Results (1773)
RoHS compliant
Datasheet
New
In stock
Sale
Not discontinued
| Show Selected | Image | Part No. | Indiv. Part No. | Manufacturer | Price | Availability | Quantity | Series | Data Sheet | RoHS | Type | Manufacturer | contacts | Assembly Type | Coil: Nominal Voltage AC | Coil: Nominal Voltage DC | Contact: Switching Current (min/typ/max) | Coil resistance | Dimension: Length | Dimension: Width | Dimension: Height | Contact material | Protection Class | Protection class RT | Operating Temperature Min. | Operating Temperature Max. |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
76 |  | Manufacturers Part No. 22.32.0.230.4540(22.32.0.230.4540) Finder Modular contactor 22.32 SPST-NO/SPST-NC 25A 230VAC 230VDC 88,8mmx17,5mmx60,8mm IP20 | Customer Part No. Customer Project No. | 10 Pcs. Planned Delivery Time Ø 2 Weeks Available (from stock) | (at least 1 or mul. of 1) | Modular contactor | Finder | SPST-NO/SPST-NC | DIN rail | 230.0 V AC | 230.0 V DC | 25.0 A | 88.8 mm | 17.5 mm | 60.8 mm | AgSnO2 | IP20 | -25.0 °C | 50.0 °C | |||||||
77 | | Manufacturers Part No. 22.64.0.024.4310(22.64.0.024.4310) Finder Modular contactor 22.64 4PDT 63A 24VAC 24VDC 95,8mmx53,5mmx63,1mm IP20 | Customer Part No. Customer Project No. | 2 Pcs. Planned Delivery Time Ø 2 Weeks Available (from stock) | (at least 1 or mul. of 1) | Modular contactor | Finder | 4PDT | DIN rail | 24.0 V AC | 24.0 V DC | 63.0 A | 95.8 mm | 53.5 mm | 63.1 mm | AgSnO2 | IP20 | -15.0 °C | 55.0 °C | |||||||
78 | | Manufacturers Part No. 22.64.0.024.4710(22.64.0.024.4710) Finder Modular contactor 22.64 3PDT-NO/SPDT-NC 63A 24VAC 24VDC 95,8mmx53,5mmx63,1mm IP20 | Customer Part No. Customer Project No. | 1 Pcs. Planned Delivery Time Ø 2 Weeks Available (from stock) | (at least 1 or mul. of 1) | Modular contactor | Finder | 3PDT-NO/SPDT-NC | DIN rail | 24.0 V AC | 24.0 V DC | 63.0 A | 95.8 mm | 53.5 mm | 63.1 mm | AgSnO2 | IP20 | -25.0 °C | 55.0 °C | |||||||
79 | | Manufacturers Part No. 22.64.0.230.4310(22.64.0.230.4310) Finder Modular contactor 22.64 4PDT 63A 230VAC 220VDC 95,8mmx53,5mmx63,1mm IP20 | Customer Part No. Customer Project No. | 2 Pcs. Planned Delivery Time Ø 2 Weeks Available (from stock) | (at least 1 or mul. of 1) | Modular contactor | Finder | 4PDT | DIN rail | 230.0 V AC | 220.0 V DC | 63.0 A | 95.8 mm | 53.5 mm | 63.1 mm | AgSnO2 | IP20 | -15.0 °C | 55.0 °C | |||||||
80 | | Manufacturers Part No. 22.64.0.230.4710(22.64.0.230.4710) Finder Modular contactor 22.64 3PDT-NO/SPDT-NC 63A 230VAC 220VDC 95,8mmx53,5mmx63,1mm IP20 | Customer Part No. Customer Project No. | 13 Pcs. Planned Delivery Time Ø 2 Weeks Available (from stock) | (at least 1 or mul. of 1) | Modular contactor | Finder | 3PDT-NO/SPDT-NC | DIN rail | 230.0 V AC | 220.0 V DC | 63.0 A | 95.8 mm | 53.5 mm | 63.1 mm | AgSnO2 | IP20 | -25.0 °C | 55.0 °C | |||||||
81 | | Manufacturers Part No. 13.31.8.012.4300(13.31.8.012.4300) Finder Impulse relay 13.31 SPST-NO 12A 12VAC 37mmx22,7mmx39mm IP20 | Customer Part No. Customer Project No. | 2 Pcs. Planned Delivery Time Ø 2 Weeks Available (from stock) | (at least 1 or mul. of 1) | Impulse relay | Finder | SPST-NO | Switch box | 12.0 V AC | 12.0 A | 37.0 mm | 22.7 mm | 39.0 mm | AgSnO2 | IP20 | -10.0 °C | 60.0 °C | ||||||||
82 | | Manufacturers Part No. 13.31.8.230.4300(13.31.8.230.4300) Finder Impulse relay 13.31 SPST-NO 12A 230VAC 37mmx22,7mmx39mm IP20 | Customer Part No. Customer Project No. | 2 Pcs. Planned Delivery Time Ø 2 Weeks Available (from stock) | (at least 1 or mul. of 1) | Impulse relay | Finder | SPST-NO | Switch box | 230.0 V AC | 12.0 A | 37.0 mm | 22.7 mm | 39.0 mm | AgSnO2 | IP20 | -10.0 °C | 60.0 °C | ||||||||
83 | | Manufacturers Part No. 20.21.8.230.4000(20.21.8.230.4000) Finder Impulse relay 20.21 SPST-NO 16A 230VAC 2.500Ohm 87,5mmx17,5mmx58,4mm IP20 | Customer Part No. Customer Project No. | 8 Pcs. Planned Delivery Time Ø 2 Weeks Available (from stock) | (at least 1 or mul. of 1) | Impulse relay | Finder | SPST-NO | DIN rail | 230.0 V AC | 16.0 A | 2500.0 Ohm | 87.5 mm | 17.5 mm | 58.4 mm | AgSnO2 | IP20 | -40.0 °C | 40.0 °C | |||||||
84 | | Manufacturers Part No. 20.22.8.230.4000(20.22.8.230.4000) Finder Impulse relay 20.22 SPDT-NO 16A 230VAC 2.500Ohm 87,5mmx17,5mmx58,4mm IP20 | Customer Part No. Customer Project No. | 15 Pcs. Planned Delivery Time Ø 2 Weeks Available (from stock) | (at least 1 or mul. of 1) | Impulse relay | Finder | SPDT-NO | DIN rail | 230.0 V AC | 16.0 A | 2500.0 Ohm | 87.5 mm | 17.5 mm | 58.4 mm | AgSnO2 | IP20 | -40.0 °C | 40.0 °C | |||||||
85 | | Manufacturers Part No. 20.22.9.012.4000(20.22.9.012.4000) Finder Impulse relay 20.22 SPDT-NO 16A 12VDC 27Ohm 87,5mmx17,5mmx58,4mm IP20 | Customer Part No. Customer Project No. | 24 Pcs. Planned Delivery Time Ø 2 Weeks Available (from stock) | (at least 1 or mul. of 1) | Impulse relay | Finder | SPDT-NO | DIN rail | 12.0 V DC | 16.0 A | 27.0 Ohm | 87.5 mm | 17.5 mm | 58.4 mm | AgSnO2 | IP20 | -40.0 °C | 40.0 °C | |||||||
86 | | Manufacturers Part No. 20.21.9.012.4000(20.21.9.012.4000) Finder Impulse relay 20.21 SPST-NO 16A 12VDC 27Ohm 87,5mmx17,5mmx58,4mm IP20 | Customer Part No. Customer Project No. | 20 Pcs. Planned Delivery Time Ø 2 Weeks Available (from stock) | (at least 1 or mul. of 1) | Impulse relay | Finder | SPST-NO | DIN rail | 12.0 V DC | 16.0 A | 27.0 Ohm | 87.5 mm | 17.5 mm | 58.4 mm | AgSnO2 | IP20 | -40.0 °C | 40.0 °C | |||||||
87 | | Manufacturers Part No. 20.21.9.024.4000(20.21.9.024.4000) Finder Impulse relay 20.21 SPST-NO 16A 24VDC 105Ohm 87,5mmx17,5mmx58,4mm IP20 | Customer Part No. Customer Project No. | 40 Pcs. Planned Delivery Time Ø 2 Weeks Available (from stock) | (at least 1 or mul. of 1) | Impulse relay | Finder | SPST-NO | DIN rail | 24.0 V DC | 16.0 A | 105.0 Ohm | 87.5 mm | 17.5 mm | 58.4 mm | AgSnO2 | IP20 | -40.0 °C | 40.0 °C | |||||||
88 | | Manufacturers Part No. 20.22.9.024.4000(20.22.9.024.4000) Finder Impulse relay 20.22 SPDT-NO 16A 24VDC 105Ohm 87,5mmx17,5mmx58,4mm IP20 | Customer Part No. Customer Project No. | 31 Pcs. Planned Delivery Time Ø 2 Weeks Available (from stock) | (at least 1 or mul. of 1) | Impulse relay | Finder | SPDT-NO | DIN rail | 24.0 V DC | 16.0 A | 105.0 Ohm | 87.5 mm | 17.5 mm | 58.4 mm | AgSnO2 | IP20 | -40.0 °C | 40.0 °C | |||||||
89 | | Customer Part No. Customer Project No. | 1 Pcs. Planned Delivery Time Ø 2 Weeks Available (from stock) | (at least 1 or mul. of 1) | Electrode holder for level sensor | Finder | Screw Mount | |||||||||||||||||||
90 | | Customer Part No. Customer Project No. | 1 Pcs. Planned Delivery Time Ø 2 Weeks Available (from stock) | (at least 1 or mul. of 1) | Level floor sensor | Finder | Screw Mount | 44.0 mm | 32.0 mm | 26.5 mm | ||||||||||||||||
91 | | Customer Part No. Customer Project No. | 1 Pcs. Planned Delivery Time Ø 2 Weeks Available (from stock) | (at least 1 or mul. of 1) | Level sensor | Finder | Cable mounting | 58.0 mm | 23.0 mm | 23.0 mm | ||||||||||||||||
92 | | Manufacturers Part No. 72.01.8.240.0000(72.01.8.240.0000) Finder Level control relays 72.01 DIN rail SPDT 16A 240VAC | Customer Part No. Customer Project No. | 1 Pcs. Planned Delivery Time Ø 2 Weeks Available (from stock) | (at least 1 or mul. of 1) | Level control relays | Finder | SPDT | DIN rail | 240.0 V AC | 16.0 A | 84.0 mm | 35.0 mm | 54.6 mm | AgNi | IP20 | -20.0 °C | 60.0 °C | ||||||||
93 | | Manufacturers Part No. 72.01.9.024.0000(72.01.9.024.0000) Finder Level control relays 72.01 DIN rail SPDT 16A 24VDC | Customer Part No. Customer Project No. | 1 Pcs. Planned Delivery Time Ø 2 Weeks Available (from stock) | (at least 1 or mul. of 1) | Level control relays | Finder | SPDT | DIN rail | 24.0 V DC | 16.0 A | 84.0 mm | 35.0 mm | 54.6 mm | AgNi | IP20 | -20.0 °C | 60.0 °C | ||||||||
94 | | Manufacturers Part No. AZEV400-4AE-12D(AZEV400-4AE-12D) Zettler PC relay AZEV400 THT 4PST-NO 50A 12VDC 30Ohm 58,6mmx35mmx45,3mm RTII | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 23 Weeks Available on order | (at least 180 or mul. of 180) | PC relay | Zettler | 4PST-NO | THT | 12.0 V DC | 50.0 A | 30.0 Ohm | 58.6 mm | 35.0 mm | 45.3 mm | AgSnO2 | RTII | -40.0 °C | 95.0 °C | |||||||
95 | | Manufacturers Part No. AZEV400-4AE-24D(AZEV400-4AE-24D) Zettler PC relay AZEV400 THT 4PST-NO 50A 24VDC 120Ohm 58,6mmx35mmx45,3mm RTII | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 23 Weeks Available on order | (at least 180 or mul. of 180) | PC relay | Zettler | 4PST-NO | THT | 24.0 V DC | 50.0 A | 120.0 Ohm | 58.6 mm | 35.0 mm | 45.3 mm | AgSnO2 | RTII | -40.0 °C | 95.0 °C | |||||||
96 | | Manufacturers Part No. AZEV400-4AE-6D(AZEV400-4AE-6D) Zettler PC relay AZEV400 THT 4PST-NO 50A 6VDC 7,5Ohm 58,6mmx35mmx45,3mm RTII | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 23 Weeks Available on order | (at least 180 or mul. of 180) | PC relay | Zettler | 4PST-NO | THT | 6.0 V DC | 50.0 A | 7.5 Ohm | 58.6 mm | 35.0 mm | 45.3 mm | AgSnO2 | RTII | -40.0 °C | 95.0 °C | |||||||
97 | | Manufacturers Part No. AZEV400-4AE-9D(AZEV400-4AE-9D) Zettler PC relay AZEV400 THT 4PST-NO 50A 9VDC 16,9Ohm 58,6mmx35mmx45,3mm RTII | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 23 Weeks Available on order | (at least 180 or mul. of 180) | PC relay | Zettler | 4PST-NO | THT | 9.0 V DC | 50.0 A | 16.9 Ohm | 58.6 mm | 35.0 mm | 45.3 mm | AgSnO2 | RTII | -40.0 °C | 95.0 °C | |||||||
98 | | Manufacturers Part No. AZEV400-4AE1BG-24D(AZEV400-4AE1BG-24D) Zettler PC relay AZEV400 THT 4PST-NO/SPST-NC 50A 24VDC 120Ohm 58,6mmx35mmx45,3mm RTII | Customer Part No. Customer Project No. | 30 Pcs. Planned Delivery Time Ø 22 Weeks Available (from stock) | (at least 10 or mul. of 10) | PC relay | Zettler | 4PST-NO/SPST-NC | THT | 24.0 V DC | 50.0 A | 120.0 Ohm | 58.6 mm | 35.0 mm | 45.3 mm | AgSnO2 | RTII | -40.0 °C | 95.0 °C | |||||||
99 | | Manufacturers Part No. AZEV400-4AE1BG-6D(AZEV400-4AE1BG-6D) Zettler PC relay AZEV400 THT 4PST-NO/SPST-NC 50A 6VDC 7,5Ohm 58,6mmx35mmx45,3mm RTII | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 23 Weeks Available on order | (at least 180 or mul. of 180) | PC relay | Zettler | 4PST-NO/SPST-NC | THT | 6.0 V DC | 50.0 A | 7.5 Ohm | 58.6 mm | 35.0 mm | 45.3 mm | AgSnO2 | RTII | -40.0 °C | 95.0 °C | |||||||
100 | | Manufacturers Part No. AZEV400-4AE1BG-9D(AZEV400-4AE1BG-9D) Zettler PC relay AZEV400 THT 4PST-NO/SPST-NC 50A 9VDC 16,9Ohm 58,6mmx35mmx45,3mm RTII | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 23 Weeks Available on order | (at least 180 or mul. of 180) | PC relay | Zettler | 4PST-NO/SPST-NC | THT | 9.0 V DC | 50.0 A | 16.9 Ohm | 58.6 mm | 35.0 mm | 45.3 mm | AgSnO2 | RTII | -40.0 °C | 95.0 °C |
