Results (1085)
RoHS compliant
Datasheet
New
In stock
Sale
Not discontinued
| Show Selected | Image | Part No. | Indiv. Part No. | Manufacturer | Price | Availability | Quantity | Series | Data Sheet | RoHS | Manufacturer | Assembly Type | contacts | Contact: Switching Current (min/typ/max) | Coil: Nominal Voltage AC | Coil: Nominal Voltage DC | Coil resistance | Contact: Switching Capacity (VA) | Contact: Switching Load (W) | Contact material | Dimension: Length | Dimension: Width | Dimension: Height | Protection Class | Protection class RT | Operating Temperature Min. | Operating Temperature Max. |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
351 |  | Manufacturers Part No. RM40-2011-85-1024(RM40-2011-85-1024) RELPOL PC relay RM40 THT SPST 5A 24VDC 2.880Ohm 20mmx10mmx10,5mm RTIII | Customer Part No. Customer Project No. | 910 Pcs. Planned Delivery Time Ø 25 Weeks Available (from stock) | (at least 10 or mul. of 10) | RELPOL | THT | SPST | 5.0 A | 24.0 V DC | 2880.0 Ohm | 1250.0 VA | AgNi | 20.0 mm | 10.0 mm | 10.5 mm | IP67 | RTIII | -40.0 °C | 85.0 °C | |||||||
352 | | Manufacturers Part No. HJR1-2C-L-12VDC(HJR1-2C-L-12VDC) Tianbo PC relay HJR1-2C THT DPDT 2A 12VDC 720Ohm 20,5mmx10mmx11,8mm | Customer Part No. Customer Project No. | 115 Pcs. Available (from stock) | (at least 5 or mul. of 5) | Tianbo | THT | DPDT | 2.0 A | 12.0 V DC | 720.0 Ohm | 120.0 VA | 60.0 W | Ag alloy | 20.5 mm | 10.0 mm | 11.8 mm | -30.0 °C | 85.0 °C | ||||||||
353 | | Manufacturers Part No. ALQ105(ALQ105) Panasonic PC relay LQ THT SPDT 5A 5VDC 62,5Ohm 20mmx10mmx16mm RTIII | Customer Part No. Customer Project No. | 400 Pcs. Available (from stock) | (at least 10 or mul. of 10) | Panasonic | THT | SPDT | 5.0 A | 5.0 V DC | 62.5 Ohm | 1250.0 VA | 150.0 W | AgNi | 20.0 mm | 10.0 mm | 16.0 mm | RTIII | -40.0 °C | 85.0 °C | |||||||
354 | | Manufacturers Part No. ALQ112(ALQ112) Panasonic PC relay LQ THT SPDT 5A 12VDC 360Ohm 20mmx10mmx16mm RTIII | Customer Part No. Customer Project No. | 500 Pcs. Planned Delivery Time Ø 10 Weeks Available (from stock) | (at least 10 or mul. of 10) | Panasonic | THT | SPDT | 5.0 A | 12.0 V DC | 360.0 Ohm | 1250.0 VA | 150.0 W | AgNi | 20.0 mm | 10.0 mm | 16.0 mm | RTIII | -40.0 °C | 85.0 °C | |||||||
355 | | Manufacturers Part No. FTR-LYCA012Y(FTR-LYCA012Y) FCL Components PC relay FTR-LY THT SPDT 6A 12VDC 847Ohm 28mmx5mmx15mm RTIII | Customer Part No. Customer Project No. | 0 Pcs. Available (from stock) | (at least 5 or mul. of 5) | FCL Components | THT | SPDT | 6.0 A | 12.0 V DC | 847.0 Ohm | 1500.0 VA | 144.0 W | AgSnO2 | 28.0 mm | 5.0 mm | 15.0 mm | RTIII | -40.0 °C | 85.0 °C | |||||||
356 | | Manufacturers Part No. FTR-LYCA024Y(FTR-LYCA024Y) FCL Components PC relay FTR-LY THT SPDT 6A 24VDC 3.390Ohm 28mmx5mmx15mm RTIII | Customer Part No. Customer Project No. | 355 Pcs. Available (from stock) | (at least 5 or mul. of 5) | FCL Components | THT | SPDT | 6.0 A | 24.0 V DC | 3390.0 Ohm | 1500.0 VA | 144.0 W | AgSnO2 | 28.0 mm | 5.0 mm | 15.0 mm | RTIII | -40.0 °C | 85.0 °C | |||||||
357 | | Manufacturers Part No. FTR-LYCA005V(FTR-LY-005) FCL Components PC relay FTR-LY THT SPDT 6A 5VDC 147Ohm 28mmx5mmx15mm RTIII TOP | Customer Part No. Customer Project No. | 0 Pcs. Available (from stock) | (at least 5 or mul. of 5) | FCL Components | THT | SPDT | 6.0 A | 5.0 V DC | 147.0 Ohm | 1500.0 VA | 144.0 W | AgSnO2/Au | 28.0 mm | 5.0 mm | 15.0 mm | RTIII | -40.0 °C | 85.0 °C | |||||||
358 | | Manufacturers Part No. FTR-LYCA024V(FTR-LY-024) FCL Components PC relay FTR-LY THT SPDT 6A 24VDC 3.390Ohm 28mmx5mmx15mm RTIII TOP | Customer Part No. Customer Project No. | 1.185 Pcs. Available (from stock) | (at least 5 or mul. of 5) | FCL Components | THT | SPDT | 6.0 A | 24.0 V DC | 3390.0 Ohm | 1500.0 VA | 144.0 W | AgSnO2/Au | 28.0 mm | 5.0 mm | 15.0 mm | RTIII | -40.0 °C | 85.0 °C | |||||||
359 | | Manufacturers Part No. FTR-LYAA012Y(FTR-LYAA012Y) FCL Components PC relay FTR-LY THT SPST-NO 6A 12VDC 847Ohm 28mmx5mmx15mm RTIII | Customer Part No. Customer Project No. | 135 Pcs. Planned Delivery Time Ø 30 Weeks Available (from stock) | (at least 5 or mul. of 5) | FCL Components | THT | SPST-NO | 6.0 A | 12.0 V DC | 847.0 Ohm | 1500.0 VA | 144.0 W | AgSnO2 | 28.0 mm | 5.0 mm | 15.0 mm | RTIII | -40.0 °C | 85.0 °C | |||||||
360 | | Manufacturers Part No. HF46F/24-HS1T(HF46F-24-HS1T) Hongfa PC relay HF46F THT SPST-NO 5A 24VDC 2.880Ohm 20,5mmx7mmx15,3mm | Customer Part No. Customer Project No. | 815 Pcs. Planned Delivery Time Ø 16 Weeks Available (from stock) | (at least 5 or mul. of 5) | Hongfa | THT | SPST-NO | 5.0 A | 24.0 V DC | 2880.0 Ohm | 1385.0 VA | 150.0 W | AgSnO2 | 20.5 mm | 7.0 mm | 15.3 mm | -40.0 °C | 85.0 °C | ||||||||
361 | | Manufacturers Part No. AZ8462-12(AZ8462-12) Zettler PC relay AZ8462 THT DPDT 2A 12VDC 1.028Ohm 15,2mmx7,7mmx9,2mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 34 Weeks Available on order | (at least 1000 or mul. of 1000) | Zettler | THT | DPDT | 2.0 A | 12.0 V DC | 1028.0 Ohm | 62.5 VA | 60.0 W | AgPd/Au | 15.2 mm | 7.7 mm | 9.2 mm | -40.0 °C | 105.0 °C | ||||||||
362 | | Manufacturers Part No. HF46F-G/12-HS1(HF46F-G-12-HS1) Hongfa PC relay HF46F THT SPST-NO 10A 12VDC 720Ohm 20,5mmx7mmx15,3mm | Customer Part No. Customer Project No. | 255 Pcs. Planned Delivery Time Ø 15 Weeks Available (from stock) | (at least 5 or mul. of 5) | Hongfa | THT | SPST-NO | 10.0 A | 12.0 V DC | 720.0 Ohm | 2770.0 VA | 300.0 W | AgNi | 20.5 mm | 7.0 mm | 15.3 mm | -40.0 °C | 85.0 °C | ||||||||
363 | | Manufacturers Part No. AZ8462-5(AZ8462-5) Zettler PC relay AZ8462 THT DPDT 2A 5VDC 178Ohm 15,2mmx7,7mmx9,2mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 34 Weeks Available on order | (at least 1000 or mul. of 1000) | Zettler | THT | DPDT | 2.0 A | 5.0 V DC | 178.0 Ohm | 62.5 VA | 60.0 W | AgPd/Au | 15.2 mm | 7.7 mm | 9.2 mm | -40.0 °C | 105.0 °C | ||||||||
364 | | Manufacturers Part No. HF46F-G/12-HS1T(HF46F-G-12-HS1T) Hongfa PC relay HF46F THT SPST-NO 10A 24VDC 2.880Ohm 20,5mmx7mmx15,3mm | Customer Part No. Customer Project No. | 105 Pcs. Available (from stock) | (at least 5 or mul. of 5) | Hongfa | THT | SPST-NO | 10.0 A | 24.0 V DC | 2880.0 Ohm | 2770.0 VA | 300.0 W | AgSnO2 | 20.5 mm | 7.0 mm | 15.3 mm | -40.0 °C | 85.0 °C | ||||||||
365 | | Manufacturers Part No. G5V-2-H1 DC12(G5V2-12H1) Omron PC relay G5V-2 THT DPDT 1A 12VDC 960Ohm 20,5mmx10,1mmx11,5mm | Customer Part No. Customer Project No. | 1.725 Pcs. Available (from stock) | (at least 25 or mul. of 25) | Omron | THT | DPDT | 1.0 A | 12.0 V DC | 960.0 Ohm | 62.5 VA | 24.0 W | Ag/Au | 20.5 mm | 10.1 mm | 11.5 mm | -25.0 °C | 70.0 °C | ||||||||
366 | | Manufacturers Part No. G5V-2-H1 DC24(G5V2-24H1) Omron PC relay G5V-2 THT DPDT 1A 24VDC 2.880Ohm 20,5mmx10,1mmx11,5mm TOP | Customer Part No. Customer Project No. | 2.950 Pcs. Planned Delivery Time Ø 23 Weeks Available (from stock) | (at least 25 or mul. of 25) | Omron | THT | DPDT | 1.0 A | 24.0 V DC | 2880.0 Ohm | 62.5 VA | 24.0 W | Ag/Au | 20.5 mm | 10.1 mm | 11.5 mm | -25.0 °C | 70.0 °C | ||||||||
367 | | Manufacturers Part No. G5V-2-H1 DC5(G5V2-5H1) Omron PC relay G5V-2 THT DPDT 1A 5VDC 167Ohm 20,5mmx10,1mmx11,5mm TOP | Customer Part No. Customer Project No. | 1.975 Pcs. Planned Delivery Time Ø 27 Weeks Available (from stock) | (at least 25 or mul. of 25) | Omron | THT | DPDT | 1.0 A | 5.0 V DC | 167.0 Ohm | 62.5 VA | 24.0 W | Ag/Au | 20.5 mm | 10.1 mm | 11.5 mm | -25.0 °C | 70.0 °C | ||||||||
368 | | Manufacturers Part No. AZ8462S-5TR(AZ8462S-5TR) Zettler PC relay AZ8462 SMD DPDT 2A 5VDC 178Ohm 15,2mmx7,7mmx9,2mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 34 Weeks Available on order | (at least 2000 or mul. of 2000) | Zettler | SMD | DPDT | 2.0 A | 5.0 V DC | 178.0 Ohm | 62.5 VA | 60.0 W | AgPd/Au | 15.2 mm | 7.7 mm | 9.2 mm | -40.0 °C | 105.0 °C | ||||||||
369 | | Manufacturers Part No. AZ8462S-24TR(AZ8462S-24TR) Zettler PC relay AZ8462 SMD DPDT 2A 24VDC 4.114Ohm 15,2mmx7,7mmx9,2mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 34 Weeks Available on order | (at least 2000 or mul. of 2000) | Zettler | SMD | DPDT | 2.0 A | 24.0 V DC | 4114.0 Ohm | 62.5 VA | 60.0 W | AgPd/Au | 15.2 mm | 7.7 mm | 9.2 mm | -40.0 °C | 105.0 °C | ||||||||
370 | | Manufacturers Part No. AZ8462-24(AZ8462-24) Zettler PC relay AZ8462 THT DPDT 2A 24VDC 4.114Ohm 15,2mmx7,7mmx9,2mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 34 Weeks Available on order | (at least 1000 or mul. of 1000) | Zettler | THT | DPDT | 2.0 A | 24.0 V DC | 4114.0 Ohm | 62.5 VA | 60.0 W | AgPd/Au | 15.2 mm | 7.7 mm | 9.2 mm | -40.0 °C | 105.0 °C | ||||||||
371 | | Manufacturers Part No. AZ832-2C-24DEA(AZ832-2C-24DEA) Zettler PC relay AZ832 THT DPDT 3A 24VDC 2.880Ohm 20,2mmx10,2mmx10,6mm | Customer Part No. Customer Project No. | 590 Pcs. Planned Delivery Time Ø 25 Weeks Available (from stock) | (at least 5 or mul. of 5) | Zettler | THT | DPDT | 3.0 A | 24.0 V DC | 2880.0 Ohm | 250.0 VA | 60.0 W | AgPd/AgPd_Au | 20.2 mm | 10.2 mm | 10.6 mm | -40.0 °C | 85.0 °C | ||||||||
372 | | Manufacturers Part No. AZ832-2C-24DSE(AZ832-2C-24DSE) Zettler PC relay AZ832 THT DPDT 3A 24VDC 3.840Ohm 20,2mmx10,2mmx10,6mm | Customer Part No. Customer Project No. | 0 Pcs. Available (from stock) | (at least 5 or mul. of 5) | Zettler | THT | DPDT | 3.0 A | 24.0 V DC | 3840.0 Ohm | 250.0 VA | 60.0 W | AgPd/Ag_Au | 20.2 mm | 10.2 mm | 10.6 mm | -40.0 °C | 85.0 °C | ||||||||
373 | | Manufacturers Part No. AZ832P2-2C-12DSE(AZ832P2-2C-12DSE) Zettler PC relay AZ832P THT DPDT 3A 12VDC 960Ohm 20,2mmx10,2mmx10,6mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 27 Weeks Available on order | (at least 1000 or mul. of 1000) | Zettler | THT | DPDT | 3.0 A | 12.0 V DC | 960.0 Ohm | 250.0 VA | 60.0 W | AgPd/Ag_Au | 20.2 mm | 10.2 mm | 10.6 mm | -40.0 °C | 85.0 °C | ||||||||
374 | | Manufacturers Part No. AZ832P2-2C-5DSE(AZ832P2-2C-5DSE) Zettler PC relay AZ832P THT DPDT 3A 5VDC 167Ohm 20,2mmx10,2mmx10,6mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 27 Weeks Available on order | (at least 1000 or mul. of 1000) | Zettler | THT | DPDT | 3.0 A | 5.0 V DC | 167.0 Ohm | 250.0 VA | 60.0 W | AgPd/Ag_Au | 20.2 mm | 10.2 mm | 10.6 mm | -40.0 °C | 85.0 °C | ||||||||
375 | | Manufacturers Part No. ALQ305(ALQ305) Panasonic PC relay LQ THT SPST-NO 5A 5VDC 125Ohm 20mmx10mmx16mm RTIII | Customer Part No. Customer Project No. | 40 Pcs. Available (from stock) | (at least 10 or mul. of 10) | Panasonic | THT | SPST-NO | 5.0 A | 5.0 V DC | 125.0 Ohm | 1250.0 VA | 150.0 W | AgNi | 20.0 mm | 10.0 mm | 16.0 mm | RTIII | -40.0 °C | 85.0 °C |
