Results (1085)
RoHS compliant
Datasheet
New
In stock
Sale
Not discontinued
| Show Selected | Image | Part No. | Indiv. Part No. | Manufacturer | Price | Availability | Quantity | Series | Data Sheet | RoHS | Manufacturer | Assembly Type | contacts | Contact: Switching Current (min/typ/max) | Coil: Nominal Voltage AC | Coil: Nominal Voltage DC | Coil resistance | Contact: Switching Capacity (VA) | Contact: Switching Load (W) | Contact material | Dimension: Length | Dimension: Width | Dimension: Height | Protection Class | Protection class RT | Operating Temperature Min. | Operating Temperature Max. |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
426 |  | Manufacturers Part No. 0-1393219-6(PE140-12) TE Connectivity PC relay PE THT SPDT 5A 12VDC 685Ohm 20mmx10mmx10mm RTII TOP | Customer Part No. Customer Project No. | 1.025 Pcs. Available (from stock) | (at least 25 or mul. of 25) | TE Connectivity | THT | SPDT | 5.0 A | 12.0 V DC | 685.0 Ohm | 1250.0 VA | AgNi | 20.0 mm | 10.0 mm | 10.0 mm | RTII | -40.0 °C | 85.0 °C | ||||||||
427 | | Manufacturers Part No. RM699BV-2011-85-1012(RM699BV2011-851012) RELPOL PC relay RM699B THT SPST 10A 12VDC 848Ohm 28mmx5mmx15mm RTIII | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 28 Weeks Available on order | (at least 2000 or mul. of 2000) | RELPOL | THT | SPST | 10.0 A | 12.0 V DC | 848.0 Ohm | 1500.0 VA | 1.0 W | AgNi | 28.0 mm | 5.0 mm | 15.0 mm | IP67 | RTIII | -40.0 °C | 85.0 °C | ||||||
428 | | Manufacturers Part No. RM699BV-2011-85-1024(RM699BV2011-851024) RELPOL PC relay RM699B THT SPST 10A 24VDC 3.390Ohm 28mmx5mmx15mm RTIII | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 28 Weeks Available on order | (at least 2000 or mul. of 2000) | RELPOL | THT | SPST | 10.0 A | 24.0 V DC | 3390.0 Ohm | 1500.0 VA | 1.0 W | AgNi | 28.0 mm | 5.0 mm | 15.0 mm | IP67 | RTIII | -40.0 °C | 85.0 °C | ||||||
429 | | Manufacturers Part No. RM699BV-3211-85-1012(RM699BV3211-851012) RELPOL PC relay RM699B THT SPST 5A 12VDC 848Ohm 28mmx5mmx15mm RTIII | Customer Part No. Customer Project No. | 90 Pcs. Planned Delivery Time Ø 24 Weeks Available (from stock) | (at least 5 or mul. of 5) | RELPOL | THT | SPST | 5.0 A | 12.0 V DC | 848.0 Ohm | 1.2 VA | 0.05 W | AgSnO2/Au | 28.0 mm | 5.0 mm | 15.0 mm | IP67 | RTIII | -40.0 °C | 85.0 °C | ||||||
430 | | Manufacturers Part No. RM699BV-3211-85-1024(RM699BV3211-851024) RELPOL PC relay RM699B THT SPST 5A 24VDC 3.390Ohm 28mmx5mmx15mm RTIII | Customer Part No. Customer Project No. | 1.895 Pcs. Planned Delivery Time Ø 24 Weeks Available (from stock) | (at least 5 or mul. of 5) | RELPOL | THT | SPST | 5.0 A | 24.0 V DC | 3390.0 Ohm | 1.2 VA | 0.05 W | AgSnO2/Au | 28.0 mm | 5.0 mm | 15.0 mm | IP67 | RTIII | -40.0 °C | 85.0 °C | ||||||
431 | | Manufacturers Part No. AZ832-2C-24DE(AZ832-2C-24DE) Zettler PC relay AZ832 THT DPDT 3A 24VDC 2.880Ohm 20,2mmx10,2mmx10,6mm | Customer Part No. Customer Project No. | 225 Pcs. Available (from stock) | (at least 5 or mul. of 5) | Zettler | THT | DPDT | 3.0 A | 24.0 V DC | 2880.0 Ohm | 250.0 VA | 60.0 W | AgPd/Ag_Au | 20.2 mm | 10.2 mm | 10.6 mm | -40.0 °C | 85.0 °C | ||||||||
432 | | Manufacturers Part No. AZ832P2-2C-12DE(AZ832P2-2C-12DE) Zettler PC relay AZ832P THT DPDT 3A 12VDC 720Ohm 20,2mmx10,2mmx10,6mm | Customer Part No. Customer Project No. | 0 Pcs. Available (from stock) | (at least 5 or mul. of 5) | Zettler | THT | DPDT | 3.0 A | 12.0 V DC | 720.0 Ohm | 250.0 VA | 60.0 W | AgPd/Ag_Au | 20.2 mm | 10.2 mm | 10.6 mm | -40.0 °C | 85.0 °C | ||||||||
433 | | Manufacturers Part No. G5Q-14 DC24(G5Q14-24) Omron PC relay G5Q THT SPDT 10A 24VDC 1.440Ohm 20,3mmx10,3mmx15,5mm RTIII | Customer Part No. Customer Project No. | 1.350 Pcs. Planned Delivery Time Ø 30 Weeks Available (from stock) | (at least 10 or mul. of 10) | Omron | THT | SPDT | 10.0 A | 24.0 V DC | 1440.0 Ohm | Ag alloy | 20.3 mm | 10.3 mm | 15.5 mm | RTIII | -40.0 °C | 105.0 °C | |||||||||
434 | | Manufacturers Part No. FTR-C1CB003G(FTR-C1CB003G) FCL Components PC relay FTR-C1 THT DPDT 2A 3VDC 64Ohm 15,2mmx7,7mmx9,4mm RTIII | Customer Part No. Customer Project No. | 350 Pcs. Planned Delivery Time Ø 99 Weeks Available (from stock) | (at least 10 or mul. of 10) | FCL Components | THT | DPDT | 2.0 A | 3.0 V DC | 64.0 Ohm | 62.5 VA | 30.0 W | AgPd/Au | 15.2 mm | 7.7 mm | 9.4 mm | RTIII | -40.0 °C | 85.0 °C | |||||||
435 | | Manufacturers Part No. AZ921-1A-24DEF(AZ921-1A-24DEF) Zettler PC relay AZ921 THT SPST-NO 5A 24VDC 3.200Ohm 20,3mmx5,3mmx12,8mm | Customer Part No. Customer Project No. | 830 Pcs. Planned Delivery Time Ø 28 Weeks Available (from stock) | (at least 10 or mul. of 10) | Zettler | THT | SPST-NO | 5.0 A | 24.0 V DC | 3200.0 Ohm | 1250.0 VA | 150.0 W | AgNi | 20.3 mm | 5.3 mm | 12.8 mm | -40.0 °C | 85.0 °C | ||||||||
436 | | Manufacturers Part No. AZ6991-1A-24DE(AZ6991-1A-24DE) Zettler PC relay AZ6991 THT SPST-NO 8A 24VDC 3.390Ohm 28mmx5mmx15mm | Customer Part No. Customer Project No. | 0 Pcs. Available (from stock) | (at least 10 or mul. of 10) | Zettler | THT | SPST-NO | 8.0 A | 24.0 V DC | 3390.0 Ohm | 2216.0 VA | 180.0 W | AgNi | 28.0 mm | 5.0 mm | 15.0 mm | -40.0 °C | 85.0 °C | ||||||||
437 | | Manufacturers Part No. AZ6991-1AE-24DE(AZ6991-1AE-24DE) Zettler PC relay AZ6991 THT SPST-NO 8A 24VDC 3.390Ohm 28mmx5mmx15mm | Customer Part No. Customer Project No. | 280 Pcs. Planned Delivery Time Ø 25 Weeks Available (from stock) | (at least 10 or mul. of 10) | Zettler | THT | SPST-NO | 8.0 A | 24.0 V DC | 3390.0 Ohm | 2216.0 VA | 180.0 W | AgSnO2 | 28.0 mm | 5.0 mm | 15.0 mm | -40.0 °C | 85.0 °C | ||||||||
438 | | Manufacturers Part No. 3-1393789-5(V23079A2001B301) TE Connectivity PC relay P2 V23079 THT DPDT 2A 5VDC 125Ohm 14,5mmx7,2mmx9,8mm RTIII % | Customer Part No. Customer Project No. | 900 Pcs. Planned Delivery Time Ø 20 Weeks Available (from stock) | (at least 25 or mul. of 25) | TE Connectivity | THT | DPDT | 2.0 A | 5.0 V DC | 125.0 Ohm | 62.5 VA | 60.0 W | AgNi/Au | 14.5 mm | 7.2 mm | 9.8 mm | RTIII | -40.0 °C | 85.0 °C | |||||||
439 | | Manufacturers Part No. 4-1393789-3(V23079D2001B301) TE Connectivity PC relay P2 V23079 SMD DPDT 2A 5VDC 125Ohm 14,5mmx7,2mmx10,4mm RTIII | Customer Part No. Customer Project No. | 250 Pcs. Planned Delivery Time Ø 48 Weeks Available (from stock) | (at least 25 or mul. of 25) | TE Connectivity | SMD | DPDT | 2.0 A | 5.0 V DC | 125.0 Ohm | 62.5 VA | 60.0 W | AgNi/Au | 14.5 mm | 7.2 mm | 10.4 mm | RTIII | -40.0 °C | 85.0 °C | |||||||
440 | | Manufacturers Part No. FTR-F3AA024V(FTR-F3AA024V) FCL Components PC relay FTR-F3 THT SPST-NO 5A 24VDC 2.060Ohm 20,5mmx7,2mmx15,3mm RTIII | Customer Part No. Customer Project No. | 970 Pcs. Planned Delivery Time Ø 24 Weeks Available (from stock) | (at least 10 or mul. of 10) | FCL Components | THT | SPST-NO | 5.0 A | 24.0 V DC | 2060.0 Ohm | 1250.0 VA | 150.0 W | AgSnO2/Au | 20.5 mm | 7.2 mm | 15.3 mm | RTIII | -40.0 °C | 85.0 °C | |||||||
441 | | Manufacturers Part No. HF41F/024-ZST(HF41F-024-ZST) Hongfa PC relay HF41F THT SPDT 6A 24VDC 3.390Ohm 28mmx5mmx15mm TOP | Customer Part No. Customer Project No. | 1.355 Pcs. Planned Delivery Time Ø 22 Weeks Available (from stock) | (at least 5 or mul. of 5) | Hongfa | THT | SPDT | 6.0 A | 24.0 V DC | 3390.0 Ohm | 1500.0 VA | 180.0 W | AgSnO2 | 28.0 mm | 5.0 mm | 15.0 mm | -40.0 °C | 85.0 °C | ||||||||
442 | | Manufacturers Part No. 2-1419142-2(PE140-3) TE Connectivity PC relay PE THT SPDT 5A 3VDC 45Ohm 20mmx10mmx10mm RTII | Customer Part No. Customer Project No. | 200 Pcs. Planned Delivery Time Ø 9 Weeks Available (from stock) | (at least 25 or mul. of 25) | TE Connectivity | THT | SPDT | 5.0 A | 3.0 V DC | 45.0 Ohm | 1250.0 VA | AgNi | 20.0 mm | 10.0 mm | 10.0 mm | RTII | -40.0 °C | 85.0 °C | ||||||||
443 | | Manufacturers Part No. AZ943-1AH-12DEGW(AZ943-1AH-12DEGW) Zettler PC relay AZ943 THT SPST-NO 10A 12VDC 400Ohm 19mmx15,3mmx15,7mm | Customer Part No. Customer Project No. | 390 Pcs. Planned Delivery Time Ø 20 Weeks Available (from stock) | (at least 10 or mul. of 10) | Zettler | THT | SPST-NO | 10.0 A | 12.0 V DC | 400.0 Ohm | 2770.0 VA | 300.0 W | AgSnO2 | 19.0 mm | 15.3 mm | 15.7 mm | -40.0 °C | 70.0 °C | ||||||||
444 | | Manufacturers Part No. 0-1393219-3(PE140-5) TE Connectivity PC relay PE THT SPDT 5A 5VDC 125Ohm 20mmx10mmx10mm RTII TOP | Customer Part No. Customer Project No. | 5.250 Pcs. Planned Delivery Time Ø 15 Weeks Available (from stock) | (at least 25 or mul. of 25) | TE Connectivity | THT | SPDT | 5.0 A | 5.0 V DC | 125.0 Ohm | 1250.0 VA | AgNi | 20.0 mm | 10.0 mm | 10.0 mm | RTII | -40.0 °C | 85.0 °C | ||||||||
445 | | Manufacturers Part No. AZ943-1CH-24DE(AZ943-1CH-24DE) Zettler PC relay AZ943 THT SPDT 10A 24VDC 1.600Ohm 19mmx15,3mmx15,7mm | Customer Part No. Customer Project No. | 5.250 Pcs. Planned Delivery Time Ø 20 Weeks Available (from stock) | (at least 10 or mul. of 10) | Zettler | THT | SPDT | 10.0 A | 24.0 V DC | 1600.0 Ohm | 2770.0 VA | 300.0 W | AgSnO2 | 19.0 mm | 15.3 mm | 15.7 mm | -40.0 °C | 70.0 °C | ||||||||
446 | | Manufacturers Part No. AZ943-1AH-5DEGW(AZ943-1AH-5DEGW) Zettler PC relay AZ943 THT SPST-NO 10A 5VDC 70Ohm 19mmx15,3mmx15,7mm | Customer Part No. Customer Project No. | 380 Pcs. Planned Delivery Time Ø 20 Weeks Available (from stock) | (at least 10 or mul. of 10) | Zettler | THT | SPST-NO | 10.0 A | 5.0 V DC | 70.0 Ohm | 2770.0 VA | 300.0 W | AgSnO2 | 19.0 mm | 15.3 mm | 15.7 mm | -40.0 °C | 70.0 °C | ||||||||
447 | | Manufacturers Part No. AZ832-2C-12DE(AZ832-2C-12DE) Zettler PC relay AZ832 THT DPDT 3A 12VDC 720Ohm 20,2mmx10,2mmx10,6mm | Customer Part No. Customer Project No. | 770 Pcs. Planned Delivery Time Ø 25 Weeks Available (from stock) | (at least 5 or mul. of 5) | Zettler | THT | DPDT | 3.0 A | 12.0 V DC | 720.0 Ohm | 250.0 VA | 60.0 W | AgPd/Ag_Au | 20.2 mm | 10.2 mm | 10.6 mm | -40.0 °C | 85.0 °C | ||||||||
448 | | Manufacturers Part No. AZ832-2C-12DSE(AZ832-2C-12DSE) Zettler PC relay AZ832 THT DPDT 3A 12VDC 960Ohm 20,2mmx10,2mmx10,6mm | Customer Part No. Customer Project No. | 1.405 Pcs. Planned Delivery Time Ø 25 Weeks Available (from stock) | (at least 5 or mul. of 5) | Zettler | THT | DPDT | 3.0 A | 12.0 V DC | 960.0 Ohm | 250.0 VA | 60.0 W | AgPd/Ag_Au | 20.2 mm | 10.2 mm | 10.6 mm | -40.0 °C | 85.0 °C | ||||||||
449 | | Manufacturers Part No. AZ832P2-2C-5DE(AZ832P2-2C-5DE) Zettler PC relay AZ832P THT DPDT 3A 5VDC 125Ohm 20,2mmx10,2mmx10,6mm | Customer Part No. Customer Project No. | 480 Pcs. Planned Delivery Time Ø 25 Weeks Available (from stock) | (at least 5 or mul. of 5) | Zettler | THT | DPDT | 3.0 A | 5.0 V DC | 125.0 Ohm | 250.0 VA | 60.0 W | AgPd/Ag_Au | 20.2 mm | 10.2 mm | 10.6 mm | -40.0 °C | 85.0 °C | ||||||||
450 | | Manufacturers Part No. FTR-C1CA024G(FTR-C1CA024G) FCL Components PC relay FTR-C1 THT DPDT 2A 24VDC 1.920Ohm 15,2mmx7,7mmx9,4mm RTIII | Customer Part No. Customer Project No. | 0 Pcs. Available (from stock) | (at least 10 or mul. of 10) | FCL Components | THT | DPDT | 2.0 A | 24.0 V DC | 1920.0 Ohm | 62.5 VA | 30.0 W | AgPd/Au | 15.2 mm | 7.7 mm | 9.4 mm | RTIII | -40.0 °C | 85.0 °C |
