Results (570)
Not discontinued
In stock
RoHS compliant
Datasheet
New
| Show Selected | Image | Part No. | Indiv. Part No. | Manufacturer | Price | Availability | Quantity | Series | Data Sheet | RoHS | Manufacturer | Type | Package/Case | Frequency | Frequency tolerance | Load capacity | Ageing, max. | Load, max. | Operating Temperature Min. | Operating Temperature Max. | Dimension: Length | Dimension: Width | Dimension: Height |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
276 | Manufacturers Part No. IC13025.000M20.0CE1B(IC13M25.0) Red Frequency SMD Crystal IC 13 Ceramic case 25MHz 20ppm 3,4mm x 2,7mm x 0,75mm 20pF | Customer Part No. Customer Project No. | 4.925 Pcs. Planned Delivery Time Ø 8 Weeks Available (from stock) | (at least 5 or mul. of 5) | Red Frequency | SMD Crystal | Ceramic case | 25.0 MHz | 20 ppm | 20.0 pF | ±5 ppm/Jahr | -20.0 °C | 70.0 °C | 3.4 mm | 2.7 mm | 0.75 mm | |||||||
277 | Manufacturers Part No. IC21020.000M30.0EE1B(IC21SMD20) Red Frequency SMD Crystal IC 21 Metal housing 20MHz ±30ppm 13,3mm x 5mm x 4mm 30pF | Customer Part No. Customer Project No. | 1.200 Pcs. Planned Delivery Time Ø 8 Weeks Available (from stock) | (at least 10 or mul. of 10) | Red Frequency | SMD Crystal | Metal housing | 20.0 MHz | ±30 ppm | 30.0 pF | ±3 ppm/Jahr | 1,0 mW | -20.0 °C | 70.0 °C | 13.3 mm | 5.0 mm | 4.0 mm | ||||||
278 | Manufacturers Part No. IC21006.000M30.0EE1B(IC21SMD6) Red Frequency SMD Crystal IC 21 Metal housing 6MHz ±30ppm 13,3mm x 5mm x 4mm 30pF | Customer Part No. Customer Project No. | 3.090 Pcs. Planned Delivery Time Ø 8 Weeks Available (from stock) | (at least 10 or mul. of 10) | Red Frequency | SMD Crystal | Metal housing | 6.0 MHz | ±30 ppm | 30.0 pF | ±3 ppm/Jahr | 1,0 mW | -20.0 °C | 70.0 °C | 13.3 mm | 5.0 mm | 4.0 mm | ||||||
279 | Manufacturers Part No. 49SX3SMD4-14.7456M-AF-30/30(49SX3SMD4-14.7456M) Abundance SMD Crystal 49SX3SMD4 Plastic housing 14,7456MHz ±50ppm 12,5mm x 4,85mm x 5mm 16pF | Customer Part No. Customer Project No. | 4.275 Pcs. Planned Delivery Time Ø 10 Weeks Available (from stock) | (at least 5 or mul. of 5) | Abundance | SMD Crystal | Plastic housing | 14.7456 MHz | ±50 ppm | 16.0 pF | ±5 ppm/Jahr | 500 µW | -20.0 °C | 70.0 °C | 12.5 mm | 4.85 mm | 5.0 mm | ||||||
280 | Manufacturers Part No. Q22FA1280053012(Q22FA12800530) Epson SMD Crystal FA-128 Plastic housing 32MHz 10ppm 2mm x 1,6mm x 0,5mm 10pF | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 16 Weeks Available on order | (at least 1000 or mul. of 1000) | Epson | SMD Crystal | Plastic housing | 32.0 MHz | 10 ppm | 10.0 pF | 1 ppm/Jahr | 100 µW | -40.0 °C | 85.0 °C | 2.0 mm | 1.6 mm | 0.5 mm | ||||||
281 | Manufacturers Part No. Q22FA1280060212(Q22FA1280060212) Epson SMD Crystal FA-128 Plastic housing 25MHz 10ppm 2mm x 1,6mm x 0,5mm 10pF | Customer Part No. Customer Project No. | 270 Pcs. Planned Delivery Time Ø 16 Weeks Available (from stock) | (at least 10 or mul. of 10) | Epson | SMD Crystal | Plastic housing | 25.0 MHz | 10 ppm | 10.0 pF | 100 µW | -40.0 °C | 85.0 °C | 2.0 mm | 1.6 mm | 0.5 mm | |||||||
282 | Manufacturers Part No. 49SX3SMD4-8M-AF-30/30(49SX3SMD4-8M) Abundance SMD Crystal 49SX3SMD4 Plastic housing 8MHz ±50ppm 12,5mm x 4,85mm x 5mm 16pF | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 13 Weeks Available on order | (at least 5000 or mul. of 5000) | Abundance | SMD Crystal | Plastic housing | 8.0 MHz | ±50 ppm | 16.0 pF | ±5 ppm/Jahr | 500 µW | -20.0 °C | 70.0 °C | 12.5 mm | 4.85 mm | 5.0 mm | ||||||
283 | Manufacturers Part No. Q22FA1280037412(Q22FA1280037412) Epson SMD Crystal FA-128 Plastic housing 27,12MHz 15ppm 2mm x 1,6mm x 0,5mm 6pF | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 16 Weeks Available on order | (at least 250 or mul. of 250) | Epson | SMD Crystal | Plastic housing | 27.12 MHz | 15 ppm | 6.0 pF | 100 µW | -40.0 °C | 85.0 °C | 2.0 mm | 1.6 mm | 0.5 mm | |||||||
284 | Manufacturers Part No. 49S4HSMD6.144M-AF-3030100R-16P(QSMD006.144) Abundance SMD Crystal HC49-S4-SMD Metal housing 6,144MHz ±30ppm 13mm x 4,73mm x 4,2mm 16pF | Customer Part No. Customer Project No. | 4.990 Pcs. Planned Delivery Time Ø 7 Weeks Available (from stock) | (at least 10 or mul. of 10) | Abundance | SMD Crystal | Metal housing | 6.144 MHz | ±30 ppm | 16.0 pF | ±5 ppm/Jahr | 1,0 mW | -10.0 °C | 60.0 °C | 13.0 mm | 4.73 mm | 4.2 mm | ||||||
285 | Manufacturers Part No. Q22FA1280034512(Q22FA12800345) Epson SMD Crystal FA-128 Plastic housing 50MHz 10ppm 2mm x 1,6mm x 0,5mm 8pF | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 16 Weeks Available on order | (at least 250 or mul. of 250) | Epson | SMD Crystal | Plastic housing | 50.0 MHz | 10 ppm | 8.0 pF | 1 ppm/Jahr | 100 µW | -40.0 °C | 85.0 °C | 2.0 mm | 1.6 mm | 0.5 mm | ||||||
286 | Manufacturers Part No. 49S4HSMD12.288M-AF3030-50R-30P(QSMD012.288) Abundance SMD Crystal HC49-S4-SMD Metal housing 12,228MHz ±30ppm 13mm x 4,73mm x 4,2mm 30pF | Customer Part No. Customer Project No. | 2.420 Pcs. Planned Delivery Time Ø 15 Weeks Available (from stock) | (at least 10 or mul. of 10) | Abundance | SMD Crystal | Metal housing | 12.228 MHz | ±30 ppm | 30.0 pF | ±5 ppm/Jahr | 1,0 mW | -10.0 °C | 60.0 °C | 13.0 mm | 4.73 mm | 4.2 mm | ||||||
287 | Manufacturers Part No. 49SX3SMD4-12M-AF-30/30(49SX3SMD4-12M) Abundance SMD Crystal 49SX3SMD4 Plastic housing 12MHz ±50ppm 12,5mm x 4,85mm x 5mm 16pF | Customer Part No. Customer Project No. | 4.030 Pcs. Planned Delivery Time Ø 29 Weeks Available (from stock) | (at least 5 or mul. of 5) | Abundance | SMD Crystal | Plastic housing | 12.0 MHz | ±50 ppm | 16.0 pF | ±5 ppm/Jahr | 500 µW | -20.0 °C | 70.0 °C | 12.5 mm | 4.85 mm | 5.0 mm | ||||||
288 | Manufacturers Part No. 49SX3SMD4-16M-AF-30/30(49SX3SMD4-16M) Abundance SMD Crystal 49SX3SMD4 Plastic housing 16MHz ±50ppm 12,5mm x 4,85mm x 5mm 16pF | Customer Part No. Customer Project No. | 8.465 Pcs. Planned Delivery Time Ø 19 Weeks Available (from stock) | (at least 5 or mul. of 5) | Abundance | SMD Crystal | Plastic housing | 16.0 MHz | ±50 ppm | 16.0 pF | ±5 ppm/Jahr | 500 µW | -20.0 °C | 70.0 °C | 12.5 mm | 4.85 mm | 5.0 mm | ||||||
289 | Manufacturers Part No. 49SX3SMD4-4M-AF-30/30(49SX3SMD4-4M) Abundance SMD Crystal 49SX3SMD4 Plastic housing 4MHz ±50ppm 12,5mm x 4,85mm x 5mm 16pF | Customer Part No. Customer Project No. | 4.245 Pcs. Planned Delivery Time Ø 24 Weeks Available (from stock) | (at least 5 or mul. of 5) | Abundance | SMD Crystal | Plastic housing | 4.0 MHz | ±50 ppm | 16.0 pF | ±5 ppm/Jahr | 500 µW | -20.0 °C | 70.0 °C | 12.5 mm | 4.85 mm | 5.0 mm | ||||||
290 | Manufacturers Part No. IC23012.288M30.0EE1C(IC23TH12.288) Red Frequency Crystal, wired IC 23 Metal housing 12,228MHz ±30ppm 10,7mm x 4,3mm x 3,5mm 30pF | Customer Part No. Customer Project No. | 450 Pcs. Planned Delivery Time Ø 8 Weeks Available (from stock) | (at least 10 or mul. of 10) | Red Frequency | Crystal, wired | Metal housing | 12.228 MHz | ±30 ppm | 30.0 pF | ±3 ppm/Jahr | 500 µW | -10.0 °C | 60.0 °C | 10.7 mm | 4.3 mm | 3.5 mm | ||||||
291 | Manufacturers Part No. IC2304.433619M16EE1C(IC23TH4.433619) Red Frequency Crystal, wired IC23 Metal housing 4,433619MHz ±30ppm 10,7mm x 4,3mm x 3,5mm 16pF | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 8 Weeks Available on order | (at least 500 or mul. of 500) | Red Frequency | Crystal, wired | Metal housing | 4.433619 MHz | ±30 ppm | 16.0 pF | ±3 ppm/Jahr | 500 µW | -10.0 °C | 60.0 °C | 10.7 mm | 4.3 mm | 3.5 mm | ||||||
292 | Manufacturers Part No. 49S4H-9.8304M-AF-30/30-80R-30R(QMIM009.830) Abundance Miniature Crystal HC49/U-S Metal housing 9,8304MHz ±50ppm 3,8mm x 11,05mm x 3,5mm 30pF | Customer Part No. Customer Project No. | 4.320 Pcs. Planned Delivery Time Ø 29 Weeks Available (from stock) | (at least 10 or mul. of 10) | Abundance | Miniature Crystal | Metal housing | 9.8304 MHz | ±50 ppm | 30.0 pF | ±5 ppm/Jahr | 1,0 mW | -10.0 °C | 60.0 °C | 3.8 mm | 11.05 mm | 3.5 mm | ||||||
293 | Manufacturers Part No. Q22FA2380019414(FA238-25) Epson SMD Crystal FA-238 Plastic housing 25MHz 50ppm 3,2mm x 2,5mm x 0,7mm | Customer Part No. Customer Project No. | 2.630 Pcs. Planned Delivery Time Ø 16 Weeks Available (from stock) | (at least 10 or mul. of 10) | Epson | SMD Crystal | Plastic housing | 25.0 MHz | 50 ppm | 5 ppm/Jahr | 200 µW | -40.0 °C | 85.0 °C | 3.2 mm | 2.5 mm | 0.7 mm | |||||||
294 | Manufacturers Part No. IC24012.000M30.0DE1B(IC24TH12.0) Red Frequency Crystal, wired IC 24 Metal housing 12MHz 25ppm 10,7mm x 4,3mm x 2,8mm 30pF | Customer Part No. Customer Project No. | 190 Pcs. Planned Delivery Time Ø 8 Weeks Available (from stock) | (at least 10 or mul. of 10) | Red Frequency | Crystal, wired | Metal housing | 12.0 MHz | 25 ppm | 30.0 pF | ±3 ppm/Jahr | 500 µW | -20.0 °C | 70.0 °C | 10.7 mm | 4.3 mm | 2.8 mm | ||||||
295 | Manufacturers Part No. IC13026.000M20.0CE1B(IC13M26.0) Red Frequency SMD Crystal IC 13 Ceramic case 26MHz 20ppm 3,4mm x 2,7mm x 0,75mm 20pF | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 8 Weeks Available on order | (at least 1000 or mul. of 1000) | Red Frequency | SMD Crystal | Ceramic case | 26.0 MHz | 20 ppm | 20.0 pF | ±5 ppm/Jahr | -20.0 °C | 70.0 °C | 3.4 mm | 2.7 mm | 0.75 mm | |||||||
296 | Manufacturers Part No. Q22FA1280046712(Q22FA12800467) Epson SMD Crystal FA-128 Plastic housing 24MHz 10ppm 2mm x 1,6mm x 0,5mm 8pF | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 16 Weeks Available on order | (at least 250 or mul. of 250) | Epson | SMD Crystal | Plastic housing | 24.0 MHz | 10 ppm | 8.0 pF | 1 ppm/Jahr | 100 µW | -40.0 °C | 85.0 °C | 2.0 mm | 1.6 mm | 0.5 mm | ||||||
297 | Manufacturers Part No. IC2307.3728M32.0EE1C(IC23TH7.3728) Red Frequency Crystal, wired IC 23 Metal housing 7,3728MHz ±30ppm 10,7mm x 4,3mm x 3,5mm 32pF | Customer Part No. Customer Project No. | 980 Pcs. Planned Delivery Time Ø 8 Weeks Available (from stock) | (at least 10 or mul. of 10) | Red Frequency | Crystal, wired | Metal housing | 7.3728 MHz | ±30 ppm | 32.0 pF | ±3 ppm/Jahr | 500 µW | -10.0 °C | 60.0 °C | 10.7 mm | 4.3 mm | 3.5 mm | ||||||
298 | Manufacturers Part No. IC2303.579545M16EE1C(IC23TH3.579545) Red Frequency Crystal, wired IC 23 Metal housing 3,579545MHz ±30ppm 10,7mm x 4,3mm x 3,5mm 16pF | Customer Part No. Customer Project No. | 480 Pcs. Planned Delivery Time Ø 8 Weeks Available (from stock) | (at least 10 or mul. of 10) | Red Frequency | Crystal, wired | Metal housing | 3.579545 MHz | ±30 ppm | 16.0 pF | ±3 ppm/Jahr | 500 µW | -10.0 °C | 60.0 °C | 10.7 mm | 4.3 mm | 3.5 mm | ||||||
299 | Manufacturers Part No. 49S4H12.0000M-AF-30/30-60R-30R(QMIM012) Abundance Miniature Crystal HC49/U-S Metal housing 12MHz ±50ppm 3,8mm x 11,05mm x 3,5mm 30pF | Customer Part No. Customer Project No. | 7.570 Pcs. Planned Delivery Time Ø 29 Weeks Available (from stock) | (at least 10 or mul. of 10) | Abundance | Miniature Crystal | Metal housing | 12.0 MHz | ±50 ppm | 30.0 pF | ±5 ppm/Jahr | 1,0 mW | -10.0 °C | 60.0 °C | 3.8 mm | 11.05 mm | 3.5 mm | ||||||
300 | Manufacturers Part No. 49S4H-8.0000M-AF-30/30-90R-30R(QMIM008) Abundance Miniature Crystal HC49/U-S Metal housing 8MHz ±50ppm 3,8mm x 11,05mm x 3,5mm 30pF | Customer Part No. Customer Project No. | 12.420 Pcs. Planned Delivery Time Ø 21 Weeks Available (from stock) | (at least 10 or mul. of 10) | Abundance | Miniature Crystal | Metal housing | 8.0 MHz | ±50 ppm | 30.0 pF | ±5 ppm/Jahr | 1,0 mW | -10.0 °C | 60.0 °C | 3.8 mm | 11.05 mm | 3.5 mm |
