Results (1741)
RoHS compliant
Datasheet
New
In stock
Sale
Not discontinued
| Show Selected | Image | Part No. | Indiv. Part No. | Manufacturer | Price | Availability | Quantity | Series | Data Sheet | RoHS | Type | Manufacturer | contacts | Assembly Type | Coil: Nominal Voltage AC | Coil: Nominal Voltage DC | Contact: Switching Current (min/typ/max) | Coil resistance | Dimension: Length | Dimension: Width | Dimension: Height | Contact material | Protection Class | Protection class RT | Operating Temperature Min. | Operating Temperature Max. |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
801 |  | Manufacturers Part No. 9-1393222-1(V23061B1005A301) TE Connectivity PC relay MSR V23061 THT SPDT 8A 12VDC 652Ohm 30mmx10mmx15mm RTIII | Customer Part No. Customer Project No. | 1.000 Pcs. Available (from stock) | (at least 20 or mul. of 20) | PC relay | TE Connectivity | SPDT | THT | 12.0 V DC | 8.0 A | 652.0 Ohm | 30.0 mm | 10.0 mm | 15.0 mm | AgSnO2 | RTIII | -40.0 °C | 85.0 °C | |||||||
802 | | Manufacturers Part No. 1-1393223-7(V23061B1007A301) TE Connectivity PC relay MSR V23061 THT SPDT 8A 24VDC 2.270Ohm 30mmx10mmx15mm RTIII | Customer Part No. Customer Project No. | 240 Pcs. Planned Delivery Time Ø 22 Weeks Available (from stock) | (at least 20 or mul. of 20) | PC relay | TE Connectivity | SPDT | THT | 24.0 V DC | 8.0 A | 2270.0 Ohm | 30.0 mm | 10.0 mm | 15.0 mm | AgSnO2 | RTIII | -40.0 °C | 85.0 °C | |||||||
803 | | Manufacturers Part No. FTR-F1CL005R(FTRF1CL005R) FCL Components PC relay FTR-F1 R THT DPDT 8A 5VDC 62Ohm 29mmx12,8mmx16,5mm RTII | Customer Part No. Customer Project No. | 2.920 Pcs. Planned Delivery Time Ø 28 Weeks Available (from stock) | (at least 10 or mul. of 10) | PC relay | FCL Components | DPDT | THT | 5.0 V DC | 8.0 A | 62.0 Ohm | 29.0 mm | 12.8 mm | 16.5 mm | AgSnO2/Au | RTII | -40.0 °C | 75.0 °C | |||||||
804 | | Manufacturers Part No. FTR-F1CL012R(FTRF1CL012R) FCL Components PC relay FTR-F1 R THT DPDT 8A 12VDC 360Ohm 29mmx12,8mmx16,5mm RTII | Customer Part No. Customer Project No. | 1.870 Pcs. Available (from stock) | (at least 10 or mul. of 10) | PC relay | FCL Components | DPDT | THT | 12.0 V DC | 8.0 A | 360.0 Ohm | 29.0 mm | 12.8 mm | 16.5 mm | AgSnO2/Au | RTII | -40.0 °C | 75.0 °C | |||||||
805 | | Manufacturers Part No. FTR-F1CL024R(FTRF1CL024R) FCL Components PC relay FTR-F1 R THT DPDT 8A 24VDC 1.440Ohm 29mmx12,8mmx16,5mm RTII TOP | Customer Part No. Customer Project No. | 1.110 Pcs. Available (from stock) | (at least 10 or mul. of 10) | PC relay | FCL Components | DPDT | THT | 24.0 V DC | 8.0 A | 1440.0 Ohm | 29.0 mm | 12.8 mm | 16.5 mm | AgSnO2/Au | RTII | -40.0 °C | 75.0 °C | |||||||
806 | | Manufacturers Part No. AZ9405-1A-12DSEF(AZ9405-1A-12DSEF) Zettler PC relay AZ9405 THT SPST-NO 10A 12VDC 72Ohm 20mmx10mmx15,2mm | Customer Part No. Customer Project No. | 1.460 Pcs. Planned Delivery Time Ø 25 Weeks Available (from stock) | (at least 10 or mul. of 10) | PC relay | Zettler | SPST-NO | THT | 12.0 V DC | 10.0 A | 72.0 Ohm | 20.0 mm | 10.0 mm | 15.2 mm | AgSnO2 | -40.0 °C | 85.0 °C | ||||||||
807 | | Manufacturers Part No. AZ9405-1C-24DSEF(AZ9405-1C-24DSEF) Zettler PC relay AZ9405 THT SPDT 10A 24VDC 2.800Ohm 20mmx10mmx15,2mm | Customer Part No. Customer Project No. | 4.390 Pcs. Planned Delivery Time Ø 25 Weeks Available (from stock) | (at least 10 or mul. of 10) | PC relay | Zettler | SPDT | THT | 24.0 V DC | 10.0 A | 2800.0 Ohm | 20.0 mm | 10.0 mm | 15.2 mm | AgSnO2 | -40.0 °C | 85.0 °C | ||||||||
808 | | Manufacturers Part No. EMR-112D-3-1(EMR-112D-3) GoodSky PC relay EMR THT SPDT 8A 12VDC 650Ohm 30mmx10mmx15mm | Customer Part No. Customer Project No. | 650 Pcs. Planned Delivery Time Ø 18 Weeks Available (from stock) | (at least 10 or mul. of 10) | PC relay | GoodSky | SPDT | THT | 12.0 V DC | 8.0 A | 650.0 Ohm | 30.0 mm | 10.0 mm | 15.0 mm | Ag alloy | -40.0 °C | 85.0 °C | ||||||||
809 | | Manufacturers Part No. G6RL-14ASI DC12(G6RL14ASIDC12) Omron PC relay G6RL THT SPDT 10A 12VDC 654Ohm 28,5mmx10mmx12,3mm RTII | Customer Part No. Customer Project No. | 300 Pcs. Planned Delivery Time Ø 30 Weeks Available (from stock) | (at least 20 or mul. of 20) | PC relay | Omron | SPDT | THT | 12.0 V DC | 10.0 A | 654.0 Ohm | 28.5 mm | 10.0 mm | 12.3 mm | Ag alloy | RTII | -40.0 °C | 85.0 °C | |||||||
810 | | Manufacturers Part No. G6RL-14ASI DC5(G6RL14ASIDC5) Omron PC relay G6RL THT SPDT 10A 5VDC 113Ohm 28,5mmx10mmx12,3mm RTII | Customer Part No. Customer Project No. | 0 Pcs. Available (from stock) | (at least 20 or mul. of 20) | PC relay | Omron | SPDT | THT | 5.0 V DC | 10.0 A | 113.0 Ohm | 28.5 mm | 10.0 mm | 12.3 mm | Ag alloy | RTII | -40.0 °C | 85.0 °C | |||||||
811 | | Manufacturers Part No. G6RN-1 DC12(G6RN1-12) Omron PC relay G6RN THT SPDT 8A 12VDC 655Ohm 28,5mmx10mmx15mm TOP | Customer Part No. Customer Project No. | 4.780 Pcs. Available (from stock) | (at least 20 or mul. of 20) | PC relay | Omron | SPDT | THT | 12.0 V DC | 8.0 A | 655.0 Ohm | 28.5 mm | 10.0 mm | 15.0 mm | Ag alloy/Au | -40.0 °C | 85.0 °C | ||||||||
812 | | Manufacturers Part No. AZ742-2A-24DE(AZ742-2A-24DE) Zettler PC relay AZ742 THT DPST-NO 10A 24VDC 1.440Ohm 29mmx12,7mmx15,7mm | Customer Part No. Customer Project No. | 1.100 Pcs. Planned Delivery Time Ø 10 Weeks Available (from stock) | (at least 10 or mul. of 10) | PC relay | Zettler | DPST-NO | THT | 24.0 V DC | 10.0 A | 1440.0 Ohm | 29.0 mm | 12.7 mm | 15.7 mm | AgNi | -40.0 °C | 85.0 °C | ||||||||
813 | | Manufacturers Part No. AZ742-2CG-12DE(AZ742-2CG-12DE) Zettler PC relay AZ742 THT DPDT 10A 12VDC 360Ohm 29mmx12,7mmx15,7mm | Customer Part No. Customer Project No. | 0 Pcs. Available (from stock) | (at least 10 or mul. of 10) | PC relay | Zettler | DPDT | THT | 12.0 V DC | 10.0 A | 360.0 Ohm | 29.0 mm | 12.7 mm | 15.7 mm | AgNi/Au | -40.0 °C | 85.0 °C | ||||||||
814 | | Manufacturers Part No. 43.41.7.012.4000(F4341-12S) Finder PC relay 43.41 THT SPDT 10A 12VDC 580Ohm 30,2mmx10,2mmx15,4mm RTII | Customer Part No. Customer Project No. | 60 Pcs. Planned Delivery Time Ø 9 Weeks Available (from stock) | (at least 10 or mul. of 10) | PC relay | Finder | SPDT | THT | 12.0 V DC | 10.0 A | 580.0 Ohm | 30.2 mm | 10.2 mm | 15.4 mm | AgSnO2 | RTII | -40.0 °C | 85.0 °C | |||||||
815 | | Manufacturers Part No. AZ696-1CE-12DE(AZ696-1CE-12DE) Zettler PC relay AZ969 THT SPDT 10A 12VDC 660Ohm 30mmx10mmx16,2mm | Customer Part No. Customer Project No. | 551 Pcs. Planned Delivery Time Ø 11 Weeks Available (from stock) | (at least 19 or mul. of 19) | PC relay | Zettler | SPDT | THT | 12.0 V DC | 10.0 A | 660.0 Ohm | 30.0 mm | 10.0 mm | 16.2 mm | AgSnO2 | -40.0 °C | 85.0 °C | ||||||||
816 | | Manufacturers Part No. JS-24N-K(JS24NK) FCL Components PC relay JS THT SPDT 8A 24VDC 2.350Ohm 29mmx10mmx12,5mm TOP | Customer Part No. Customer Project No. | 2.080 Pcs. Available (from stock) | (at least 10 or mul. of 10) | PC relay | FCL Components | SPDT | THT | 24.0 V DC | 8.0 A | 2350.0 Ohm | 29.0 mm | 10.0 mm | 12.5 mm | AgSnO2/Au | -40.0 °C | 85.0 °C | ||||||||
817 | | Manufacturers Part No. APF30205(APF30205) Panasonic PC relay APF THT SPDT 6A 5VDC 147Ohm 28mmx5mmx15mm | Customer Part No. Customer Project No. | 100 Pcs. Planned Delivery Time Ø 10 Weeks Available (from stock) | (at least 10 or mul. of 10) | PC relay | Panasonic | SPDT | THT | 5.0 V DC | 6.0 A | 147.0 Ohm | 28.0 mm | 5.0 mm | 15.0 mm | AgNi/Au | -40.0 °C | 85.0 °C | ||||||||
818 | | Manufacturers Part No. DK1A-12V-F(DK1A-12V-F) Panasonic PC relay DK THT SPST-NO 10A 12VDC 720Ohm 20mmx12,5mmx10mm RTIII | Customer Part No. Customer Project No. | 20 Pcs. Planned Delivery Time Ø 10 Weeks Available (from stock) | (at least 5 or mul. of 5) | PC relay | Panasonic | SPST-NO | THT | 12.0 V DC | 10.0 A | 720.0 Ohm | 20.0 mm | 12.5 mm | 10.0 mm | AgSnO2/Au | RTIII | -40.0 °C | 65.0 °C | |||||||
819 | | Manufacturers Part No. APF30224(APF30224) Panasonic PC relay APF THT SPDT 6A 24VDC 3.388Ohm 28mmx5mmx15mm | Customer Part No. Customer Project No. | 1.840 Pcs. Planned Delivery Time Ø 10 Weeks Available (from stock) | (at least 10 or mul. of 10) | PC relay | Panasonic | SPDT | THT | 24.0 V DC | 6.0 A | 3388.0 Ohm | 28.0 mm | 5.0 mm | 15.0 mm | AgNi/Au | -40.0 °C | 85.0 °C | ||||||||
820 | | Manufacturers Part No. RM96-3011-35-1012(RM96-3011-35-1012) RELPOL PC relay RM96 THT SPST 8A 12VDC 600Ohm 30mmx10mmx16,2mm RTII | Customer Part No. Customer Project No. | 117 Pcs. Planned Delivery Time Ø 8 Weeks Available (from stock) | (at least 19 or mul. of 19) | PC relay | RELPOL | SPST | THT | 12.0 V DC | 8.0 A | 600.0 Ohm | 30.0 mm | 10.0 mm | 16.2 mm | AgSnO2 | IP67 | RTII | -40.0 °C | 80.0 °C | ||||||
821 | | Manufacturers Part No. S7001C24W(S7001C24W) NF PC relay S7 THT SPDT 10A 24VDC 2.350Ohm 28,5mmx10,1mmx12,5mm RTIII | Customer Part No. Customer Project No. | 1.840 Pcs. Planned Delivery Time Ø 25 Weeks Available (from stock) | (at least 10 or mul. of 10) | PC relay | NF | SPDT | THT | 24.0 V DC | 10.0 A | 2350.0 Ohm | 28.5 mm | 10.1 mm | 12.5 mm | AgNi/Au | RTIII | -40.0 °C | 85.0 °C | |||||||
822 | | Manufacturers Part No. FTR-F1CA024V(FTRF1CA024V) FCL Components PC relay FTR-F1 THT DPDT 5A 24VDC 1.100Ohm 29mmx12,8mmx16,5mm RTIII | Customer Part No. Customer Project No. | 630 Pcs. Planned Delivery Time Ø 28 Weeks Available (from stock) | (at least 10 or mul. of 10) | PC relay | FCL Components | DPDT | THT | 24.0 V DC | 5.0 A | 1100.0 Ohm | 29.0 mm | 12.8 mm | 16.5 mm | AgSnO2/Au | RTIII | -40.0 °C | 75.0 °C | |||||||
823 | | Manufacturers Part No. 0-1419108-1(RT114-12) TE Connectivity PC relay RT1 THT SPDT 12A 12VDC 360Ohm 29mmx12,7mmx15,7mm RTII TOP | Customer Part No. Customer Project No. | 3.220 Pcs. Available (from stock) | (at least 20 or mul. of 20) | PC relay | TE Connectivity | SPDT | THT | 12.0 V DC | 12.0 A | 360.0 Ohm | 29.0 mm | 12.7 mm | 15.7 mm | AgNi | RTII | -40.0 °C | 85.0 °C | |||||||
824 | | Manufacturers Part No. 9-1393239-8(RT314-24) TE Connectivity PC relay RT1 THT SPDT 16A 24VDC 1.440Ohm 29mmx12,7mmx15,7mm RTII TOP | Customer Part No. Customer Project No. | 1.760 Pcs. Available (from stock) | (at least 20 or mul. of 20) | PC relay | TE Connectivity | SPDT | THT | 24.0 V DC | 16.0 A | 1440.0 Ohm | 29.0 mm | 12.7 mm | 15.7 mm | AgNi | RTII | -40.0 °C | 85.0 °C | |||||||
825 | | Manufacturers Part No. AZ888-1A-5DE(AZ888-1A-5DE) Zettler PC relay AZ888 THT SPST-NO 8A 5VDC 83Ohm 20,2mmx11,3mmx10,5mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 99 Weeks Available on order | (at least 1000 or mul. of 1000) | PC relay | Zettler | SPST-NO | THT | 5.0 V DC | 8.0 A | 83.0 Ohm | 20.2 mm | 11.3 mm | 10.5 mm | AgSnO2 | -40.0 °C | 85.0 °C |
