery Time Ø 9 Weeks Available (from stock) | (at least 100 or mul. of 100) | SMD fuse | Schurter | super quick acting | 125.0 V AC | 63.0 V DC | 95.0 mV | 0.16 A | 10 A | -55.0 °C | 90.0 °C | 3.2 mm | 1.6 mm | 1.75 mm | CE IEC UK CA cULus | |||||||
195 | | Manufacturers Part No. 3413.0009.11(3413.0009.11) Schurter SMD fuse USFF1206 superquickacting 10A 125VAC 63VDC 0,2A 3,2x1,6mm | Customer Part No. Customer Project No. | 490 Pcs. Planned Delivery Time Ø 9 Weeks Available (from stock) | (at least 10 or mul. of 10) | SMD fuse | Schurter | super quick acting | 125.0 V AC | 63.0 V DC | 87.0 mV | 0.2 A | 10 A | -55.0 °C | 90.0 °C | 3.2 mm | 1.6 mm | 1.75 mm | CE IEC UK CA cULus | |||||||
196 | | Manufacturers Part No. 3413.0009.22(3413.0009.22) Schurter SMD fuse USFF1206 superquickacting 10A 125VAC 63VDC 0,2A 3,2x1,6mm | Customer Part No. Customer Project No. | 1.000 Pcs. Planned Delivery Time Ø 9 Weeks Available (from stock) | (at least 100 or mul. of 100) | SMD fuse | Schurter | super quick acting | 125.0 V AC | 63.0 V DC | 87.0 mV | 0.2 A | 10 A | -55.0 °C | 90.0 °C | 3.2 mm | 1.6 mm | 1.75 mm | CE IEC UK CA cULus | |||||||
197 | | Manufacturers Part No. 3413.0010.11(3413.0010.11) Schurter SMD fuse USFF1206 superquickacting 10A 125VAC 63VDC 0,25A 3,2x1,6mm | Customer Part No. Customer Project No. | 500 Pcs. Planned Delivery Time Ø 9 Weeks Available (from stock) | (at least 10 or mul. of 10) | SMD fuse | Schurter | super quick acting | 125.0 V AC | 63.0 V DC | 75.0 mV | 0.25 A | 10 A | -55.0 °C | 90.0 °C | 3.2 mm | 1.6 mm | 1.75 mm | CE IEC UK CA cULus | |||||||
198 | | Manufacturers Part No. 3413.0010.22(3413.0010.22) Schurter SMD fuse USFF1206 superquickacting 10A 125VAC 63VDC 0,25A 3,2x1,6mm | Customer Part No. Customer Project No. | 2.400 Pcs. Planned Delivery Time Ø 9 Weeks Available (from stock) | (at least 100 or mul. of 100) | SMD fuse | Schurter | super quick acting | 125.0 V AC | 63.0 V DC | 75.0 mV | 0.25 A | 10 A | -55.0 °C | 90.0 °C | 3.2 mm | 1.6 mm | 1.75 mm | CE IEC UK CA cULus | |||||||
199 | | Manufacturers Part No. 3403.0281.23(3403.0281.23) Schurter SMD fuse UMT-H time-lag 1.500A 277VAC 125VDC 16x5,3mm | Customer Part No. Customer Project No. | 2.630 Pcs. Planned Delivery Time Ø 11 Weeks Available (from stock) | (at least 10 or mul. of 10) | SMD fuse | Schurter | time-lag | 277.0 V AC | 125.0 V DC | 115.0 mV | 1.500 A | -55.0 °C | 125.0 °C | 15.4 mm | 5.35 mm | 5.35 mm | CE IEC UK CA UL VDE cULus | ||||||||
200 | | Manufacturers Part No. 3403.0279.23(3403.0279.23) Schurter SMD fuse UMT-H time-lag 1.500A 277VAC 125VDC 16x5,3mm | Customer Part No. Customer Project No. | 2.700 Pcs. Planned Delivery Time Ø 11 Weeks Available (from stock) | (at least 10 or mul. of 10) | SMD fuse | Schurter | time-lag | 277.0 V AC | 125.0 V DC | 175.0 mV | 1.500 A | -55.0 °C | 125.0 °C | 15.4 mm | 5.35 mm | 5.35 mm | CE CQC IEC UK CA UL VDE cULus |
