DHA-08TQR
Diptronics DIP/DIL/Rotary Coded Switches DHA Standard-SMD RM1,27mm 8 Switch position 8 Pol(e)
Enter your company's part number here. Your part number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
Enter your personal project number here to assign the item to a project. Your part project number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
1.880 Pcs. in stock
Planned delivery time
Ø 35 Weeks
Life Cycle Status
The life cycle indicates which market phase the item is in. We distinguish between:
• Active (green)
• NRND = Not Recommended for New Designs (yellow)
• LTB = Last Time Buy (yellow)
• EOL = End of Life (red)
Active
Available (from stock)
Data Sheet
ECAD Model
Prices
Manufacturer bundle 1800 Pcs.
Manufacturer's packaging unit (Mfr. PU) means the smallest original packaging unit of the manufacturer.
Price per 1 Pcs.
Quantity and Options
(at least 10 or multiple of 10)
All prices net plus VAT. We do not deliver to private customers.
Fact Sheet
- Type
- DIP/DIL/Rotary Coded Switches
- Series
- DHA
- Body colour
- black
- Type ( axial, radial )
- Standard-SMD
- Pitch
- 1.27 mm
- Type of actuator
- Lever
- Number of switch positions
- 8
- Actuator colour
- white
- Number of poles
- 8
- illumination
- unlit
- Switching current, max.
- 0.025 A
- Actuating force, max.
- 500 gf
- Operating temperature range, min.
- -40 °C
- Operating temperature range, max.
- 85 °C
- RoHS-Conform
Specifications
Open all
Dimensions and weights
- Dimension: Length
- 11.29 mm
- Dimension: Width
- 6.2 mm
- Dimension: Height
- 2.2 mm
- Pitch
- 1.27 mm
Operating conditions
- Operating temperature range, min.
- -40 °C
- Operating temperature range, max.
- 85 °C
- Minimum Storage Temperature
- -40 °C
- Maximum Storage Temperature
- 85 °C
Technical features
- Switching current, max.
- 0.025 A
- Contact resistance, max.
- 100 mOhm
- Insulation resistance, min.
- 100 MOhm
- Material: Terminals
- gold plated
Mechanical properties
- Connection
- SMD
- Operating path
- 0.8 mm
- Actuating force, max.
- 500 gf
- Number of switch positions
- 8
- Number of poles
- 8
