Results (826)
RoHS compliant
Datasheet
New
In stock
Sale
Not discontinued
| Show Selected | Image | Part No. | Indiv. Part No. | Manufacturer | Price | Availability | Quantity | Series | Data Sheet | RoHS | Manufacturer | Type | Product Family | Contact Type | Design | Housing | Alignment | Number of poles | Pitch | Contact Surface Input | Housing material | Colour | Coding | Locking Type | Connector Contact | Dimension: Width | Dimension: Height | Dimension: Depth | Operating Temperature Min. | Operating Temperature Max. | Rated current | Rated voltage DC |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
76 |  | Manufacturers Part No. 093-2-020-0-F-BS0(LPH20RA) Binder MPE Tray pin strip 093-2 Pin Box Header 2-row 90° 20 Pole Pitch2,54mm black vergoldet | Customer Part No. Customer Project No. | 2.560 Pcs. Planned Delivery Time Ø 18 Weeks Available (from stock) | (at least 10 or mul. of 10) | Binder MPE | Tray pin strip | 093 | Pin | Box Header | 2-row | 90° | 20 | 2.54 mm | vergoldet | High Temperature Thermoplast (TP) | black | yes | Solder | 22.86 mm | 9.0 mm | 14.02 mm | -40.0 °C | 105.0 °C | 3.0 A | 150.0 V DC | ||||||
77 | | Manufacturers Part No. 093-2-026-0-F-BS0(LPH26RA) Binder MPE Tray pin strip 093-2 Pin Box Header 2-row 90° 26 Pole Pitch2,54mm black vergoldet | Customer Part No. Customer Project No. | 1.520 Pcs. Available (from stock) | (at least 10 or mul. of 10) | Binder MPE | Tray pin strip | 093 | Pin | Box Header | 2-row | 90° | 26 | 2.54 mm | vergoldet | High Temperature Thermoplast (TP) | black | yes | Solder | 30.48 mm | 9.0 mm | 14.02 mm | -40.0 °C | 105.0 °C | 3.0 A | 150.0 V DC | ||||||
78 | | Manufacturers Part No. 093-2-040-0-F-BS0(LPH40RA) Binder MPE Tray pin strip 093-2 Pin Box Header 2-row 90° 40 Pole Pitch2,54mm black vergoldet | Customer Part No. Customer Project No. | 930 Pcs. Planned Delivery Time Ø 18 Weeks Available (from stock) | (at least 10 or mul. of 10) | Binder MPE | Tray pin strip | 093 | Pin | Box Header | 2-row | 90° | 40 | 2.54 mm | vergoldet | High Temperature Thermoplast (TP) | black | yes | Solder | 48.26 mm | 9.0 mm | 14.02 mm | -40.0 °C | 105.0 °C | 3.0 A | 150.0 V DC | ||||||
79 | | Manufacturers Part No. 093-1-010-0-F-BS0(LPH10S) Binder MPE Tray pin strip 093-1 Pin Box Header 2-row straight 10 Pole Pitch2,54mm black vergoldet TOP | Customer Part No. Customer Project No. | 20.420 Pcs. Available (from stock) | (at least 10 or mul. of 10) | Binder MPE | Tray pin strip | 093 | Pin | Box Header | 2-row | straight | 10 | 2.54 mm | vergoldet | High Temperature Thermoplast (TP) | black | yes | Solder | 20.36 mm | 12.0 mm | 9.0 mm | -40.0 °C | 105.0 °C | 3.0 A | 150.0 V DC | ||||||
80 | | Manufacturers Part No. 093-1-026-0-F-BS0(LPH26S) Binder MPE Tray pin strip 093-1 Pin Box Header 2-row straight 26 Pole Pitch2,54mm black vergoldet | Customer Part No. Customer Project No. | 5.020 Pcs. Available (from stock) | (at least 10 or mul. of 10) | Binder MPE | Tray pin strip | 093 | Pin | Box Header | 2-row | straight | 26 | 2.54 mm | vergoldet | High Temperature Thermoplast (TP) | black | yes | Solder | 40.68 mm | 12.0 mm | 9.0 mm | -40.0 °C | 105.0 °C | 3.0 A | 150.0 V DC | ||||||
81 | | Manufacturers Part No. 093-1-034-0-F-BS0(LPH34S) Binder MPE Tray pin strip 093-1 Pin Box Header 2-row straight 34 Pole Pitch2,54mm black vergoldet | Customer Part No. Customer Project No. | 5.060 Pcs. Planned Delivery Time Ø 18 Weeks Available (from stock) | (at least 10 or mul. of 10) | Binder MPE | Tray pin strip | 093 | Pin | Box Header | 2-row | straight | 34 | 2.54 mm | vergoldet | High Temperature Thermoplast (TP) | black | yes | Solder | 50.84 mm | 12.0 mm | 9.0 mm | -40.0 °C | 105.0 °C | 3.0 A | 150.0 V DC | ||||||
82 | | Manufacturers Part No. 3210-26RGOCBKOOA01(PSBZ26W) SHENZHEN JINLING ELECTRONICS Tray pin strip 3210XXR Pin Box Header 2-row 90° 26 Pole Pitch2,54mm black vergoldet | Customer Part No. Customer Project No. | 250 Pcs. Planned Delivery Time Ø 3 Weeks Available (from stock) | (at least 50 or mul. of 10) | SHENZHEN JINLING ELECTRONICS | Tray pin strip | Pin | Box Header | 2-row | 90° | 26 | 2.54 mm | vergoldet | Polyamide (PA) 6T | black | Solder | 73.64 mm | 13.86 mm | 11.9 mm | -40.0 °C | 105.0 °C | 3.0 A | 1000.0 V DC | ||||||||
83 | | Manufacturers Part No. SPMH14S-3000(PSL14) Speed Tray pin strip SPMHxxS Pin Box Header 2-row straight 14 Pole Pitch2,54mm gray vergoldet | Customer Part No. Customer Project No. | 910 Pcs. Planned Delivery Time Ø 2 Weeks Available (from stock) | (at least 5 or mul. of 5) | Speed | Tray pin strip | Pin | Box Header | 2-row | straight | 14 | 2.54 mm | vergoldet | Polybutylenterephthalat (PBT) 20% GF | gray | Lever | Solder | 37.2 mm | 29.5 mm | 8.6 mm | 25.0 °C | 85.0 °C | 1.0 A | 1000.0 V DC | |||||||
84 | | Manufacturers Part No. SPMH20S-3000(PSL20) Speed Tray pin strip SPMHxxS Pin Box Header 2-row straight 20 Pole Pitch2,54mm gray vergoldet | Customer Part No. Customer Project No. | 865 Pcs. Available (from stock) | (at least 5 or mul. of 5) | Speed | Tray pin strip | Pin | Box Header | 2-row | straight | 20 | 2.54 mm | vergoldet | Polybutylenterephthalat (PBT) 20% GF | gray | Lever | Solder | 44.9 mm | 29.5 mm | 8.6 mm | 25.0 °C | 85.0 °C | 1.0 A | 1000.0 V DC | |||||||
85 | | Manufacturers Part No. 092-2-014-0-F-KS0(SCL14) Binder MPE Tray pin strip 092-2 Pin Box Header 2-row straight 14 Pole Pitch2,54mm black vergoldet | Customer Part No. Customer Project No. | 1.493 Pcs. Planned Delivery Time Ø 18 Weeks Available (from stock) | (at least 11 or mul. of 11) | Binder MPE | Tray pin strip | 092 | Pin | Box Header | 2-row | straight | 14 | 2.54 mm | vergoldet | Thermoplast (TP) | black | yes | Latching lug | Solder | 37.2 mm | 30.8 mm | 8.3 mm | -40.0 °C | 105.0 °C | 3.0 A | 150.0 V DC | |||||
86 | | Manufacturers Part No. 3310-26SGOCBLA01(PSLZ26) SHENZHEN JINLING ELECTRONICS Tray pin strip 3310XXS Pin Box Header 2-row straight 26 Pole Pitch2,54mm black vergoldet | Customer Part No. Customer Project No. | 5.000 Pcs. Planned Delivery Time Ø 3 Weeks Available (from stock) | (at least 7 or mul. of 7) | SHENZHEN JINLING ELECTRONICS | Tray pin strip | Pin | Box Header | 2-row | straight | 26 | 2.54 mm | vergoldet | Polyamide (PA) 6T | black | Lever | Solder | 85.36 mm | 30.7 mm | 8.2 mm | -40.0 °C | 105.0 °C | 3.0 A | 1000.0 V DC | |||||||
87 | | Manufacturers Part No. 3210-34RGOCBKOOA01(PSBZ34W) SHENZHEN JINLING ELECTRONICS Tray pin strip 3210XXR Pin Box Header 2-row 90° 34 Pole Pitch2,54mm black vergoldet | Customer Part No. Customer Project No. | 740 Pcs. Planned Delivery Time Ø 3 Weeks Available (from stock) | (at least 50 or mul. of 10) | SHENZHEN JINLING ELECTRONICS | Tray pin strip | Pin | Box Header | 2-row | 90° | 34 | 2.54 mm | vergoldet | Polyamide (PA) 6T | black | Solder | 93.96 mm | 13.86 mm | 11.9 mm | -40.0 °C | 105.0 °C | 3.0 A | 1000.0 V DC | ||||||||
88 | | Manufacturers Part No. SPMH40S-3000(PSL40) Speed Tray pin strip SPMHxxS Pin Box Header 2-row straight 40 Pole Pitch2,54mm gray vergoldet | Customer Part No. Customer Project No. | 365 Pcs. Planned Delivery Time Ø 2 Weeks Available (from stock) | (at least 5 or mul. of 5) | Speed | Tray pin strip | Pin | Box Header | 2-row | straight | 40 | 2.54 mm | vergoldet | Polybutylenterephthalat (PBT) 20% GF | gray | Lever | Solder | 70.3 mm | 29.5 mm | 8.6 mm | 25.0 °C | 85.0 °C | 1.0 A | 1000.0 V DC | |||||||
89 | | Manufacturers Part No. 092-2-020-0-F-KS0(SCL20) Binder MPE Tray pin strip 092-2 Pin Box Header 2-row straight 20 Pole Pitch2,54mm black vergoldet | Customer Part No. Customer Project No. | 6.444 Pcs. Planned Delivery Time Ø 18 Weeks Available (from stock) | (at least 12 or mul. of 12) | Binder MPE | Tray pin strip | 092 | Pin | Box Header | 2-row | straight | 20 | 2.54 mm | vergoldet | Thermoplast (TP) | black | yes | Latching lug | Solder | 44.9 mm | 30.8 mm | 8.3 mm | -40.0 °C | 105.0 °C | 3.0 A | 150.0 V DC | |||||
90 | | Manufacturers Part No. 3310-34SGOCBLA01(PSLZ34) SHENZHEN JINLING ELECTRONICS Tray pin strip 3310XXS Pin Box Header 2-row straight 34 Pole Pitch2,54mm black vergoldet | Customer Part No. Customer Project No. | 790 Pcs. Planned Delivery Time Ø 3 Weeks Available (from stock) | (at least 7 or mul. of 7) | SHENZHEN JINLING ELECTRONICS | Tray pin strip | Pin | Box Header | 2-row | straight | 34 | 2.54 mm | vergoldet | Polyamide (PA) 6T | black | Lever | Solder | 105.68 mm | 30.7 mm | 8.2 mm | -40.0 °C | 105.0 °C | 3.0 A | 1000.0 V DC | |||||||
91 | | Manufacturers Part No. SPMH26S-3000(PSL26) Speed Tray pin strip SPMHxxS Pin Box Header 2-row straight 26 Pole Pitch2,54mm gray vergoldet | Customer Part No. Customer Project No. | 1.100 Pcs. Available (from stock) | (at least 5 or mul. of 5) | Speed | Tray pin strip | Pin | Box Header | 2-row | straight | 26 | 2.54 mm | vergoldet | Polybutylenterephthalat (PBT) 20% GF | gray | Lever | Solder | 52.5 mm | 29.5 mm | 8.6 mm | 25.0 °C | 85.0 °C | 1.0 A | 1000.0 V DC | |||||||
92 | | Manufacturers Part No. 3310-20SGOCBLA01(PSLZ20) SHENZHEN JINLING ELECTRONICS Tray pin strip 3310XXS Pin Box Header 2-row straight 20 Pole Pitch2,54mm black vergoldet | Customer Part No. Customer Project No. | 180 Pcs. Planned Delivery Time Ø 3 Weeks Available (from stock) | (at least 9 or mul. of 9) | SHENZHEN JINLING ELECTRONICS | Tray pin strip | Pin | Box Header | 2-row | straight | 20 | 2.54 mm | vergoldet | Polyamide (PA) 6T | black | Lever | Solder | 70.12 mm | 30.7 mm | 8.2 mm | -40.0 °C | 105.0 °C | 3.0 A | 1000.0 V DC | |||||||
93 | | Manufacturers Part No. 3310-40SGOCBLA01(PSLZ40) SHENZHEN JINLING ELECTRONICS Tray pin strip 3310XXS Pin Box Header 2-row straight 40 Pole Pitch2,54mm black vergoldet | Customer Part No. Customer Project No. | 4.690 Pcs. Planned Delivery Time Ø 3 Weeks Available (from stock) | (at least 50 or mul. of 10) | SHENZHEN JINLING ELECTRONICS | Tray pin strip | Pin | Box Header | 2-row | straight | 40 | 2.54 mm | vergoldet | Polyamide (PA) 6T | black | Lever | Solder | 120.92 mm | 30.7 mm | 8.2 mm | -40.0 °C | 105.0 °C | 3.0 A | 1000.0 V DC | |||||||
94 | | Manufacturers Part No. 088-1-050-0-F-XS0-1080(ASL050GW) Binder MPE Pin header 088-1 Pin Header 1-row 90° 50 Pole Pitch2,54mm black vergoldet TOP | Customer Part No. Customer Project No. | 3.340 Pcs. Available (from stock) | (at least 10 or mul. of 10) | Binder MPE | Pin header | 088 | Pin | Header | 1-row | 90° | 50 | 2.54 mm | vergoldet | High Temperature Thermoplast (TP) | black | no | Solder | 127.0 mm | 5.8 mm | 10.8 mm | -40.0 °C | 105.0 °C | 3.0 A | 250.0 V DC | ||||||
95 | | Manufacturers Part No. 088-1-050-0-S-XS0-1080(ASL050TGW) Binder MPE Pin header 088-1 Pin Header 1-row 90° 50 Pole Pitch2,54mm black selektiv vergoldet % | Customer Part No. Customer Project No. | 460 Pcs. Planned Delivery Time Ø 17 Weeks Available (from stock) | (at least 10 or mul. of 10) | Binder MPE | Pin header | 088 | Pin | Header | 1-row | 90° | 50 | 2.54 mm | selektiv vergoldet | High Temperature Thermoplast (TP) | black | no | Solder | 127.0 mm | 5.8 mm | 10.8 mm | -40.0 °C | 105.0 °C | 3.0 A | 250.0 V DC | ||||||
96 | | Manufacturers Part No. 088-1-050-0-T-XS0-1080(ASL050ZW) Binder MPE Pin header 088-1 Pin Header 1-row 90° 50 Pole Pitch2,54mm black verzinnt TOP | Customer Part No. Customer Project No. | 1.250 Pcs. Available (from stock) | (at least 10 or mul. of 10) | Binder MPE | Pin header | 088 | Pin | Header | 1-row | 90° | 50 | 2.54 mm | verzinnt | High Temperature Thermoplast (TP) | black | no | Solder | 127.0 mm | 5.8 mm | 10.8 mm | -40.0 °C | 105.0 °C | 3.0 A | 250.0 V DC | ||||||
97 | | Manufacturers Part No. 088-2-100-0-F-XS0-1080(ASL100GW) Binder MPE Pin header 088-2 Pin Header 2-row 90° 100 Pole Pitch2,54mm black vergoldet | Customer Part No. Customer Project No. | 2.740 Pcs. Planned Delivery Time Ø 17 Weeks Available (from stock) | (at least 10 or mul. of 10) | Binder MPE | Pin header | 088 | Pin | Header | 2-row | 90° | 100 | 2.54 mm | vergoldet | High Temperature Thermoplast (TP) | black | no | Solder | 127.0 mm | 8.3 mm | 13.66 mm | -40.0 °C | 105.0 °C | 3.0 A | 250.0 V DC | ||||||
98 | | Manufacturers Part No. 150-1-020-0-S-XS0-0835(MSL120TG) Binder MPE Pin header 150-1 Pin Header 1-row straight 20 Pole Pitch2mm black selektiv vergoldet % | Customer Part No. Customer Project No. | 1.750 Pcs. Planned Delivery Time Ø 21 Weeks Available (from stock) | (at least 10 or mul. of 10) | Binder MPE | Pin header | 150 | Pin | Header | 1-row | straight | 20 | 2.0 mm | selektiv vergoldet | High Temperature Thermoplast (TP) | black | no | Solder | 40.0 mm | 8.35 mm | 2.0 mm | -40.0 °C | 105.0 °C | 1.5 A | 150.0 V DC | ||||||
99 | | Manufacturers Part No. 150-2-040-0-F-XS0-0870(SPH040MG) Binder MPE Pin header 150-2 Pin Header 1-row straight 40 Pole Pitch2mm black vergoldet | Customer Part No. Customer Project No. | 6.240 Pcs. Planned Delivery Time Ø 21 Weeks Available (from stock) | (at least 10 or mul. of 10) | Binder MPE | Pin header | 150 | Pin | Header | 1-row | straight | 40 | 2.0 mm | vergoldet | High Temperature Thermoplast (TP) | black | no | Solder | 80.0 mm | 8.7 mm | 2.0 mm | -40.0 °C | 105.0 °C | 1.5 A | 150.0 V DC | ||||||
100 | | Manufacturers Part No. 150-4-080-0-F-XS0-0870(SPH080MG) Binder MPE Pin header 150-4 Pin Header 2-row straight 80 Pole Pitch2mm black vergoldet | Customer Part No. Customer Project No. | 0 Pcs. Available (from stock) | (at least 10 or mul. of 10) | Binder MPE | Pin header | 150 | Pin | Header | 2-row | straight | 80 | 2.0 mm | vergoldet | High Temperature Thermoplast (TP) | black | no | Solder | 80.0 mm | 8.7 mm | 4.0 mm | -40.0 °C | 105.0 °C | 1.5 A | 150.0 V DC |
