Results (570)
Not discontinued
In stock
RoHS compliant
Datasheet
New
| Show Selected | Image | Part No. | Indiv. Part No. | Manufacturer | Price | Availability | Quantity | Series | Data Sheet | RoHS | Manufacturer | Type | Package/Case | Frequency | Frequency tolerance | Load capacity | Ageing, max. | Load, max. | Operating Temperature Min. | Operating Temperature Max. | Dimension: Length | Dimension: Width | Dimension: Height |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
51 | Manufacturers Part No. 49U-10.2400M-AF-30/30-40R-30P(QM010.240) Abundance Crystal HC-49/U Metal housing 10,24MHz ±30ppm x 11,05mm x 13,6mm 30pF | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 7 Weeks Available (from stock) | (at least 10 or mul. of 10) | Abundance | Crystal | Metal housing | 10.24 MHz | ±30 ppm | 30.0 pF | ±5 ppm/Jahr | 1,0 mW | -10.0 °C | 60.0 °C | 11.05 mm | 13.6 mm | |||||||
52 | Manufacturers Part No. HC49U-20.000M-AF-30/30-25R-30P(QM020) Abundance Crystal HC-49/U Metal housing 20MHz ±30ppm x 11,05mm x 13,6mm 30pF | Customer Part No. Customer Project No. | 3.920 Pcs. Planned Delivery Time Ø 29 Weeks Available (from stock) | (at least 10 or mul. of 10) | Abundance | Crystal | Metal housing | 20.0 MHz | ±30 ppm | 30.0 pF | ±5 ppm/Jahr | 1,0 mW | -10.0 °C | 60.0 °C | 11.05 mm | 13.6 mm | |||||||
53 | Manufacturers Part No. CM9V-T1A 32.768-9-20-TAQC(CM9V-32-9-2-TAQC) Micro Crystal SMD Tuning Fork Quartz Crystal CM9V-T1A Ceramic case 0,032768MHz ±20ppm 1,6mm x 1mm x 0,5mm 9pF | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 6 Weeks Available on order | (at least 100 or mul. of 100) | Micro Crystal | SMD Tuning Fork Quartz Crystal | Ceramic case | 0.032768 MHz | ±20 ppm | 9.0 pF | ±3 ppm/Jahr | 0,5 µW | -40.0 °C | 85.0 °C | 1.6 mm | 1.0 mm | 0.5 mm | ||||||
54 | Manufacturers Part No. X32-12.000-12-30/30/-40+85(X32-12.000-12-334) MEC Mercury SMD Crystal X32 Metal housing 12MHz ±30ppm 3,2mm x 2,5mm x 0,7mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 10 Weeks Available on order | (at least 100 or mul. of 100) | MEC Mercury | SMD Crystal | Metal housing | 12.0 MHz | ±30 ppm | ±3 ppm/Jahr | 100 µW | -40.0 °C | 85.0 °C | 3.2 mm | 2.5 mm | 0.7 mm | |||||||
55 | Manufacturers Part No. X32-14.31818-12-30/30/-40+85(X32-14.31818) MEC Mercury SMD Crystal X32 Metal housing 14,31818MHz ±30ppm 3,2mm x 2,5mm x 0,7mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 10 Weeks Available on order | (at least 100 or mul. of 100) | MEC Mercury | SMD Crystal | Metal housing | 14.31818 MHz | ±30 ppm | ±3 ppm/Jahr | 100 µW | -40.0 °C | 85.0 °C | 3.2 mm | 2.5 mm | 0.7 mm | |||||||
56 | Manufacturers Part No. X32-14.74560-12-30/30/-40+85(X32-14.74560) MEC Mercury SMD Crystal X32 Metal housing 14,7456MHz ±30ppm 3,2mm x 2,5mm x 0,7mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 10 Weeks Available on order | (at least 100 or mul. of 100) | MEC Mercury | SMD Crystal | Metal housing | 14.7456 MHz | ±30 ppm | ±3 ppm/Jahr | 100 µW | -40.0 °C | 85.0 °C | 3.2 mm | 2.5 mm | 0.7 mm | |||||||
57 | Manufacturers Part No. X32-18.432-12-30/30/-40+85(X32-18.432-12-334) MEC Mercury SMD Crystal X32 Metal housing 18,432MHz ±30ppm 3,2mm x 2,5mm x 0,7mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 10 Weeks Available on order | (at least 100 or mul. of 100) | MEC Mercury | SMD Crystal | Metal housing | 18.432 MHz | ±30 ppm | ±3 ppm/Jahr | 100 µW | -40.0 °C | 85.0 °C | 3.2 mm | 2.5 mm | 0.7 mm | |||||||
58 | Manufacturers Part No. QTC232.76807B2R(QTC232.76807B2R) QANTEK SMD Tuning Fork Quartz Crystal QTC2 Ceramic case 0,032768MHz ±20ppm 1,2mm x 2mm x 0,6mm 7pF | Customer Part No. Customer Project No. | 650 Pcs. Planned Delivery Time Ø 6 Weeks Available (from stock) | (at least 10 or mul. of 10) | QANTEK | SMD Tuning Fork Quartz Crystal | Ceramic case | 0.032768 MHz | ±20 ppm | 7.0 pF | ±3 ppm/Jahr | 1,5 µW | -40.0 °C | 85.0 °C | 1.2 mm | 2.0 mm | 0.6 mm | ||||||
59 | Manufacturers Part No. X32-24.576-12-30/30/-40+85(X32-24.576-12-334) MEC Mercury SMD Crystal X32 Metal housing 24,576MHz ±30ppm 3,2mm x 2,5mm x 0,7mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 10 Weeks Available on order | (at least 100 or mul. of 100) | MEC Mercury | SMD Crystal | Metal housing | 24.576 MHz | ±30 ppm | ±3 ppm/Jahr | 100 µW | -40.0 °C | 85.0 °C | 3.2 mm | 2.5 mm | 0.7 mm | |||||||
60 | Manufacturers Part No. MJ-12.000-12-30/30/-40+85(MJ-12.000-12-334) MEC Mercury SMD Crystal MJ Metal housing 12MHz ±30ppm 5mm x 3,2mm x 0,9mm | Customer Part No. Customer Project No. | 820 Pcs. Planned Delivery Time Ø 10 Weeks Available (from stock) | (at least 10 or mul. of 10) | MEC Mercury | SMD Crystal | Metal housing | 12.0 MHz | ±30 ppm | ±3 ppm/Jahr | 100 µW | -40.0 °C | 85.0 °C | 5.0 mm | 3.2 mm | 0.9 mm | |||||||
61 | Manufacturers Part No. X32-32.000-12-30/30/-40+85(X32-32.000-12-334) MEC Mercury SMD Crystal X32 Metal housing 32MHz ±30ppm 3,2mm x 2,5mm x 0,7mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 10 Weeks Available on order | (at least 100 or mul. of 100) | MEC Mercury | SMD Crystal | Metal housing | 32.0 MHz | ±30 ppm | ±3 ppm/Jahr | 100 µW | -40.0 °C | 85.0 °C | 3.2 mm | 2.5 mm | 0.7 mm | |||||||
62 | Manufacturers Part No. X32-40.000-12-30/30/-40+85(X32-40.000-12-334) MEC Mercury SMD Crystal X32 Metal housing 40MHz ±30ppm 3,2mm x 2,5mm x 0,7mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 10 Weeks Available on order | (at least 100 or mul. of 100) | MEC Mercury | SMD Crystal | Metal housing | 40.0 MHz | ±30 ppm | ±3 ppm/Jahr | 100 µW | -40.0 °C | 85.0 °C | 3.2 mm | 2.5 mm | 0.7 mm | |||||||
63 | Manufacturers Part No. MJ-16.384-12-30/30/-40+85(MJ-16.384-12-334) MEC Mercury SMD Crystal MJ Metal housing 16,384MHz ±30ppm 5mm x 3,2mm x 0,9mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 10 Weeks Available on order | (at least 100 or mul. of 100) | MEC Mercury | SMD Crystal | Metal housing | 16.384 MHz | ±30 ppm | ±3 ppm/Jahr | 100 µW | -40.0 °C | 85.0 °C | 5.0 mm | 3.2 mm | 0.9 mm | |||||||
64 | Manufacturers Part No. MQ-16.000-12-30/30/-40+85(MQ-16.000-12-334) MEC Mercury SMD Crystal MQ Metal housing 16MHz ±30ppm 7mm x 5mm x 1mm | Customer Part No. Customer Project No. | 80 Pcs. Planned Delivery Time Ø 10 Weeks Available (from stock) | (at least 10 or mul. of 10) | MEC Mercury | SMD Crystal | Metal housing | 16.0 MHz | ±30 ppm | ±3 ppm/Jahr | 100 µW | -40.0 °C | 85.0 °C | 7.0 mm | 5.0 mm | 1.0 mm | |||||||
65 | Manufacturers Part No. MQ-16.384-12-30/30/-40+85(MQ-16.384-12-334) MEC Mercury SMD Crystal MQ Metal housing 16,384MHz ±30ppm 7mm x 5mm x 1mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 10 Weeks Available on order | (at least 1000 or mul. of 1000) | MEC Mercury | SMD Crystal | Metal housing | 16.384 MHz | ±30 ppm | ±3 ppm/Jahr | 100 µW | -40.0 °C | 85.0 °C | 7.0 mm | 5.0 mm | 1.0 mm | |||||||
66 | Manufacturers Part No. MQ-18.432-12-30/30/-40+85(MQ-18.432-12-334) MEC Mercury SMD Crystal MQ Metal housing 18,432MHz ±30ppm 7mm x 5mm x 1mm | Customer Part No. Customer Project No. | 1.000 Pcs. Planned Delivery Time Ø 10 Weeks Available (from stock) | (at least 10 or mul. of 10) | MEC Mercury | SMD Crystal | Metal housing | 18.432 MHz | ±30 ppm | ±3 ppm/Jahr | 100 µW | -40.0 °C | 85.0 °C | 7.0 mm | 5.0 mm | 1.0 mm | |||||||
67 | Manufacturers Part No. MQ-20.000-12-30/30/-40+85(MQ-20.000-12-334) MEC Mercury SMD Crystal MQ Metal housing 20MHz ±30ppm 7mm x 5mm x 1mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 10 Weeks Available on order | (at least 1000 or mul. of 1000) | MEC Mercury | SMD Crystal | Metal housing | 20.0 MHz | ±30 ppm | ±3 ppm/Jahr | 100 µW | -40.0 °C | 85.0 °C | 7.0 mm | 5.0 mm | 1.0 mm | |||||||
68 | Manufacturers Part No. MQ-24.000-12-30/30/-40+85(MQ-24.000-12-334) MEC Mercury SMD Crystal MQ Metal housing 24MHz ±30ppm 7mm x 5mm x 1mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 10 Weeks Available on order | (at least 100 or mul. of 100) | MEC Mercury | SMD Crystal | Metal housing | 24.0 MHz | ±30 ppm | ±3 ppm/Jahr | 100 µW | -40.0 °C | 85.0 °C | 7.0 mm | 5.0 mm | 1.0 mm | |||||||
69 | Manufacturers Part No. MQ-24.576-12-30/30/-40+85(MQ-24.576-12-334) MEC Mercury SMD Crystal MQ Metal housing 24,576MHz ±30ppm 7mm x 5mm x 1mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 10 Weeks Available on order | (at least 1000 or mul. of 1000) | MEC Mercury | SMD Crystal | Metal housing | 24.576 MHz | ±30 ppm | ±3 ppm/Jahr | 100 µW | -40.0 °C | 85.0 °C | 7.0 mm | 5.0 mm | 1.0 mm | |||||||
70 | Manufacturers Part No. MQ-25.000-12-30/30/-40+85(MQ-25.000-12-334) MEC Mercury SMD Crystal MQ Metal housing 25MHz ±30ppm 7mm x 5mm x 1mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 10 Weeks Available on order | (at least 10 or mul. of 10) | MEC Mercury | SMD Crystal | Metal housing | 25.0 MHz | ±30 ppm | ±3 ppm/Jahr | 100 µW | -40.0 °C | 85.0 °C | 7.0 mm | 5.0 mm | 1.0 mm | |||||||
71 | Manufacturers Part No. MQ-6.000-12-30/30/-40+85(MQ-6.000-12-334) MEC Mercury SMD Crystal MQ Metal housing 6MHz ±30ppm 7mm x 5mm x 1mm | Customer Part No. Customer Project No. | 630 Pcs. Planned Delivery Time Ø 12 Weeks Available (from stock) | (at least 10 or mul. of 10) | MEC Mercury | SMD Crystal | Metal housing | 6.0 MHz | ±30 ppm | ±3 ppm/Jahr | 100 µW | -40.0 °C | 85.0 °C | 7.0 mm | 5.0 mm | 1.0 mm | |||||||
72 | Manufacturers Part No. MQ-8.000-12-30/30/-40+85(MQ-8.000-12-334) MEC Mercury SMD Crystal MQ Metal housing 8MHz ±30ppm 7mm x 5mm x 1mm | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 10 Weeks Available on order | (at least 1000 or mul. of 1000) | MEC Mercury | SMD Crystal | Metal housing | 8.0 MHz | ±30 ppm | ±3 ppm/Jahr | 100 µW | -40.0 °C | 85.0 °C | 7.0 mm | 5.0 mm | 1.0 mm | |||||||
73 | Manufacturers Part No. IC15030.000M20.0CE1B(IC15M30.0) Red Frequency SMD Crystal IC 15 Ceramic case 30MHz 20ppm 5,2mm x 3,4mm x 1,1mm 20pF | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 8 Weeks Available on order | (at least 500 or mul. of 500) | Red Frequency | SMD Crystal | Ceramic case | 30.0 MHz | 20 ppm | 20.0 pF | ±2 ppm/Jahr | -20.0 °C | 70.0 °C | 5.2 mm | 3.4 mm | 1.1 mm | |||||||
74 | Manufacturers Part No. IC15008.000M12.0EF1B(IC15M8) Red Frequency SMD Crystal IC 15 Ceramic case 8MHz 30ppm 5,2mm x 3,4mm x 1,1mm 12pF | Customer Part No. Customer Project No. | 3.380 Pcs. Planned Delivery Time Ø 16 Weeks Available (from stock) | (at least 5 or mul. of 5) | Red Frequency | SMD Crystal | Ceramic case | 8.0 MHz | 30 ppm | 12.0 pF | ±2 ppm/Jahr | -20.0 °C | 70.0 °C | 5.2 mm | 3.4 mm | 1.1 mm | |||||||
75 | Manufacturers Part No. Q13MC1461000214(MC146-32.768) Epson SMD Clock Crystal MC-146 Plastic housing 0,032768MHz 20ppm 7mm x 1,5mm x 1,4mm 12,5pF | Customer Part No. Customer Project No. | 3.550 Pcs. Planned Delivery Time Ø 16 Weeks Available (from stock) | (at least 10 or mul. of 10) | Epson | SMD Clock Crystal | Plastic housing | 0.032768 MHz | 20 ppm | 12.5 pF | ±3 ppm/Jahr | 0,5 µW | -40.0 °C | 85.0 °C | 7.0 mm | 1.5 mm | 1.4 mm |
