Results (570)
Not discontinued
In stock
RoHS compliant
Datasheet
New
| Show Selected | Image | Part No. | Indiv. Part No. | Manufacturer | Price | Availability | Quantity | Series | Data Sheet | RoHS | Manufacturer | Type | Package/Case | Frequency | Frequency tolerance | Load capacity | Ageing, max. | Load, max. | Operating Temperature Min. | Operating Temperature Max. | Dimension: Length | Dimension: Width | Dimension: Height |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
351 | Manufacturers Part No. 49S4HSMD15.000M-AF-303050R-30P(QSMD015) Abundance SMD Crystal HC49-S4-SMD Metal housing 15MHz ±30ppm 13mm x 4,73mm x 4,2mm 30pF | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 7 Weeks Available on order | (at least 1000 or mul. of 1000) | Abundance | SMD Crystal | Metal housing | 15.0 MHz | ±30 ppm | 30.0 pF | ±5 ppm/Jahr | 1,0 mW | -10.0 °C | 60.0 °C | 13.0 mm | 4.73 mm | 4.2 mm | ||||||
352 | Manufacturers Part No. IC13025.000M20.0CE1B(IC13M25.0) Red Frequency SMD Crystal IC 13 Ceramic case 25MHz 20ppm 3,4mm x 2,7mm x 0,75mm 20pF | Customer Part No. Customer Project No. | 4.925 Pcs. Planned Delivery Time Ø 8 Weeks Available (from stock) | (at least 5 or mul. of 5) | Red Frequency | SMD Crystal | Ceramic case | 25.0 MHz | 20 ppm | 20.0 pF | ±5 ppm/Jahr | -20.0 °C | 70.0 °C | 3.4 mm | 2.7 mm | 0.75 mm | |||||||
353 | Manufacturers Part No. IC21020.000M30.0EE1B(IC21SMD20) Red Frequency SMD Crystal IC 21 Metal housing 20MHz ±30ppm 13,3mm x 5mm x 4mm 30pF | Customer Part No. Customer Project No. | 1.200 Pcs. Planned Delivery Time Ø 8 Weeks Available (from stock) | (at least 10 or mul. of 10) | Red Frequency | SMD Crystal | Metal housing | 20.0 MHz | ±30 ppm | 30.0 pF | ±3 ppm/Jahr | 1,0 mW | -20.0 °C | 70.0 °C | 13.3 mm | 5.0 mm | 4.0 mm | ||||||
354 | Manufacturers Part No. Q22FA1280037412(Q22FA1280037412) Epson SMD Crystal FA-128 Plastic housing 27,12MHz 15ppm 2mm x 1,6mm x 0,5mm 6pF | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 16 Weeks Available on order | (at least 250 or mul. of 250) | Epson | SMD Crystal | Plastic housing | 27.12 MHz | 15 ppm | 6.0 pF | 100 µW | -40.0 °C | 85.0 °C | 2.0 mm | 1.6 mm | 0.5 mm | |||||||
355 | Manufacturers Part No. Q22FA1280034512(Q22FA12800345) Epson SMD Crystal FA-128 Plastic housing 50MHz 10ppm 2mm x 1,6mm x 0,5mm 8pF | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 16 Weeks Available on order | (at least 250 or mul. of 250) | Epson | SMD Crystal | Plastic housing | 50.0 MHz | 10 ppm | 8.0 pF | 1 ppm/Jahr | 100 µW | -40.0 °C | 85.0 °C | 2.0 mm | 1.6 mm | 0.5 mm | ||||||
356 | Manufacturers Part No. 49S4HSMD12.288M-AF3030-50R-30P(QSMD012.288) Abundance SMD Crystal HC49-S4-SMD Metal housing 12,228MHz ±30ppm 13mm x 4,73mm x 4,2mm 30pF | Customer Part No. Customer Project No. | 2.420 Pcs. Planned Delivery Time Ø 15 Weeks Available (from stock) | (at least 10 or mul. of 10) | Abundance | SMD Crystal | Metal housing | 12.228 MHz | ±30 ppm | 30.0 pF | ±5 ppm/Jahr | 1,0 mW | -10.0 °C | 60.0 °C | 13.0 mm | 4.73 mm | 4.2 mm | ||||||
357 | Manufacturers Part No. 49SX3SMD4-12M-AF-30/30(49SX3SMD4-12M) Abundance SMD Crystal 49SX3SMD4 Plastic housing 12MHz ±50ppm 12,5mm x 4,85mm x 5mm 16pF | Customer Part No. Customer Project No. | 4.030 Pcs. Planned Delivery Time Ø 29 Weeks Available (from stock) | (at least 5 or mul. of 5) | Abundance | SMD Crystal | Plastic housing | 12.0 MHz | ±50 ppm | 16.0 pF | ±5 ppm/Jahr | 500 µW | -20.0 °C | 70.0 °C | 12.5 mm | 4.85 mm | 5.0 mm | ||||||
358 | Manufacturers Part No. 49SX3SMD4-16M-AF-30/30(49SX3SMD4-16M) Abundance SMD Crystal 49SX3SMD4 Plastic housing 16MHz ±50ppm 12,5mm x 4,85mm x 5mm 16pF | Customer Part No. Customer Project No. | 8.465 Pcs. Planned Delivery Time Ø 19 Weeks Available (from stock) | (at least 5 or mul. of 5) | Abundance | SMD Crystal | Plastic housing | 16.0 MHz | ±50 ppm | 16.0 pF | ±5 ppm/Jahr | 500 µW | -20.0 °C | 70.0 °C | 12.5 mm | 4.85 mm | 5.0 mm | ||||||
359 | Manufacturers Part No. 49SX3SMD4-4M-AF-30/30(49SX3SMD4-4M) Abundance SMD Crystal 49SX3SMD4 Plastic housing 4MHz ±50ppm 12,5mm x 4,85mm x 5mm 16pF | Customer Part No. Customer Project No. | 4.245 Pcs. Planned Delivery Time Ø 24 Weeks Available (from stock) | (at least 5 or mul. of 5) | Abundance | SMD Crystal | Plastic housing | 4.0 MHz | ±50 ppm | 16.0 pF | ±5 ppm/Jahr | 500 µW | -20.0 °C | 70.0 °C | 12.5 mm | 4.85 mm | 5.0 mm | ||||||
360 | Manufacturers Part No. IC21012.000M30.0EE1B(IC21SMD12) Red Frequency SMD Crystal IC 21 Metal housing 12MHz ±30ppm 13,3mm x 5mm x 4mm 30pF | Customer Part No. Customer Project No. | 0 Pcs. Available (from stock) | (at least 10 or mul. of 10) | Red Frequency | SMD Crystal | Metal housing | 12.0 MHz | ±30 ppm | 30.0 pF | ±3 ppm/Jahr | 1,0 mW | -20.0 °C | 70.0 °C | 13.3 mm | 5.0 mm | 4.0 mm | ||||||
361 | Manufacturers Part No. IC23018.432M30.0EE1C(IC23TH18.432) Red Frequency Crystal, wired IC 23 Metal housing 18,432MHz ±30ppm 10,7mm x 4,3mm x 3,5mm 30pF | Customer Part No. Customer Project No. | 1.000 Pcs. Planned Delivery Time Ø 8 Weeks Available (from stock) | (at least 10 or mul. of 10) | Red Frequency | Crystal, wired | Metal housing | 18.432 MHz | ±30 ppm | 30.0 pF | ±3 ppm/Jahr | 500 µW | -10.0 °C | 60.0 °C | 10.7 mm | 4.3 mm | 3.5 mm | ||||||
362 | Manufacturers Part No. IC23015.000M30.0EE1C(IC23TH15.0) Red Frequency Crystal, wired IC 23 Metal housing 15MHz ±30ppm 10,7mm x 4,3mm x 3,5mm 30pF | Customer Part No. Customer Project No. | 840 Pcs. Planned Delivery Time Ø 8 Weeks Available (from stock) | (at least 10 or mul. of 10) | Red Frequency | Crystal, wired | Metal housing | 15.0 MHz | ±30 ppm | 30.0 pF | ±3 ppm/Jahr | 500 µW | -10.0 °C | 60.0 °C | 10.7 mm | 4.3 mm | 3.5 mm | ||||||
363 | Manufacturers Part No. IC23013.824M16.0EE1C(IC23TH13.824) Red Frequency Crystal, wired IC 23 Metal housing 13,824MHz ±30ppm 10,7mm x 4,3mm x 3,5mm 16pF | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 8 Weeks Available on order | (at least 500 or mul. of 500) | Red Frequency | Crystal, wired | Metal housing | 13.824 MHz | ±30 ppm | 16.0 pF | ±3 ppm/Jahr | 500 µW | -10.0 °C | 60.0 °C | 10.7 mm | 4.3 mm | 3.5 mm | ||||||
364 | Manufacturers Part No. QCS4.91520F18B23M(QCS4.91520F18B) QANTEK SMD Crystal QCS 4,9152MHz ±20ppm 12,5mm x 4,8mm x 4,4mm 18pF | Customer Part No. Customer Project No. | 770 Pcs. Planned Delivery Time Ø 9 Weeks Available (from stock) | (at least 10 or mul. of 10) | QANTEK | SMD Crystal | 4.9152 MHz | ±20 ppm | 18.0 pF | ±3 ppm/Jahr | 1 mW | -40.0 °C | 85.0 °C | 12.5 mm | 4.8 mm | 4.4 mm | |||||||
365 | Manufacturers Part No. QCS4.194304F18B23M(QCS4.194304F18B) QANTEK SMD Crystal QCS 4,194304MHz ±20ppm 12,5mm x 4,8mm x 4,4mm 18pF | Customer Part No. Customer Project No. | 260 Pcs. Planned Delivery Time Ø 9 Weeks Available (from stock) | (at least 10 or mul. of 10) | QANTEK | SMD Crystal | 4.194304 MHz | ±20 ppm | 18.0 pF | ±3 ppm/Jahr | 1 mW | -40.0 °C | 85.0 °C | 12.5 mm | 4.8 mm | 4.4 mm | |||||||
366 | Manufacturers Part No. QCS32.0000F18B23M(QCS32.0000F18B) QANTEK SMD Crystal QCS 32MHz ±20ppm 12,5mm x 4,8mm x 4,4mm 18pF | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 10 Weeks Available on order | (at least 100 or mul. of 100) | QANTEK | SMD Crystal | 32.0 MHz | ±20 ppm | 18.0 pF | ±3 ppm/Jahr | 1 mW | -40.0 °C | 85.0 °C | 12.5 mm | 4.8 mm | 4.4 mm | |||||||
367 | Manufacturers Part No. QCS12.2880F18B23M(QCS12.2880F18B) QANTEK SMD Crystal QCS 12,288MHz ±20ppm 12,5mm x 4,8mm x 4,4mm 18pF | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 10 Weeks Available on order | (at least 100 or mul. of 100) | QANTEK | SMD Crystal | 12.288 MHz | ±20 ppm | 18.0 pF | ±3 ppm/Jahr | 1 mW | -40.0 °C | 85.0 °C | 12.5 mm | 4.8 mm | 4.4 mm | |||||||
368 | Manufacturers Part No. QCS18.4320F18B23R(QCS18.4320F18B) QANTEK SMD Crystal QCS 18,432MHz ±20ppm 12,5mm x 4,8mm x 4,4mm 18pF | Customer Part No. Customer Project No. | 480 Pcs. Planned Delivery Time Ø 9 Weeks Available (from stock) | (at least 10 or mul. of 10) | QANTEK | SMD Crystal | 18.432 MHz | ±20 ppm | 18.0 pF | ±3 ppm/Jahr | 1 mW | -40.0 °C | 85.0 °C | 12.5 mm | 4.8 mm | 4.4 mm | |||||||
369 | Manufacturers Part No. IC13048.000M20.0CE1B(IC13M48.0) Red Frequency SMD Crystal IC 13 Ceramic case 48MHz 20ppm 3,4mm x 2,7mm x 0,75mm 20pF | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 8 Weeks Available on order | (at least 500 or mul. of 500) | Red Frequency | SMD Crystal | Ceramic case | 48.0 MHz | 20 ppm | 20.0 pF | ±5 ppm/Jahr | -20.0 °C | 70.0 °C | 3.4 mm | 2.7 mm | 0.75 mm | |||||||
370 | Manufacturers Part No. IC13010.000M12.0EF1B(IC13M10) Red Frequency SMD Crystal IC 13 Ceramic case 10MHz 30ppm 3,4mm x 2,7mm x 0,75mm 12pF | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 8 Weeks Available on order | (at least 500 or mul. of 500) | Red Frequency | SMD Crystal | Ceramic case | 10.0 MHz | 30 ppm | 12.0 pF | ±5 ppm/Jahr | -20.0 °C | 70.0 °C | 3.4 mm | 2.7 mm | 0.75 mm | |||||||
371 | Manufacturers Part No. IC13012.000M20.0CE1B(IC13M12.0) Red Frequency SMD Crystal IC 13 Ceramic case 12MHz 20ppm 3,4mm x 2,7mm x 0,75mm 20pF | Customer Part No. Customer Project No. | 480 Pcs. Planned Delivery Time Ø 8 Weeks Available (from stock) | (at least 5 or mul. of 5) | Red Frequency | SMD Crystal | Ceramic case | 12.0 MHz | 20 ppm | 20.0 pF | ±5 ppm/Jahr | -20.0 °C | 70.0 °C | 3.4 mm | 2.7 mm | 0.75 mm | |||||||
372 | Manufacturers Part No. Q22FA1280051712(Q22FA12800517) Epson SMD Crystal FA-128 Plastic housing 32MHz 10ppm 2mm x 1,6mm x 0,5mm 6pF | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 16 Weeks Available on order | (at least 1000 or mul. of 1000) | Epson | SMD Crystal | Plastic housing | 32.0 MHz | 10 ppm | 6.0 pF | 1 ppm/Jahr | 100 µW | -40.0 °C | 85.0 °C | 2.0 mm | 1.6 mm | 0.5 mm | ||||||
373 | Manufacturers Part No. Q22FA1280002512(Q22FA12800025) Epson SMD Crystal FA-128 Plastic housing 32MHz 10ppm 2mm x 1,6mm x 0,5mm 8pF | Customer Part No. Customer Project No. | 450 Pcs. Planned Delivery Time Ø 16 Weeks Available (from stock) | (at least 10 or mul. of 10) | Epson | SMD Crystal | Plastic housing | 32.0 MHz | 10 ppm | 8.0 pF | 1 ppm/Jahr | 100 µW | -40.0 °C | 85.0 °C | 2.0 mm | 1.6 mm | 0.5 mm | ||||||
374 | Manufacturers Part No. Q22FA1280001114(FA128-26) Epson SMD Crystal FA-128 Plastic housing 26MHz 10ppm 2mm x 1,6mm x 0,5mm 10pF | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 16 Weeks Available on order | (at least 1000 or mul. of 1000) | Epson | SMD Crystal | Plastic housing | 26.0 MHz | 10 ppm | 10.0 pF | 1 ppm/Jahr | 100 µW | -40.0 °C | 85.0 °C | 2.0 mm | 1.6 mm | 0.5 mm | ||||||
375 | Manufacturers Part No. Q22FA1280001412(Q22FA12800014) Epson SMD Crystal FA-128 Plastic housing 24MHz 30ppm 2mm x 1,6mm x 0,5mm 16pF | Customer Part No. Customer Project No. | 250 Pcs. Planned Delivery Time Ø 16 Weeks Available (from stock) | (at least 5 or mul. of 5) | Epson | SMD Crystal | Plastic housing | 24.0 MHz | 30 ppm | 16.0 pF | 5 ppm/Jahr | 100 µW | -40.0 °C | 85.0 °C | 2.0 mm | 1.6 mm | 0.5 mm |
