Results (1847)
RoHS compliant
Datasheet
New
In stock
Sale
Not discontinued
| Show Selected | Image | Part No. | Indiv. Part No. | Manufacturer | Price | Availability | Quantity | Series | Data Sheet | RoHS | Type | Manufacturer | contacts | Assembly Type | Coil: Nominal Voltage AC | Coil: Nominal Voltage DC | Contact: Switching Current (min/typ/max) | Coil Resistance | Dimension: Length | Dimension: Width | Dimension: Height | Contact material | Protection Class | Protection class RT | Operating Temperature Min. | Operating Temperature Max. |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
1276 |  | Manufacturers Part No. G2R-2 DC24(G2R2-24) Aratas Corporation PC relay G2R THT DPDT 5A 24VDC 1.100Ohm 29mmx13mmx25,5mm | Customer Part No. Customer Project No. | 720 Pcs. Planned Delivery Time Ø 30 Weeks Available (from stock) | (at least 10 or mul. of 10) | PC relay | Aratas Corporation | DPDT | THT | 24.0 V DC | 5.0 A | 1100.0 Ohm | 29.0 mm | 13.0 mm | 25.5 mm | AgSnIn | -40.0 °C | 70.0 °C | ||||||||
1277 | | Manufacturers Part No. HJR-3FF-06VDC-S-ZF(HJR-3FF-06VDC-S-ZF) Tianbo PC relay HJR-3FF THT SPDT 15A 6VDC 100Ohm 19mmx15,1mmx15,5mm RTIII | Customer Part No. Customer Project No. | 1.450 Pcs. Planned Delivery Time Ø 20 Weeks Available (from stock) | (at least 10 or mul. of 10) | PC relay | Tianbo | SPDT | THT | 6.0 V DC | 15.0 A | 100.0 Ohm | 19.0 mm | 15.1 mm | 15.5 mm | Ag alloy | IP67 | RTIII | -40.0 °C | 85.0 °C | ||||||
1278 | | Manufacturers Part No. 40.52.9.012.0000(F4052-12) Finder PC relay 40.52 THT DPDT 8A 12VDC 220Ohm 29mmx12,4mmx25mm RTII TOP | Customer Part No. Customer Project No. | 290 Pcs. Planned Delivery Time Ø 2 Weeks Available (from stock) | (at least 5 or mul. of 5) | PC relay | Finder | DPDT | THT | 12.0 V DC | 8.0 A | 220.0 Ohm | 29.0 mm | 12.4 mm | 25.0 mm | AgNi | RTII | -40.0 °C | 85.0 °C | |||||||
1279 | | Manufacturers Part No. 40.52.7.005.0000(F40527-05) Finder PC relay 40.52 THT DPDT 8A 5VDC 50Ohm 29mmx12,4mmx25mm RTII | Customer Part No. Customer Project No. | 85 Pcs. Planned Delivery Time Ø 2 Weeks Available (from stock) | (at least 5 or mul. of 5) | PC relay | Finder | DPDT | THT | 5.0 V DC | 8.0 A | 50.0 Ohm | 29.0 mm | 12.4 mm | 25.0 mm | AgNi | RTII | -40.0 °C | 85.0 °C | |||||||
1280 | | Manufacturers Part No. 40.52.7.024.5000(F40527-24G) Finder PC relay 40.52 THT DPDT 8A 24VDC 1.150Ohm 29mmx12,4mmx25mm RTII | Customer Part No. Customer Project No. | 40 Pcs. Planned Delivery Time Ø 2 Weeks Available (from stock) | (at least 5 or mul. of 5) | PC relay | Finder | DPDT | THT | 24.0 V DC | 8.0 A | 1150.0 Ohm | 29.0 mm | 12.4 mm | 25.0 mm | AgNi/Au | RTII | -40.0 °C | 85.0 °C | |||||||
1281 | | Manufacturers Part No. AZ21501-1AET-12DF(AZ21501-1AET-12DF) Zettler PC relay AZ21501 THT SPST-NO 50A 12VDC 96Ohm 32,5mmx27,6mmx20,5mm | Customer Part No. Customer Project No. | 330 Pcs. Planned Delivery Time Ø 26 Weeks Available (from stock) | (at least 5 or mul. of 5) | PC relay | Zettler | SPST-NO | THT | 12.0 V DC | 50.0 A | 96.0 Ohm | 32.5 mm | 27.6 mm | 20.5 mm | AgSnO2 | -55.0 °C | 85.0 °C | ||||||||
1282 | | Manufacturers Part No. HF33F/012-HSL3F(HF33F-012-HSL3F) Hongfa PC relay HF33F THT SPST-NO 10A 12VDC 720Ohm 20,5mmx10,2mmx15,3mm | Customer Part No. Customer Project No. | 35 Pcs. Available (from stock) | (at least 5 or mul. of 5) | PC relay | Hongfa | SPST-NO | THT | 12.0 V DC | 10.0 A | 720.0 Ohm | 20.5 mm | 10.2 mm | 15.3 mm | AgNi | -40.0 °C | 85.0 °C | ||||||||
1283 | | Manufacturers Part No. 32.21.7.012.4300(F3221-12A) Finder PC relay 32.21 THT SPST-NO 6A 12VDC 720Ohm 20mmx10mmx10,7mm RTII | Customer Part No. Customer Project No. | 40 Pcs. Planned Delivery Time Ø 2 Weeks Available (from stock) | (at least 10 or mul. of 10) | PC relay | Finder | SPST-NO | THT | 12.0 V DC | 6.0 A | 720.0 Ohm | 20.0 mm | 10.0 mm | 10.7 mm | AgSnO2 | RTII | -40.0 °C | 85.0 °C | |||||||
1284 | | Manufacturers Part No. HF33F/012-ZS3F(HF33F-012-ZS3F) Hongfa PC relay HF33F THT SPDT 10A 12VDC 320Ohm 20,5mmx10,2mmx15,3mm | Customer Part No. Customer Project No. | 460 Pcs. Planned Delivery Time Ø 15 Weeks Available (from stock) | (at least 5 or mul. of 5) | PC relay | Hongfa | SPDT | THT | 12.0 V DC | 10.0 A | 320.0 Ohm | 20.5 mm | 10.2 mm | 15.3 mm | AgNi | -40.0 °C | 85.0 °C | ||||||||
1285 | | Manufacturers Part No. HF33F/024-HSL3F(HF33F-024-HSL3F) Hongfa PC relay HF33F THT SPST-NO 10A 24VDC 2.800Ohm 20,5mmx10,2mmx15,3mm | Customer Part No. Customer Project No. | 260 Pcs. Planned Delivery Time Ø 20 Weeks Available (from stock) | (at least 5 or mul. of 5) | PC relay | Hongfa | SPST-NO | THT | 24.0 V DC | 10.0 A | 2800.0 Ohm | 20.5 mm | 10.2 mm | 15.3 mm | AgNi | -40.0 °C | 85.0 °C | ||||||||
1286 | | Manufacturers Part No. 32.21.7.012.4000(F3221-12U) Finder PC relay 32.21 THT SPDT 6A 12VDC 720Ohm 20mmx10mmx10,7mm RTII | Customer Part No. Customer Project No. | 110 Pcs. Planned Delivery Time Ø 2 Weeks Available (from stock) | (at least 10 or mul. of 10) | PC relay | Finder | SPDT | THT | 12.0 V DC | 6.0 A | 720.0 Ohm | 20.0 mm | 10.0 mm | 10.7 mm | AgSnO2 | RTII | -40.0 °C | 85.0 °C | |||||||
1287 | | Manufacturers Part No. AZ940-1AB-24DS(AZ940-1AB-24DS) Zettler PC relay AZ940 THT SPST-NO 10A 24VDC 2.800Ohm 20,5mmx10,2mmx15,7mm | Customer Part No. Customer Project No. | 730 Pcs. Planned Delivery Time Ø 23 Weeks Available (from stock) | (at least 10 or mul. of 10) | PC relay | Zettler | SPST-NO | THT | 24.0 V DC | 10.0 A | 2800.0 Ohm | 20.5 mm | 10.2 mm | 15.7 mm | AgNi | -40.0 °C | 85.0 °C | ||||||||
1288 | | Manufacturers Part No. FTR-F3AA012V(FTR-F3AA012V) FCL Components PC relay FTR-F3 THT SPST-NO 5A 12VDC 515Ohm 20,5mmx7,2mmx15,3mm RTIII | Customer Part No. Customer Project No. | 0 Pcs. Available (from stock) | (at least 10 or mul. of 10) | PC relay | FCL Components | SPST-NO | THT | 12.0 V DC | 5.0 A | 515.0 Ohm | 20.5 mm | 7.2 mm | 15.3 mm | AgSnO2/Au | RTIII | -40.0 °C | 85.0 °C | |||||||
1289 | | Manufacturers Part No. HF41F/005-ZST(HF41F-005-ZST) Hongfa PC relay HF41F THT SPDT 6A 5VDC 147Ohm 28mmx5mmx15mm | Customer Part No. Customer Project No. | 0 Pcs. Available (from stock) | (at least 5 or mul. of 5) | PC relay | Hongfa | SPDT | THT | 5.0 V DC | 6.0 A | 147.0 Ohm | 28.0 mm | 5.0 mm | 15.0 mm | AgSnO2 | -40.0 °C | 85.0 °C | ||||||||
1290 | | Manufacturers Part No. FTR-F3AA024E-HA(FTRF3AA024EHA) FCL Components PC relay FTR-F3 THT SPST-NO 5A 24VDC 2.880Ohm 20,5mmx7,2mmx15,3mm RTIII | Customer Part No. Customer Project No. | 30 Pcs. Available (from stock) | (at least 10 or mul. of 10) | PC relay | FCL Components | SPST-NO | THT | 24.0 V DC | 5.0 A | 2880.0 Ohm | 20.5 mm | 7.2 mm | 15.3 mm | AgNi | RTIII | -40.0 °C | 70.0 °C | |||||||
1291 | | Manufacturers Part No. HF32FA/024-HSL1(HF32FA-024-HSL1) Hongfa PC relay HF32FA THT SPST-NO 5A 24VDC 1.280Ohm 17,6mmx10,1mmx12,3mm | Customer Part No. Customer Project No. | 630 Pcs. Planned Delivery Time Ø 20 Weeks Available (from stock) | (at least 5 or mul. of 5) | PC relay | Hongfa | SPST-NO | THT | 24.0 V DC | 5.0 A | 1280.0 Ohm | 17.6 mm | 10.1 mm | 12.3 mm | AgNi | -40.0 °C | 85.0 °C | ||||||||
1292 | | Manufacturers Part No. AZ943-1AH-12D(AZ943-1AH-12D) Zettler PC relay AZ943 THT SPST-NO 10A 12VDC 400Ohm 19mmx15,3mmx15,7mm | Customer Part No. Customer Project No. | 0 Pcs. Available (from stock) | (at least 10 or mul. of 10) | PC relay | Zettler | SPST-NO | THT | 12.0 V DC | 10.0 A | 400.0 Ohm | 19.0 mm | 15.3 mm | 15.7 mm | AgSnO2 | -40.0 °C | 70.0 °C | ||||||||
1293 | | Manufacturers Part No. AZ943-1CH-12D(AZ943-1CH-12D) Zettler PC relay AZ943 THT SPDT 10A 12VDC 400Ohm 19mmx15,3mmx15,7mm | Customer Part No. Customer Project No. | 1.910 Pcs. Planned Delivery Time Ø 21 Weeks Available (from stock) | (at least 10 or mul. of 10) | PC relay | Zettler | SPDT | THT | 12.0 V DC | 10.0 A | 400.0 Ohm | 19.0 mm | 15.3 mm | 15.7 mm | AgSnO2 | -40.0 °C | 70.0 °C | ||||||||
1294 | | Manufacturers Part No. AZ943-1CH-24DEGW(AZ943-1CH-24DEGW) Zettler PC relay AZ943 THT SPDT 10A 24VDC 1.600Ohm 19mmx15,3mmx15,7mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 23 Weeks Available on order | (at least 5000 or mul. of 1000) | PC relay | Zettler | SPDT | THT | 24.0 V DC | 10.0 A | 1600.0 Ohm | 19.0 mm | 15.3 mm | 15.7 mm | AgSnO2 | -40.0 °C | 70.0 °C | ||||||||
1295 | | Manufacturers Part No. FTR-MYAA005D(FTR-MYAA005D) FCL Components PC relay FTR-MY THT SPST-NO 5A 5VDC 230Ohm 20mmx5mmx12mm RTIII | Customer Part No. Customer Project No. | 330 Pcs. Planned Delivery Time Ø 26 Weeks Available (from stock) | (at least 10 or mul. of 10) | PC relay | FCL Components | SPST-NO | THT | 5.0 V DC | 5.0 A | 230.0 Ohm | 20.0 mm | 5.0 mm | 12.0 mm | AgNi/Au | RTIII | -40.0 °C | 90.0 °C | |||||||
1296 | | Manufacturers Part No. 1-1393219-0(PE140-24) TE Connectivity PC relay PE THT SPDT 5A 24VDC 2.725Ohm 20mmx10mmx10mm RTII TOP | Customer Part No. Customer Project No. | 4.200 Pcs. Available (from stock) | (at least 25 or mul. of 25) | PC relay | TE Connectivity | SPDT | THT | 24.0 V DC | 5.0 A | 2725.0 Ohm | 20.0 mm | 10.0 mm | 10.0 mm | AgNi | RTII | -40.0 °C | 85.0 °C | |||||||
1297 | | Manufacturers Part No. GQ-SS-105LM1F(GQ-SS-105LM1F) GoodSky PC relay GQ THT SPST-NO 12A 5VDC 125Ohm 18,2mmx10mmx14,9mm RTII | Customer Part No. Customer Project No. | 820 Pcs. Planned Delivery Time Ø 16 Weeks Available (from stock) | (at least 5 or mul. of 5) | PC relay | GoodSky | SPST-NO | THT | 5.0 V DC | 12.0 A | 125.0 Ohm | 18.2 mm | 10.0 mm | 14.9 mm | Ag alloy | RTII | -40.0 °C | 105.0 °C | |||||||
1298 | | Manufacturers Part No. 2-1415030-1(PB134012) TE Connectivity PC relay PB THT SPST-NO 10A 12VDC 400Ohm 15mmx15mmx20mm RTII | Customer Part No. Customer Project No. | 70 Pcs. Planned Delivery Time Ø 7 Weeks Available (from stock) | (at least 35 or mul. of 35) | PC relay | TE Connectivity | SPST-NO | THT | 12.0 V DC | 10.0 A | 400.0 Ohm | 15.0 mm | 15.0 mm | 20.0 mm | AgNi | RTII | -40.0 °C | 85.0 °C | |||||||
1299 | | Manufacturers Part No. RM40-3021-85-1012(RM40-3021-85-1012) RELPOL PC relay RM40 THT SPST-NO 8A 12VDC 720Ohm 20mmx10mmx10,5mm RTIII | Customer Part No. Customer Project No. | 200 Pcs. Planned Delivery Time Ø 25 Weeks Available (from stock) | (at least 10 or mul. of 10) | PC relay | RELPOL | SPST-NO | THT | 12.0 V DC | 8.0 A | 720.0 Ohm | 20.0 mm | 10.0 mm | 10.5 mm | AgSnO2 | IP67 | RTIII | -40.0 °C | 85.0 °C | ||||||
1300 | | Customer Part No. Customer Project No. | 760 Pcs. Planned Delivery Time Ø 5 Weeks Available (from stock) | (at least 10 or mul. of 10) | DIN rail socket | RELPOL | DIN rail | 300.0 V AC | 75.3 mm | 15.5 mm | 61.0 mm | -40.0 °C | 70.0 °C |
