Results (331)
RoHS compliant
Datasheet
New
In stock
Sale
Not discontinued
| Show Selected | Image | Part No. | Indiv. Part No. | Manufacturer | Price | Availability | Quantity | Series | Data Sheet | RoHS | Type | Manufacturer | Assembly | Tripping time with specified reference current IS | Rated current | Interrupting Current, Max. | Rated voltage V AC | Rated voltage V DC | Max. resistance 1 hour after switching off | Operating temperature range, min. | Operating temperature range, max. | Housing | Pitch | Dimension: Length | Dimension: Width | Dimension: Height | Diameter |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
01 |  | Customer Part No. Customer Project No. | 0 Pcs. Available (from stock) | (at least 10 or mul. of 10) | Self-resetting fuse | Littelfuse | SMD | 5.0 s | 1.5 A | 15.0 V DC | 250.0 mOhm | 9.4 mm | 6.71 mm | 3.0 mm | |||||||||||||
02 | | Customer Part No. Customer Project No. | 2.120 Pcs. Available (from stock) | (at least 10 or mul. of 10) | Self-resetting fuse | Littelfuse | SMD | 0.5 s | 1.1 A | 30.0 V DC | 480.0 mOhm | 7.98 mm | 5.44 mm | 3.0 mm | |||||||||||||
03 | | Customer Part No. Customer Project No. | 1.310 Pcs. Planned Delivery Time Ø 4 Weeks Available (from stock) | (at least 10 or mul. of 10) | Self-resetting fuse | Littelfuse | SMD | 2.0 s | 1.25 A | 15.0 V DC | 250.0 mOhm | 7.98 mm | 5.44 mm | 3.0 mm | |||||||||||||
04 | | Customer Part No. Customer Project No. | 3.450 Pcs. Available (from stock) | (at least 10 or mul. of 10) | Self-resetting fuse | Littelfuse | SMD | 5.0 s | 1.85 A | 33.0 V DC | 150.0 mOhm | 9.4 mm | 6.71 mm | 3.0 mm | |||||||||||||
05 | | Customer Part No. Customer Project No. | 250 Pcs. Planned Delivery Time Ø 4 Weeks Available (from stock) | (at least 10 or mul. of 10) | Self-resetting fuse | Littelfuse | SMD | 12.0 s | 2.0 A | 15.0 V DC | 125.0 mOhm | 9.4 mm | 6.71 mm | 3.0 mm | |||||||||||||
06 | | Customer Part No. Customer Project No. | 0 Pcs. Available (from stock) | (at least 10 or mul. of 10) | Self-resetting fuse | ECE | SMD | 0.008 s | 0.14 A | 100.0 A | 60.0 V DC | 6500.0 mOhm | -40.0 °C | 85.0 °C | 1812 | 4.73 mm | 3.41 mm | 0.9 mm | |||||||||
07 | | Customer Part No. Customer Project No. | 2.560 Pcs. Planned Delivery Time Ø 18 Weeks Available (from stock) | (at least 10 or mul. of 10) | Self-resetting fuse | ECE | SMD | 0.1 s | 100.0 A | 30.0 V DC | 1750.0 mOhm | -40.0 °C | 85.0 °C | 1812 | 4.73 mm | 3.41 mm | 0.7 mm | ||||||||||
08 | | Customer Part No. Customer Project No. | 990 Pcs. Planned Delivery Time Ø 18 Weeks Available (from stock) | (at least 10 or mul. of 10) | Self-resetting fuse | ECE | SMD | 0.3 s | 1.1 A | 100.0 A | 8.0 V DC | 210.0 mOhm | -40.0 °C | 85.0 °C | 1812 | 4.73 mm | 3.41 mm | 0.55 mm | |||||||||
09 | | Customer Part No. Customer Project No. | 2.270 Pcs. Planned Delivery Time Ø 18 Weeks Available (from stock) | (at least 10 or mul. of 10) | Self-resetting fuse | ECE | SMD | 0.5 s | 1.5 A | 100.0 A | 12.0 V DC | 110.0 mOhm | -40.0 °C | 85.0 °C | 1812 | 4.73 mm | 3.41 mm | 1.1 mm | |||||||||
10 | | Customer Part No. Customer Project No. | 40 Pcs. Available (from stock) | (at least 10 or mul. of 10) | Self-resetting fuse | ECE | SMD | 3.0 s | 0.3 A | 100.0 A | 60.0 V DC | 4800.0 mOhm | -40.0 °C | 85.0 °C | 2920 | 7.98 mm | 5.44 mm | 0.9 mm | |||||||||
11 | | Customer Part No. Customer Project No. | 1.390 Pcs. Available (from stock) | (at least 10 or mul. of 10) | Self-resetting fuse | ECE | SMD | 4.0 s | 0.5 A | 100.0 A | 60.0 V DC | 1400.0 mOhm | -40.0 °C | 85.0 °C | 2920 | 7.98 mm | 5.44 mm | 0.9 mm | |||||||||
12 | | Customer Part No. Customer Project No. | 0 Pcs. Available (from stock) | (at least 10 or mul. of 10) | Self-resetting fuse | ECE | SMD | 0.5 s | 1.1 A | 100.0 A | 33.0 V DC | 410.0 mOhm | -40.0 °C | 85.0 °C | 2920 | 7.98 mm | 5.44 mm | 0.9 mm | |||||||||
13 | | Customer Part No. Customer Project No. | 1.240 Pcs. Planned Delivery Time Ø 18 Weeks Available (from stock) | (at least 10 or mul. of 10) | Self-resetting fuse | ECE | SMD | 2.0 s | 1.5 A | 100.0 A | 33.0 V DC | 230.0 mOhm | -40.0 °C | 85.0 °C | 2920 | 7.98 mm | 5.44 mm | 0.9 mm | |||||||||
14 | | Customer Part No. Customer Project No. | 2.510 Pcs. Planned Delivery Time Ø 18 Weeks Available (from stock) | (at least 10 or mul. of 10) | Self-resetting fuse | ECE | SMD | 4.5 s | 2.5 A | 100.0 A | 16.0 V DC | 85.0 mOhm | -40.0 °C | 85.0 °C | 2920 | 7.98 mm | 5.44 mm | 0.9 mm | |||||||||
15 | | Customer Part No. Customer Project No. | 620 Pcs. Planned Delivery Time Ø 18 Weeks Available (from stock) | (at least 10 or mul. of 10) | Self-resetting fuse | ECE | SMD | 25.0 s | 3.0 A | 100.0 A | 6.0 V DC | 48.0 mOhm | -40.0 °C | 85.0 °C | 2920 | 7.98 mm | 5.44 mm | 0.9 mm | |||||||||
16 | | Customer Part No. Customer Project No. | 1.300 Pcs. Planned Delivery Time Ø 8 Weeks Available (from stock) | (at least 10 or mul. of 10) | Self-resetting fuse | Schurter | SMD | 0.2 s | 0.12 A | 10.0 A | 30.0 V DC | 8500.0 mOhm | -40.0 °C | 85.0 °C | 1206 | 3.4 mm | 1.8 mm | 1.1 mm | |||||||||
17 | | Customer Part No. Customer Project No. | 2.350 Pcs. Planned Delivery Time Ø 8 Weeks Available (from stock) | (at least 10 or mul. of 10) | Self-resetting fuse | Schurter | SMD | 0.1 s | 0.35 A | 100.0 A | 6.0 V DC | 1200.0 mOhm | -40.0 °C | 85.0 °C | 1206 | 3.4 mm | 1.8 mm | 0.85 mm | |||||||||
18 | | Customer Part No. Customer Project No. | 2.260 Pcs. Planned Delivery Time Ø 8 Weeks Available (from stock) | (at least 10 or mul. of 10) | Self-resetting fuse | Schurter | SMD | 0.1 s | 0.5 A | 100.0 A | 13.2 V DC | 700.0 mOhm | -40.0 °C | 85.0 °C | 1206 | 3.4 mm | 1.8 mm | 0.85 mm | |||||||||
19 | | Customer Part No. Customer Project No. | 2.440 Pcs. Planned Delivery Time Ø 8 Weeks Available (from stock) | (at least 10 or mul. of 10) | Self-resetting fuse | Schurter | SMD | 1.5 s | 0.1 A | 40.0 A | 60.0 V DC | 15000.0 mOhm | -40.0 °C | 85.0 °C | 1812 | 4.73 mm | 3.41 mm | 1.1 mm | |||||||||
20 | | Customer Part No. Customer Project No. | 1.250 Pcs. Planned Delivery Time Ø 8 Weeks Available (from stock) | (at least 10 or mul. of 10) | Self-resetting fuse | Schurter | SMD | 0.2 s | 0.75 A | 100.0 A | 13.2 V DC | 450.0 mOhm | -40.0 °C | 85.0 °C | 1812 | 4.73 mm | 3.41 mm | 0.85 mm | |||||||||
21 | | Customer Part No. Customer Project No. | 1.480 Pcs. Planned Delivery Time Ø 8 Weeks Available (from stock) | (at least 10 or mul. of 10) | Self-resetting fuse | Schurter | SMD | 0.06 s | 0.2 A | 80.0 A | 30.0 V DC | 6000.0 mOhm | -40.0 °C | 85.0 °C | 1812 | 4.73 mm | 3.41 mm | 1.1 mm | |||||||||
22 | | Customer Part No. Customer Project No. | 400 Pcs. Planned Delivery Time Ø 8 Weeks Available (from stock) | (at least 10 or mul. of 10) | Self-resetting fuse | Schurter | SMD | 0.15 s | 0.5 A | 100.0 A | 13.0 V DC | 1000.0 mOhm | -40.0 °C | 85.0 °C | 1812 | 4.73 mm | 3.41 mm | 0.85 mm | |||||||||
23 | | Manufacturers Part No. RUEF090(RUEF090) Littelfuse Poly-Switch Fuse RUEF 30VAC 30VDC 0,9A THT RM5,8mm | Customer Part No. Customer Project No. | 1.070 Pcs. Planned Delivery Time Ø 4 Weeks Available (from stock) | (at least 10 or mul. of 10) | Self-resetting fuse | Littelfuse | THT | 5.9 s | 0.9 A | 40.0 A | 30.0 V AC | 30.0 V DC | 120.0 mOhm | -40.0 °C | 85.0 °C | 5.8 mm | 7.4 mm | 3.0 mm | 19.8 mm | |||||||
24 | | Manufacturers Part No. RUEF110(RUEF110) Littelfuse Poly-Switch Fuse RUEF 30VAC 30VDC 1,1A THT RM5,8mm | Customer Part No. Customer Project No. | 2.430 Pcs. Planned Delivery Time Ø 4 Weeks Available (from stock) | (at least 10 or mul. of 10) | Self-resetting fuse | Littelfuse | THT | 6.6 s | 1.1 A | 40.0 A | 30.0 V AC | 30.0 V DC | 170.0 mOhm | -40.0 °C | 85.0 °C | 5.8 mm | 7.4 mm | 3.0 mm | 21.8 mm | |||||||
25 | | Manufacturers Part No. RUEF160(RUEF160) Littelfuse Poly-Switch Fuse RUEF 30VAC 30VDC 1,6A THT RM5,8mm | Customer Part No. Customer Project No. | 1.490 Pcs. Available (from stock) | (at least 10 or mul. of 10) | Self-resetting fuse | Littelfuse | THT | 8.0 s | 1.6 A | 40.0 A | 30.0 V AC | 30.0 V DC | 110.0 mOhm | -40.0 °C | 85.0 °C | 5.8 mm | 8.9 mm | 3.0 mm | 22.8 mm |
