Relays

(1629 Results)

Filtering by Categories

Industrial- / Interfacerelays (107)

Automotive Relays (35)

PCB Relays (976)

Reed Relays (87)

Safety Relays (11)

Heating Control Relays and Timers (4)

Timer (12)

Solid State Relays (332)

Relays Accesories (65)

Filter results

Show Selected	Part No.	Indiv. Part No.	Manufacturer	Availability	Quantity	Series	Type	Manufacturer	contacts	Assembly Type	Coil: Nominal Voltage AC	Coil: Nominal Voltage DC	Contact: Switching Current (min/typ/max)	Coil resistance	Dimension: Length	Dimension: Width	Dimension: Height	Contact material	Protection class RT	Operating Temperature Min.	Operating Temperature Max.
1026	Manufacturers Part No. AZSR131-1AE-24DGW (AZSR131-1AE-24DGW) Zettler PC relay AZSR131 THT SPST-NO 35A 24VDC 410Ohm 30,4mmx15,9mmx25,15mm RTII	Customer Part No. Customer Project No.	Zettler	630 Pcs. Planned Delivery Time Ø 21 Weeks Available (from stock)	(at least 10 or mul. of 10)	AZSR131	PC relay	Zettler	SPST-NO	THT		24.0 V DC	35.0 A	410.0 Ohm	30.4 mm	15.9 mm	25.15 mm	AgSnO2	RTII	-40.0 °C	85.0 °C
1027	Manufacturers Part No. AZEV140-1AE1BG-5D (AZEV140-1AE1BG-5D) Zettler PC relay AZEV140 THT SPST-NO/SPST-NC 50A 5VDC 11,8Ohm 35mmx16mmx28mm RTII	Customer Part No. Customer Project No.	Zettler	0 Pcs. Planned Delivery Time Ø 27 Weeks Available on order	(at least 400 or mul. of 50)	AZEV140	PC relay	Zettler	SPST-NO/SPST-NC	THT		5.0 V DC	50.0 A	11.8 Ohm	35.0 mm	16.0 mm	28.0 mm	Ag alloy	RTII	-40.0 °C	85.0 °C
1028	Manufacturers Part No. AZEV140-1AE1BG-9D (AZEV140-1AE1BG-9D) Zettler PC relay AZEV140 THT SPST-NO/SPST-NC 50A 9VDC 38,4Ohm 35mmx16mmx28mm RTII	Customer Part No. Customer Project No.	Zettler	0 Pcs. Planned Delivery Time Ø 27 Weeks Available on order	(at least 400 or mul. of 50)	AZEV140	PC relay	Zettler	SPST-NO/SPST-NC	THT		9.0 V DC	50.0 A	38.4 Ohm	35.0 mm	16.0 mm	28.0 mm	Ag alloy	RTII	-40.0 °C	85.0 °C
1029	Manufacturers Part No. AZEV140-1AE1BG-12D (AZEV140-1AE1BG-12D) Zettler PC relay AZEV140 THT SPST-NO/SPST-NC 50A 12VDC 68,5Ohm 35mmx16mmx28mm RTII	Customer Part No. Customer Project No.	Zettler	0 Pcs. Planned Delivery Time Ø 27 Weeks Available (from stock)	(at least 10 or mul. of 10)	AZEV140	PC relay	Zettler	SPST-NO/SPST-NC	THT		12.0 V DC	50.0 A	68.5 Ohm	35.0 mm	16.0 mm	28.0 mm	Ag alloy	RTII	-40.0 °C	85.0 °C
1030	Manufacturers Part No. AZEV140-1AE1BG-24D (AZEV140-1AE1BG-24D) Zettler PC relay AZEV140 THT SPST-NO/SPST-NC 50A 24VDC 274Ohm 35mmx16mmx28mm RTII	Customer Part No. Customer Project No.	Zettler	420 Pcs. Planned Delivery Time Ø 27 Weeks Available (from stock)	(at least 10 or mul. of 10)	AZEV140	PC relay	Zettler	SPST-NO/SPST-NC	THT		24.0 V DC	50.0 A	274.0 Ohm	35.0 mm	16.0 mm	28.0 mm	Ag alloy	RTII	-40.0 °C	85.0 °C
1031	Manufacturers Part No. AZEV140-1AE1BG-48D (AZEV140-1AE1BG-48D) Zettler PC relay AZEV140 THT SPST-NO/SPST-NC 50A 48VDC 1.096Ohm 35mmx16mmx28mm RTII	Customer Part No. Customer Project No.	Zettler	0 Pcs. Planned Delivery Time Ø 27 Weeks Available on order	(at least 400 or mul. of 50)	AZEV140	PC relay	Zettler	SPST-NO/SPST-NC	THT		48.0 V DC	50.0 A	1096.0 Ohm	35.0 mm	16.0 mm	28.0 mm	Ag alloy	RTII	-40.0 °C	85.0 °C
1032	Manufacturers Part No. AZ2800-2AE-240A5 (AZ2800-2AE-240A5) Zettler PC relay AZ2800 THT DPST-NO 40A 240VAC 4.500Ohm 59,7mmx34,5mmx26,4mm	Customer Part No. Customer Project No.	Zettler	0 Pcs. Next Stock Receipt Week 32/2026 (290 Pcs.) Available (from stock)	(at least 10 or mul. of 10)	AZ2800	PC relay	Zettler	DPST-NO	THT	240.0 V AC		40.0 A	4500.0 Ohm	59.7 mm	34.5 mm	26.4 mm	AgSnO2		-40.0 °C	65.0 °C
1033	Manufacturers Part No. AZ2800-2CE-240A5 (AZ2800-2CE-240A5) Zettler PC relay AZ2800 Flange mounting DPDT 40A 240VAC 4.500Ohm 59,7mmx34,5mmx26,4mm	Customer Part No. Customer Project No.	Zettler	400 Pcs. Planned Delivery Time Ø 20 Weeks Available (from stock)	(at least 10 or mul. of 10)	AZ2800	PC relay	Zettler	DPDT	Flange mounting	240.0 V AC		40.0 A	4500.0 Ohm	59.7 mm	34.5 mm	26.4 mm	AgSnO2		-40.0 °C	65.0 °C
1034	Manufacturers Part No. AZ2850-2AE-12D (AZ2850-2AE-12D) Zettler PC relay AZ2850 THT DPST-NO 40A 12VDC 86Ohm 52,6mmx34,8mmx26,4mm	Customer Part No. Customer Project No.	Zettler	0 Pcs. Planned Delivery Time Ø 20 Weeks Available on order	(at least 1000 or mul. of 1000)	AZ2850	PC relay	Zettler	DPST-NO	THT		12.0 V DC	40.0 A	86.0 Ohm	52.6 mm	34.8 mm	26.4 mm	AgSnO2		-40.0 °C	85.0 °C
1035	Manufacturers Part No. AZ2850-2AE-24D (AZ2850-2AE-24D) Zettler PC relay AZ2850 THT DPST-NO 40A 24VDC 350Ohm 52,6mmx34,8mmx26,4mm	Customer Part No. Customer Project No.	Zettler	0 Pcs. Planned Delivery Time Ø 20 Weeks Available on order	(at least 1000 or mul. of 1000)	AZ2850	PC relay	Zettler	DPST-NO	THT		24.0 V DC	40.0 A	350.0 Ohm	52.6 mm	34.8 mm	26.4 mm	AgSnO2		-40.0 °C	85.0 °C
1036	Manufacturers Part No. AZ2850-2CE-12DE (AZ2850-2CE-12DE) Zettler PC relay AZ2850 THT DPDT 40A 12VDC 86Ohm 52,6mmx34,8mmx26,4mm	Customer Part No. Customer Project No.	Zettler	0 Pcs. Planned Delivery Time Ø 20 Weeks Available on order	(at least 1000 or mul. of 1000)	AZ2850	PC relay	Zettler	DPDT	THT		12.0 V DC	40.0 A	86.0 Ohm	52.6 mm	34.8 mm	26.4 mm	AgSnO2		-40.0 °C	85.0 °C
1037	Manufacturers Part No. AZ2850-2CE-24DE (AZ2850-2CE-24DE) Zettler PC relay AZ2850 THT DPDT 40A 24VDC 350Ohm 52,6mmx34,8mmx26,4mm	Customer Part No. Customer Project No.	Zettler	0 Pcs. Planned Delivery Time Ø 20 Weeks Available on order	(at least 1000 or mul. of 1000)	AZ2850	PC relay	Zettler	DPDT	THT		24.0 V DC	40.0 A	350.0 Ohm	52.6 mm	34.8 mm	26.4 mm	AgSnO2		-40.0 °C	85.0 °C
1038	Manufacturers Part No. NF120-001E12S (NF120-001E12S) NF PC relay NF120 THT SPDT 40A 12VDC 90Ohm 26,8mmx21,5mmx22,3mm	Customer Part No. Customer Project No.	NF	0 Pcs. Planned Delivery Time Ø 25 Weeks Available (from stock)	(at least 10 or mul. of 10)	NF120	PC relay	NF	SPDT	THT		12.0 V DC	40.0 A	90.0 Ohm	26.8 mm	21.5 mm	22.3 mm	Ag alloy		-40.0 °C	125.0 °C
1039	Manufacturers Part No. NF120-001E24S (NF120-001E24S) NF PC relay NF120 THT SPDT 40A 24VDC 360Ohm 26,8mmx21,5mmx22,3mm	Customer Part No. Customer Project No.	NF	200 Pcs. Planned Delivery Time Ø 25 Weeks Available (from stock)	(at least 10 or mul. of 10)	NF120	PC relay	NF	SPDT	THT		24.0 V DC	40.0 A	360.0 Ohm	26.8 mm	21.5 mm	22.3 mm	Ag alloy		-40.0 °C	125.0 °C
1040	Manufacturers Part No. AZ21501-1AET-12DF (AZ21501-1AET-12DF) Zettler PC relay AZ21501 THT SPST-NO 50A 12VDC 96Ohm 32,5mmx27,6mmx20,5mm	Customer Part No. Customer Project No.	Zettler	575 Pcs. Planned Delivery Time Ø 26 Weeks Available (from stock)	(at least 5 or mul. of 5)	AZ21501	PC relay	Zettler	SPST-NO	THT		12.0 V DC	50.0 A	96.0 Ohm	32.5 mm	27.6 mm	20.5 mm	AgSnO2		-55.0 °C	85.0 °C
1041	Manufacturers Part No. AZ21501-1AET-24DF (AZ21501-1AET-24DF) Zettler PC relay AZ21501 THT SPST-NO 50A 24VDC 384Ohm 32,5mmx27,6mmx20,5mm	Customer Part No. Customer Project No.	Zettler	770 Pcs. Planned Delivery Time Ø 26 Weeks Available (from stock)	(at least 5 or mul. of 5)	AZ21501	PC relay	Zettler	SPST-NO	THT		24.0 V DC	50.0 A	384.0 Ohm	32.5 mm	27.6 mm	20.5 mm	AgSnO2		-55.0 °C	85.0 °C
1042	Manufacturers Part No. AZ21501-1CET-12DF (AZ21501-1CET-12DF) Zettler PC relay AZ21501 THT SPDT 50A 12VDC 96Ohm 32,5mmx27,6mmx20,5mm	Customer Part No. Customer Project No.	Zettler	953 Pcs. Planned Delivery Time Ø 26 Weeks Available (from stock)	(at least 5 or mul. of 5)	AZ21501	PC relay	Zettler	SPDT	THT		12.0 V DC	50.0 A	96.0 Ohm	32.5 mm	27.6 mm	20.5 mm	AgSnO2		-55.0 °C	85.0 °C
1043	Manufacturers Part No. AZ21501-1CET-24DF (AZ21501-1CET-24DF) Zettler PC relay AZ21501 THT SPDT 50A 24VDC 384Ohm 32,5mmx27,6mmx20,5mm	Customer Part No. Customer Project No.	Zettler	0 Pcs. Next Stock Receipt Week 37/2026 (900 Pcs.) Available (from stock)	(at least 5 or mul. of 5)	AZ21501	PC relay	Zettler	SPDT	THT		24.0 V DC	50.0 A	384.0 Ohm	32.5 mm	27.6 mm	20.5 mm	AgSnO2		-55.0 °C	85.0 °C
1044	Manufacturers Part No. AZ2501P2-1A-12DE (AZ2501P2-1A-12DE) Zettler PC relay AZ2501P THT SPST-NO 50A 12VDC 48Ohm 39,3mmx15,3mmx30,5mm	Customer Part No. Customer Project No.	Zettler	0 Pcs. Planned Delivery Time Ø 26 Weeks Available on order	(at least 800 or mul. of 800)	AZ2501P	PC relay	Zettler	SPST-NO	THT		12.0 V DC	50.0 A	48.0 Ohm	39.3 mm	15.3 mm	30.5 mm	AgSnO2		-40.0 °C	70.0 °C
1045	Manufacturers Part No. AZ2501P2-1A-24DE (AZ2501P2-1A-24DE) Zettler PC relay AZ2501P THT SPST-NO 50A 24VDC 192Ohm 39,3mmx15,3mmx30,5mm	Customer Part No. Customer Project No.	Zettler	0 Pcs. Planned Delivery Time Ø 26 Weeks Available on order	(at least 400 or mul. of 400)	AZ2501P	PC relay	Zettler	SPST-NO	THT		24.0 V DC	50.0 A	192.0 Ohm	39.3 mm	15.3 mm	30.5 mm	AgSnO2		-40.0 °C	70.0 °C
1046	Manufacturers Part No. AZ2501P2-1C-12DE (AZ2501P2-1C-12DE) Zettler PC relay AZ2501P THT SPDT 50A 12VDC 48Ohm 39,3mmx15,3mmx30,5mm	Customer Part No. Customer Project No.	Zettler	0 Pcs. Planned Delivery Time Ø 26 Weeks Available on order	(at least 400 or mul. of 400)	AZ2501P	PC relay	Zettler	SPDT	THT		12.0 V DC	50.0 A	48.0 Ohm	39.3 mm	15.3 mm	30.5 mm	AgSnO2		-40.0 °C	70.0 °C
1047	Manufacturers Part No. AZ2501P2-1C-24DE (AZ2501P2-1C-24DE) Zettler PC relay AZ2501P THT SPDT 50A 24VDC 192Ohm 39,3mmx15,3mmx30,5mm	Customer Part No. Customer Project No.	Zettler	0 Pcs. Planned Delivery Time Ø 26 Weeks Available on order	(at least 800 or mul. of 800)	AZ2501P	PC relay	Zettler	SPDT	THT		24.0 V DC	50.0 A	192.0 Ohm	39.3 mm	15.3 mm	30.5 mm	AgSnO2		-40.0 °C	70.0 °C
1048	Manufacturers Part No. G9KB-1A-12VDC (G9KB-1A-12VDC) Omron PC relay G9KB THT SPST-NO 50A 12VDC 51Ohm 50mmx36,7mmx50mm RTII	Customer Part No. Customer Project No.	Omron	4 Pcs. Planned Delivery Time Ø 21 Weeks Available (from stock)	(at least 1 or mul. of 1)	G9KB	PC relay	Omron	SPST-NO	THT		12.0 V DC	50.0 A	51.0 Ohm	50.0 mm	36.7 mm	50.0 mm	Ag alloy	RTII	-40.0 °C	85.0 °C
1049	Manufacturers Part No. G9KB-1A-24VDC (G9KB-1A-24VDC) Omron PC relay G9KB THT SPST-NO 50A 24VDC 206Ohm 50mmx36,7mmx50mm RTII	Customer Part No. Customer Project No.	Omron	5 Pcs. Planned Delivery Time Ø 21 Weeks Available (from stock)	(at least 1 or mul. of 1)	G9KB	PC relay	Omron	SPST-NO	THT		24.0 V DC	50.0 A	206.0 Ohm	50.0 mm	36.7 mm	50.0 mm	Ag alloy	RTII	-40.0 °C	85.0 °C
1050	Manufacturers Part No. AZSR165-1A-12DL (AZSR165-1A-12DL) Zettler PC relay AZSR165 THT SPST-NO 80A 12VDC 65Ohm 38mmx33mmx41,5mm RTII	Customer Part No. Customer Project No.	Zettler	156 Pcs. Planned Delivery Time Ø 22 Weeks Available (from stock)	(at least 10 or mul. of 10)	AZSR165	PC relay	Zettler	SPST-NO	THT		12.0 V DC	80.0 A	65.0 Ohm	38.0 mm	33.0 mm	41.5 mm	AgNi	RTII	-40.0 °C	85.0 °C

‹ 1 ··· 40 41 42 43 44 ··· 66 ›
