Results (542)
RoHS compliant
Datasheet
New
In stock
Sale
Not discontinued
| Show Selected | Image | Part No. | Indiv. Part No. | Manufacturer | Price | Availability | Quantity | Series | Data Sheet | RoHS | Type | Manufacturer | Characteristic | Design | Rated voltage V AC | Rated voltage V DC | Voltage drop | Rated current | Rated breaking capacity | Operating temperature range, min. | Operating temperature range, max. | Dimension: Length | Dimension: Width | Dimension: Height | Qualification | Approvals |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
101 |  | Manufacturers Part No. 3402.0016.22(3402.0016.22) Schurter SMD fuse OMF63 quickacting 50A 63VAC 63VDC 4A 7,4x3,1mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 5 Weeks Available on order | (at least 250 or mul. of 250) | SMD fuse | Schurter | quick acting | 63.0 V AC | 63.0 V DC | 140.0 mV | 4.0 A | 50 A | -40.0 °C | 125.0 °C | 7.4 mm | 3.1 mm | 2.6 mm | CE cULus | |||||||
102 | | Manufacturers Part No. 3402.0017.22(3402.0017.22) Schurter SMD fuse OMF63 quickacting 50A 63VAC 63VDC 5A 7,4x3,1mm | Customer Part No. Customer Project No. | 750 Pcs. Planned Delivery Time Ø 5 Weeks Available (from stock) | (at least 10 or mul. of 10) | SMD fuse | Schurter | quick acting | 63.0 V AC | 63.0 V DC | 140.0 mV | 5.0 A | 50 A | -40.0 °C | 125.0 °C | 7.4 mm | 3.1 mm | 2.6 mm | CE cULus | |||||||
103 | | Manufacturers Part No. 3402.0020.22(3402.0020.22) Schurter SMD fuse OMF63 quickacting 50A 63VAC 63VDC 8A 7,4x3,1mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 5 Weeks Available on order | (at least 250 or mul. of 250) | SMD fuse | Schurter | quick acting | 63.0 V AC | 63.0 V DC | 100.0 mV | 8.0 A | 50 A | -40.0 °C | 125.0 °C | 7.4 mm | 3.1 mm | 2.6 mm | CE cULus | |||||||
104 | | Manufacturers Part No. 3402.0040.22(3402.0040.22) Schurter SMD fuse OMF63 quickacting 50A 63VAC 63VDC 10A 7,4x3,1mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 5 Weeks Available on order | (at least 250 or mul. of 250) | SMD fuse | Schurter | quick acting | 63.0 V AC | 63.0 V DC | 80.0 mV | 10.0 A | 50 A | -40.0 °C | 125.0 °C | 7.4 mm | 3.1 mm | 2.6 mm | CE cULus | |||||||
105 | | Manufacturers Part No. 157000.0,25GT(ESF0.25-SMD) SIBA SMD fuse 157000 quickacting 50A 125VAC 125VDC 0,25A 6,1x2,6mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 5 Weeks Available (from stock) | (at least 100 or mul. of 100) | SMD fuse | SIBA | quick acting | 125.0 V AC | 125.0 V DC | 230.0 mV | 0.25 A | 50 A | 6.1 mm | 2.6 mm | 2.6 mm | cULus | |||||||||
106 | | Manufacturers Part No. 157000.0,5GT(ESF0.5-SMD) SIBA SMD fuse 157000 quickacting 50A 125VAC 125VDC 0,5A 6,1x2,6mm | Customer Part No. Customer Project No. | 3.300 Pcs. Planned Delivery Time Ø 5 Weeks Available (from stock) | (at least 100 or mul. of 100) | SMD fuse | SIBA | quick acting | 125.0 V AC | 125.0 V DC | 180.0 mV | 0.5 A | 50 A | 6.1 mm | 2.6 mm | 2.6 mm | cULus | |||||||||
107 | | Manufacturers Part No. 157000.1GT(ESF1.0-SMD) SIBA SMD fuse 157000 quickacting 50A 125VAC 125VDC 1A 6,1x2,6mm | Customer Part No. Customer Project No. | 1.900 Pcs. Planned Delivery Time Ø 5 Weeks Available (from stock) | (at least 100 or mul. of 100) | SMD fuse | SIBA | quick acting | 125.0 V AC | 125.0 V DC | 150.0 mV | 1.0 A | 50 A | 6.1 mm | 2.6 mm | 2.6 mm | cULus | |||||||||
108 | | Manufacturers Part No. 157000.2GT(ESF2.0-SMD) SIBA SMD fuse 157000 quickacting 50A 125VAC 125VDC 2A 6,1x2,6mm | Customer Part No. Customer Project No. | 1.800 Pcs. Planned Delivery Time Ø 5 Weeks Available (from stock) | (at least 100 or mul. of 100) | SMD fuse | SIBA | quick acting | 125.0 V AC | 125.0 V DC | 100.0 mV | 2.0 A | 50 A | 6.1 mm | 2.6 mm | 2.6 mm | cULus | |||||||||
109 | | Manufacturers Part No. 157000.3GT(ESF3.0-SMD) SIBA SMD fuse 157000 quickacting 50A 125VAC 125VDC 3A 6,1x2,6mm | Customer Part No. Customer Project No. | 1.500 Pcs. Planned Delivery Time Ø 5 Weeks Available (from stock) | (at least 100 or mul. of 100) | SMD fuse | SIBA | quick acting | 125.0 V AC | 125.0 V DC | 100.0 mV | 3.0 A | 50 A | 6.1 mm | 2.6 mm | 2.6 mm | cULus | |||||||||
110 | | Manufacturers Part No. 157000.4GT(ESF4.0-SMD) SIBA SMD fuse 157000 quickacting 50A 125VAC 125VDC 4A 6,1x2,6mm | Customer Part No. Customer Project No. | 2.000 Pcs. Planned Delivery Time Ø 5 Weeks Available (from stock) | (at least 100 or mul. of 100) | SMD fuse | SIBA | quick acting | 125.0 V AC | 125.0 V DC | 100.0 mV | 4.0 A | 50 A | 6.1 mm | 2.6 mm | 2.6 mm | cULus | |||||||||
111 | | Manufacturers Part No. 3403.0016.11(3403.0016.11) Schurter SMD fuse OMF250 quickacting 100A 250VAC 250VDC 1A 11x4,6mm | Customer Part No. Customer Project No. | 230 Pcs. Planned Delivery Time Ø 5 Weeks Available (from stock) | (at least 10 or mul. of 10) | SMD fuse | Schurter | quick acting | 250.0 V AC | 250.0 V DC | 300.0 mV | 1.0 A | 100 A | -55.0 °C | 125.0 °C | 11.0 mm | 4.6 mm | 3.9 mm | CE cULus | |||||||
112 | | Manufacturers Part No. 3403.0019.11(3403.0019.11) Schurter SMD fuse OMF250 quickacting 100A 250VAC 250VDC 2A 11x4,6mm | Customer Part No. Customer Project No. | 400 Pcs. Planned Delivery Time Ø 5 Weeks Available (from stock) | (at least 10 or mul. of 10) | SMD fuse | Schurter | quick acting | 250.0 V AC | 250.0 V DC | 300.0 mV | 2.0 A | 100 A | -55.0 °C | 125.0 °C | 11.0 mm | 4.6 mm | 3.9 mm | CE cULus | |||||||
113 | | Manufacturers Part No. 3403.0020.11(3403.0020.11) Schurter SMD fuse OMF250 quickacting 100A 250VAC 250VDC 2,5A 11x4,6mm | Customer Part No. Customer Project No. | 70 Pcs. Planned Delivery Time Ø 5 Weeks Available (from stock) | (at least 10 or mul. of 10) | SMD fuse | Schurter | quick acting | 250.0 V AC | 250.0 V DC | 300.0 mV | 2.5 A | 100 A | -55.0 °C | 125.0 °C | 11.0 mm | 4.6 mm | 3.9 mm | CE cULus | |||||||
114 | | Manufacturers Part No. 3403.0022.11(3403.0022.11) Schurter SMD fuse OMF250 quickacting 100A 250VAC 250VDC 4A 11x4,6mm | Customer Part No. Customer Project No. | 300 Pcs. Planned Delivery Time Ø 5 Weeks Available (from stock) | (at least 10 or mul. of 10) | SMD fuse | Schurter | quick acting | 250.0 V AC | 250.0 V DC | 300.0 mV | 4.0 A | 100 A | -55.0 °C | 125.0 °C | 11.0 mm | 4.6 mm | 3.9 mm | CE cULus | |||||||
115 | | Manufacturers Part No. 3403.0016.24(3403.0016.24) Schurter SMD fuse OMF250 quickacting 100A 250VAC 250VDC 1A 11x4,6mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 5 Weeks Available on order | (at least 250 or mul. of 250) | SMD fuse | Schurter | quick acting | 250.0 V AC | 250.0 V DC | 300.0 mV | 1.0 A | 100 A | -55.0 °C | 125.0 °C | 11.0 mm | 4.6 mm | 3.9 mm | CE cULus | |||||||
116 | | Manufacturers Part No. 3403.0019.24(3403.0019.24) Schurter SMD fuse OMF250 quickacting 100A 250VAC 250VDC 2A 11x4,6mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 5 Weeks Available on order | (at least 250 or mul. of 250) | SMD fuse | Schurter | quick acting | 250.0 V AC | 250.0 V DC | 300.0 mV | 2.0 A | 100 A | -55.0 °C | 125.0 °C | 11.0 mm | 4.6 mm | 3.9 mm | CE cULus | |||||||
117 | | Manufacturers Part No. 3403.0020.24(3403.0020.24) Schurter SMD fuse OMF250 quickacting 100A 250VAC 250VDC 2,5A 11x4,6mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 5 Weeks Available on order | (at least 250 or mul. of 250) | SMD fuse | Schurter | quick acting | 250.0 V AC | 250.0 V DC | 300.0 mV | 2.5 A | 100 A | -55.0 °C | 125.0 °C | 11.0 mm | 4.6 mm | 3.9 mm | CE cULus | |||||||
118 | | Manufacturers Part No. 3403.0022.24(3403.0022.24) Schurter SMD fuse OMF250 quickacting 100A 250VAC 250VDC 4A 11x4,6mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 5 Weeks Available on order | (at least 250 or mul. of 250) | SMD fuse | Schurter | quick acting | 250.0 V AC | 250.0 V DC | 300.0 mV | 4.0 A | 100 A | -55.0 °C | 125.0 °C | 11.0 mm | 4.6 mm | 3.9 mm | CE cULus | |||||||
119 | | Manufacturers Part No. 158000.0,25GT(EST0.25-SMD) SIBA SMD fuse 158000 time-lag 50A 125VAC 125VDC 0,25A 6,1x2,6mm | Customer Part No. Customer Project No. | 6.300 Pcs. Available (from stock) | (at least 100 or mul. of 100) | SMD fuse | SIBA | time-lag | 125.0 V AC | 125.0 V DC | 280.0 mV | 0.25 A | 50 A | 6.1 mm | 2.6 mm | 2.6 mm | cULus | |||||||||
120 | | Manufacturers Part No. 158000.0,315GT(EST0.315-SMD) SIBA SMD fuse 158000 time-lag 50A 125VAC 125VDC 0,315A 6,1x2,6mm | Customer Part No. Customer Project No. | 1.700 Pcs. Planned Delivery Time Ø 5 Weeks Available (from stock) | (at least 100 or mul. of 100) | SMD fuse | SIBA | time-lag | 125.0 V AC | 125.0 V DC | 260.0 mV | 0.315 A | 50 A | 6.1 mm | 2.6 mm | 2.6 mm | cULus | |||||||||
121 | | Manufacturers Part No. 158000.0,375GT(EST0.375-SMD) SIBA SMD fuse 158000 time-lag 50A 125VAC 125VDC 0,375A 6,1x2,6mm | Customer Part No. Customer Project No. | 3.100 Pcs. Planned Delivery Time Ø 5 Weeks Available (from stock) | (at least 100 or mul. of 100) | SMD fuse | SIBA | time-lag | 125.0 V AC | 125.0 V DC | 230.0 mV | 0.375 A | 50 A | 6.1 mm | 2.6 mm | 2.6 mm | cULus | |||||||||
122 | | Manufacturers Part No. 158000.0,4GT(EST0.4-SMD) SIBA SMD fuse 158000 time-lag 50A 125VAC 125VDC 0,4A 6,1x2,6mm | Customer Part No. Customer Project No. | 3.100 Pcs. Planned Delivery Time Ø 5 Weeks Available (from stock) | (at least 100 or mul. of 100) | SMD fuse | SIBA | time-lag | 125.0 V AC | 125.0 V DC | 220.0 mV | 0.4 A | 50 A | 6.1 mm | 2.6 mm | 2.6 mm | cULus | |||||||||
123 | | Manufacturers Part No. 158000.0,5GT(EST0.5-SMD) SIBA SMD fuse 158000 time-lag 50A 125VAC 125VDC 0,5A 6,1x2,6mm | Customer Part No. Customer Project No. | 3.100 Pcs. Available (from stock) | (at least 100 or mul. of 100) | SMD fuse | SIBA | time-lag | 125.0 V AC | 125.0 V DC | 200.0 mV | 0.5 A | 50 A | 6.1 mm | 2.6 mm | 2.6 mm | cULus | |||||||||
124 | | Manufacturers Part No. 158000.0,63GT(EST0.63-SMD) SIBA SMD fuse 158000 time-lag 50A 125VAC 125VDC 0,63A 6,1x2,6mm | Customer Part No. Customer Project No. | 5.200 Pcs. Planned Delivery Time Ø 5 Weeks Available (from stock) | (at least 100 or mul. of 100) | SMD fuse | SIBA | time-lag | 125.0 V AC | 125.0 V DC | 200.0 mV | 0.63 A | 50 A | 6.1 mm | 2.6 mm | 2.6 mm | cULus | |||||||||
125 | | Manufacturers Part No. 158000.0,75GT(EST0.75-SMD) SIBA SMD fuse 158000 time-lag 50A 125VAC 125VDC 0,75A 6,1x2,6mm | Customer Part No. Customer Project No. | 2.000 Pcs. Available (from stock) | (at least 100 or mul. of 100) | SMD fuse | SIBA | time-lag | 125.0 V AC | 125.0 V DC | 190.0 mV | 0.75 A | 50 A | 6.1 mm | 2.6 mm | 2.6 mm | cULus |
