Results (1085)
RoHS compliant
Datasheet
New
In stock
Sale
Not discontinued
| Show Selected | Image | Part No. | Indiv. Part No. | Manufacturer | Price | Availability | Quantity | Series | Data Sheet | RoHS | Manufacturer | Assembly Type | contacts | Contact: Switching Current (min/typ/max) | Coil: Nominal Voltage AC | Coil: Nominal Voltage DC | Coil resistance | Contact: Switching Capacity (VA) | Contact: Switching Load (W) | Contact material | Dimension: Length | Dimension: Width | Dimension: Height | Protection Class | Protection class RT | Operating Temperature Min. | Operating Temperature Max. |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
451 |  | Manufacturers Part No. AZ832-2C-5DE(AZ832-2C-5DE) Zettler PC relay AZ832 THT DPDT 3A 5VDC 125Ohm 20,2mmx10,2mmx10,6mm | Customer Part No. Customer Project No. | 0 Pcs. Available (from stock) | (at least 5 or mul. of 5) | Zettler | THT | DPDT | 3.0 A | 5.0 V DC | 125.0 Ohm | 250.0 VA | 60.0 W | AgPd/Ag_Au | 20.2 mm | 10.2 mm | 10.6 mm | -40.0 °C | 85.0 °C | ||||||||
452 | | Manufacturers Part No. FTR-C1GA012G-B05(FTR-C1GA012G-B05) FCL Components PC relay FTR-C1 SMD DPDT 2A 12VDC 514Ohm 15,2mmx7,7mmx9,7mm RTIII | Customer Part No. Customer Project No. | 0 Pcs. Available (from stock) | (at least 10 or mul. of 10) | FCL Components | SMD | DPDT | 2.0 A | 12.0 V DC | 514.0 Ohm | 62.5 VA | 30.0 W | AgPd/Au | 15.2 mm | 7.7 mm | 9.7 mm | RTIII | -40.0 °C | 85.0 °C | |||||||
453 | | Manufacturers Part No. AZ921-1AE-24DEF(AZ921-1AE-24DEF) Zettler PC relay AZ921 THT SPST-NO 5A 24VDC 3.200Ohm 20,3mmx5,3mmx12,8mm | Customer Part No. Customer Project No. | 980 Pcs. Planned Delivery Time Ø 28 Weeks Available (from stock) | (at least 10 or mul. of 10) | Zettler | THT | SPST-NO | 5.0 A | 24.0 V DC | 3200.0 Ohm | 1250.0 VA | 150.0 W | AgSnO2 | 20.3 mm | 5.3 mm | 12.8 mm | -40.0 °C | 85.0 °C | ||||||||
454 | | Manufacturers Part No. AZ6991-1A-5D(AZ6991-1A-5D) Zettler PC relay AZ6991 THT SPST-NO 8A 5VDC 147Ohm 28mmx5mmx15mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 26 Weeks Available on order | (at least 2000 or mul. of 2000) | Zettler | THT | SPST-NO | 8.0 A | 5.0 V DC | 147.0 Ohm | 2216.0 VA | 180.0 W | AgNi | 28.0 mm | 5.0 mm | 15.0 mm | -40.0 °C | 85.0 °C | ||||||||
455 | | Manufacturers Part No. AZ6991-1C-24DE(AZ6991-1C-24DE) Zettler PC relay AZ6991 THT SPDT 8A 24VDC 3.390Ohm 28mmx5mmx15mm | Customer Part No. Customer Project No. | 1.900 Pcs. Planned Delivery Time Ø 25 Weeks Available (from stock) | (at least 10 or mul. of 10) | Zettler | THT | SPDT | 8.0 A | 24.0 V DC | 3390.0 Ohm | 2216.0 VA | 180.0 W | AgNi | 28.0 mm | 5.0 mm | 15.0 mm | -40.0 °C | 85.0 °C | ||||||||
456 | | Manufacturers Part No. 3-1393788-6(V23079B1203B301) TE Connectivity PC relay P2 V23079 THT DPDT 2A 12VDC 1.029Ohm 14,5mmx7,2mmx9,8mm RTIII | Customer Part No. Customer Project No. | 50 Pcs. Planned Delivery Time Ø 47 Weeks Available (from stock) | (at least 25 or mul. of 25) | TE Connectivity | THT | DPDT | 2.0 A | 12.0 V DC | 1029.0 Ohm | 62.5 VA | 60.0 W | AgNi/Au | 14.5 mm | 7.2 mm | 9.8 mm | RTIII | -40.0 °C | 85.0 °C | |||||||
457 | | Manufacturers Part No. 4-1393789-5(V23079D2003B301) TE Connectivity PC relay P2 V23079 SMD DPDT 2A 12VDC 720Ohm 14,5mmx7,2mmx10,4mm RTIII | Customer Part No. Customer Project No. | 475 Pcs. Planned Delivery Time Ø 1 Week Available (from stock) | (at least 25 or mul. of 25) | TE Connectivity | SMD | DPDT | 2.0 A | 12.0 V DC | 720.0 Ohm | 62.5 VA | 60.0 W | AgNi/Au | 14.5 mm | 7.2 mm | 10.4 mm | RTIII | -40.0 °C | 85.0 °C | |||||||
458 | | Manufacturers Part No. AZ943-1AH-24DEFGW(AZ943-1AH-24DEFGW) Zettler PC relay AZ943 THT SPST-NO 10A 24VDC 1.600Ohm 19mmx15,3mmx15,7mm | Customer Part No. Customer Project No. | 4.370 Pcs. Planned Delivery Time Ø 20 Weeks Available (from stock) | (at least 10 or mul. of 10) | Zettler | THT | SPST-NO | 10.0 A | 24.0 V DC | 1600.0 Ohm | 2770.0 VA | 300.0 W | AgSnO2 | 19.0 mm | 15.3 mm | 15.7 mm | -40.0 °C | 85.0 °C | ||||||||
459 | | Manufacturers Part No. AZ943-1CH-24DEFGW(AZ943-1CH-24DEFGW) Zettler PC relay AZ943 THT SPDT 10A 24VDC 1.600Ohm 19mmx15,3mmx15,7mm | Customer Part No. Customer Project No. | 380 Pcs. Planned Delivery Time Ø 20 Weeks Available (from stock) | (at least 10 or mul. of 10) | Zettler | THT | SPDT | 10.0 A | 24.0 V DC | 1600.0 Ohm | 2770.0 VA | 300.0 W | AgSnO2 | 19.0 mm | 15.3 mm | 15.7 mm | -40.0 °C | 85.0 °C | ||||||||
460 | | Manufacturers Part No. AZ921-1AB-12DEA(AZ921-1AB-12DEA) Zettler PC relay AZ921 THT SPST-NO 5A 12VDC 1.200Ohm 20,3mmx5,3mmx12,8mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 27 Weeks Available on order | (at least 1000 or mul. of 1000) | Zettler | THT | SPST-NO | 5.0 A | 12.0 V DC | 1200.0 Ohm | 1250.0 VA | 150.0 W | AgNi/Au | 20.3 mm | 5.3 mm | 12.8 mm | -40.0 °C | 85.0 °C | ||||||||
461 | | Manufacturers Part No. FTR-C1CA005G(FTR-C1CA005G) FCL Components PC relay FTR-C1 THT DPDT 2A 5VDC 89,3Ohm 15,2mmx7,7mmx9,4mm RTIII | Customer Part No. Customer Project No. | 110 Pcs. Available (from stock) | (at least 10 or mul. of 10) | FCL Components | THT | DPDT | 2.0 A | 5.0 V DC | 89.3 Ohm | 62.5 VA | 30.0 W | AgPd/Au | 15.2 mm | 7.7 mm | 9.4 mm | RTIII | -40.0 °C | 85.0 °C | |||||||
462 | | Manufacturers Part No. AZ921-1AB-12DEAF(AZ921-1AB-12DEAF) Zettler PC relay AZ921 THT SPST-NO 5A 12VDC 1.200Ohm 20,3mmx5,3mmx12,8mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 27 Weeks Available on order | (at least 1000 or mul. of 1000) | Zettler | THT | SPST-NO | 5.0 A | 12.0 V DC | 1200.0 Ohm | 1250.0 VA | 150.0 W | AgNi/Au | 20.3 mm | 5.3 mm | 12.8 mm | -40.0 °C | 85.0 °C | ||||||||
463 | | Manufacturers Part No. AZ921-1AB-5DEA(AZ921-1AB-5DEA) Zettler PC relay AZ921 THT SPST-NO 5A 5VDC 208Ohm 20,3mmx5,3mmx12,8mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 27 Weeks Available on order | (at least 1000 or mul. of 1000) | Zettler | THT | SPST-NO | 5.0 A | 5.0 V DC | 208.0 Ohm | 1250.0 VA | 150.0 W | AgNi/Au | 20.3 mm | 5.3 mm | 12.8 mm | -40.0 °C | 85.0 °C | ||||||||
464 | | Manufacturers Part No. AZ832P2-2C-24DSE(AZ832P2-2C-24DSE) Zettler PC relay AZ832P THT DPDT 3A 24VDC 3.840Ohm 20,2mmx10,2mmx10,6mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 27 Weeks Available on order | (at least 1000 or mul. of 1000) | Zettler | THT | DPDT | 3.0 A | 24.0 V DC | 3840.0 Ohm | 250.0 VA | 60.0 W | AgPd/Ag_Au | 20.2 mm | 10.2 mm | 10.6 mm | -40.0 °C | 85.0 °C | ||||||||
465 | | Manufacturers Part No. AZ6991-1A-12DE(AZ6991-1A-12DE) Zettler PC relay AZ6991 THT SPST-NO 8A 12VDC 848Ohm 28mmx5mmx15mm | Customer Part No. Customer Project No. | 0 Pcs. Available (from stock) | (at least 10 or mul. of 10) | Zettler | THT | SPST-NO | 8.0 A | 12.0 V DC | 848.0 Ohm | 2216.0 VA | 180.0 W | AgNi | 28.0 mm | 5.0 mm | 15.0 mm | -40.0 °C | 85.0 °C | ||||||||
466 | | Manufacturers Part No. AZ6991-1CE-12DE(AZ6991-1CE-12DE) Zettler PC relay AZ6991 THT SPDT 8A 12VDC 848Ohm 28mmx5mmx15mm | Customer Part No. Customer Project No. | 0 Pcs. Available (from stock) | (at least 10 or mul. of 10) | Zettler | THT | SPDT | 8.0 A | 12.0 V DC | 848.0 Ohm | 2216.0 VA | 180.0 W | AgSnO2 | 28.0 mm | 5.0 mm | 15.0 mm | -40.0 °C | 85.0 °C | ||||||||
467 | | Manufacturers Part No. 3-1393789-7(V23079A2003B301) TE Connectivity PC relay P2 V23079 THT DPDT 2A 12VDC 720Ohm 14,5mmx7,2mmx9,8mm RTIII | Customer Part No. Customer Project No. | 500 Pcs. Planned Delivery Time Ø 20 Weeks Available (from stock) | (at least 25 or mul. of 25) | TE Connectivity | THT | DPDT | 2.0 A | 12.0 V DC | 720.0 Ohm | 62.5 VA | 60.0 W | AgNi/Au | 14.5 mm | 7.2 mm | 9.8 mm | RTIII | -40.0 °C | 85.0 °C | |||||||
468 | | Manufacturers Part No. AZ943-1AH-24DE(AZ943-1AH-24DE) Zettler PC relay AZ943 THT SPST-NO 10A 24VDC 1.600Ohm 19mmx15,3mmx15,7mm | Customer Part No. Customer Project No. | 440 Pcs. Planned Delivery Time Ø 20 Weeks Available (from stock) | (at least 10 or mul. of 10) | Zettler | THT | SPST-NO | 10.0 A | 24.0 V DC | 1600.0 Ohm | 2770.0 VA | 300.0 W | AgSnO2 | 19.0 mm | 15.3 mm | 15.7 mm | -40.0 °C | 70.0 °C | ||||||||
469 | | Manufacturers Part No. AZ943-1AH-12DE(AZ943-1AH-12DE) Zettler PC relay AZ943 THT SPST-NO 10A 12VDC 400Ohm 19mmx15,3mmx15,7mm | Customer Part No. Customer Project No. | 170 Pcs. Planned Delivery Time Ø 20 Weeks Available (from stock) | (at least 10 or mul. of 10) | Zettler | THT | SPST-NO | 10.0 A | 12.0 V DC | 400.0 Ohm | 2770.0 VA | 300.0 W | AgSnO2 | 19.0 mm | 15.3 mm | 15.7 mm | -40.0 °C | 70.0 °C | ||||||||
470 | | Manufacturers Part No. AZ943-1CH-24D(AZ943-1CH-24D) Zettler PC relay AZ943 THT SPDT 10A 24VDC 1.600Ohm 19mmx15,3mmx15,7mm | Customer Part No. Customer Project No. | 4.940 Pcs. Planned Delivery Time Ø 20 Weeks Available (from stock) | (at least 10 or mul. of 10) | Zettler | THT | SPDT | 10.0 A | 24.0 V DC | 1600.0 Ohm | 2770.0 VA | 300.0 W | AgSnO2 | 19.0 mm | 15.3 mm | 15.7 mm | -40.0 °C | 70.0 °C | ||||||||
471 | | Manufacturers Part No. AZ943-1CH-12DE(AZ943-1CH-12DE) Zettler PC relay AZ943 THT SPDT 10A 12VDC 400Ohm 19mmx15,3mmx15,7mm | Customer Part No. Customer Project No. | 5.450 Pcs. Planned Delivery Time Ø 20 Weeks Available (from stock) | (at least 10 or mul. of 10) | Zettler | THT | SPDT | 10.0 A | 12.0 V DC | 400.0 Ohm | 2770.0 VA | 300.0 W | AgSnO2 | 19.0 mm | 15.3 mm | 15.7 mm | -40.0 °C | 70.0 °C | ||||||||
472 | | Manufacturers Part No. AZ943-1CH-5DE(AZ943-1CH-5DE) Zettler PC relay AZ943 THT SPDT 10A 5VDC 70Ohm 19mmx15,3mmx15,7mm | Customer Part No. Customer Project No. | 1.990 Pcs. Planned Delivery Time Ø 20 Weeks Available (from stock) | (at least 10 or mul. of 10) | Zettler | THT | SPDT | 10.0 A | 5.0 V DC | 70.0 Ohm | 2770.0 VA | 300.0 W | AgSnO2 | 19.0 mm | 15.3 mm | 15.7 mm | -40.0 °C | 70.0 °C | ||||||||
473 | | Manufacturers Part No. AZ832P2-2C-3DE(AZ832P2-2C-3DE) Zettler PC relay AZ832P THT DPDT 3A 3VDC 45Ohm 20,2mmx10,2mmx10,6mm | Customer Part No. Customer Project No. | 335 Pcs. Planned Delivery Time Ø 25 Weeks Available (from stock) | (at least 5 or mul. of 5) | Zettler | THT | DPDT | 3.0 A | 3.0 V DC | 45.0 Ohm | 250.0 VA | 60.0 W | AgPd/Ag_Au | 20.2 mm | 10.2 mm | 10.6 mm | -40.0 °C | 85.0 °C | ||||||||
474 | | Manufacturers Part No. FTR-C1CB012G(FTR-C1CB012G) FCL Components PC relay FTR-C1 THT DPDT 2A 12VDC 1.029Ohm 15,2mmx7,7mmx9,4mm RTIII | Customer Part No. Customer Project No. | 50 Pcs. Planned Delivery Time Ø 99 Weeks Available (from stock) | (at least 10 or mul. of 10) | FCL Components | THT | DPDT | 2.0 A | 12.0 V DC | 1029.0 Ohm | 62.5 VA | 30.0 W | AgPd/Au | 15.2 mm | 7.7 mm | 9.4 mm | RTIII | -40.0 °C | 85.0 °C | |||||||
475 | | Manufacturers Part No. AZ6991-1A-24D(AZ6991-1A-24D) Zettler PC relay AZ6991 THT SPST-NO 8A 24VDC 3.390Ohm 28mmx5mmx15mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 26 Weeks Available on order | (at least 2000 or mul. of 2000) | Zettler | THT | SPST-NO | 8.0 A | 24.0 V DC | 3390.0 Ohm | 2216.0 VA | 180.0 W | AgNi | 28.0 mm | 5.0 mm | 15.0 mm | -40.0 °C | 85.0 °C |
