Results (906)
RoHS compliant
Datasheet
New
In stock
Sale
Not discontinued
| Show Selected | Image | Part No. | Indiv. Part No. | Manufacturer | Price | Availability | Quantity | Series | Data Sheet | RoHS | Manufacturer | Type | Contact Type | Specifications | Locking Type | Housing | Alignment | Number of poles | Pitch | Contact Material Input | Contact Surface Input | Housing material | Colour | Connector Contact | Connector Material | Connector Coating | Strain Relief | Conductor cross-section, min. | Conductor cross-section (AWG), min. | Conductor cross-section, max. | Conductor cross-section (AWG), max. | Rated current | Operating Temperature Min. | Operating Temperature Max. | Test voltage |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
301 |  | Manufacturers Part No. 2091-1405(2091-1405) WAGO Box header 2091 Pin Box Header 1-row straight 5 Pole Pitch3,5mm light gray 160VAC | Customer Part No. Customer Project No. | 75 Pcs. Planned Delivery Time Ø 2 Weeks Available (from stock) | (at least 5 or mul. of 5) | WAGO | Box header | Pin | Box Header | 1-row | straight | 5 | 3.5 mm | Electrolytic copper | verzinnt | Polyphthalamid (PPA) GF | light gray | Solder | Electrolytic copper | Tinned | no | 10.0 A | -60.0 °C | 100.0 °C | 2500.0 V AC | ||||||||||
302 | | Manufacturers Part No. 2091-1422(2091-1422) WAGO Box header 2091 Pin Box Header 1-row angled 2 Pole Pitch3,5mm light gray 160VAC | Customer Part No. Customer Project No. | 125 Pcs. Planned Delivery Time Ø 2 Weeks Available (from stock) | (at least 5 or mul. of 5) | WAGO | Box header | Pin | Box Header | 1-row | angled | 2 | 3.5 mm | Electrolytic copper | verzinnt | Polyphthalamid (PPA) GF | light gray | Solder | Electrolytic copper | Tinned | no | 10.0 A | -60.0 °C | 100.0 °C | 2500.0 V AC | ||||||||||
303 | | Manufacturers Part No. 2091-1425(2091-1425) WAGO Box header 2091 Pin Box Header 1-row angled 5 Pole Pitch3,5mm light gray 160VAC | Customer Part No. Customer Project No. | 195 Pcs. Planned Delivery Time Ø 2 Weeks Available (from stock) | (at least 5 or mul. of 5) | WAGO | Box header | Pin | Box Header | 1-row | angled | 5 | 3.5 mm | Electrolytic copper | verzinnt | Polyphthalamid (PPA) GF | light gray | Solder | Electrolytic copper | Tinned | no | 10.0 A | -60.0 °C | 100.0 °C | 2500.0 V AC | ||||||||||
304 | | Manufacturers Part No. 733-102(733-102) WAGO PCB connector 733 Spring Header 1-row straight 2 Pole Pitch2,5mm light gray 160VAC | Customer Part No. Customer Project No. | 475 Pcs. Planned Delivery Time Ø 2 Weeks Available (from stock) | (at least 5 or mul. of 5) | WAGO | PCB connector | Spring | Header | 1-row | straight | 2 | 2.5 mm | Copper alloy | verzinnt | Polyamide (PA) 66 | light gray | Cage clamp | Copper alloy | Tinned | no | 28.0 AWG | 20.0 AWG | 6.0 A | -60.0 °C | 100.0 °C | 2500.0 V AC | ||||||||
305 | | Manufacturers Part No. 733-108(733-108) WAGO PCB connector 733 Spring Header 1-row straight 8 Pole Pitch2,5mm light gray 160VAC | Customer Part No. Customer Project No. | 260 Pcs. Planned Delivery Time Ø 2 Weeks Available (from stock) | (at least 5 or mul. of 5) | WAGO | PCB connector | Spring | Header | 1-row | straight | 8 | 2.5 mm | Copper alloy | verzinnt | Polyamide (PA) 66 | light gray | Cage clamp | Copper alloy | Tinned | no | 28.0 AWG | 20.0 AWG | 6.0 A | -60.0 °C | 100.0 °C | 2500.0 V AC | ||||||||
306 | | Manufacturers Part No. 733-112(733-112) WAGO PCB connector 733 Spring Header 1-row straight 12 Pole Pitch2,5mm light gray 160VAC | Customer Part No. Customer Project No. | 30 Pcs. Planned Delivery Time Ø 2 Weeks Available (from stock) | (at least 5 or mul. of 5) | WAGO | PCB connector | Spring | Header | 1-row | straight | 12 | 2.5 mm | Copper alloy | verzinnt | Polyamide (PA) 66 | light gray | Cage clamp | Copper alloy | Tinned | no | 28.0 AWG | 20.0 AWG | 6.0 A | -60.0 °C | 100.0 °C | 2500.0 V AC | ||||||||
307 | | Manufacturers Part No. 733-362(733-362) WAGO Box header 733 Pin Box Header 1-row angled 2 Pole Pitch2,5mm light gray 160VAC | Customer Part No. Customer Project No. | 320 Pcs. Planned Delivery Time Ø 6 Weeks Available (from stock) | (at least 5 or mul. of 5) | WAGO | Box header | Pin | Box Header | 1-row | angled | 2 | 2.5 mm | Electrolytic copper | verzinnt | Polyamide (PA) 66 | light gray | Solder | Electrolytic copper | Tinned | no | 6.0 A | -60.0 °C | 100.0 °C | 2500.0 V AC | ||||||||||
308 | | Manufacturers Part No. 733-365(733-365) WAGO Box header 733 Pin Box Header 1-row angled 5 Pole Pitch2,5mm light gray 160VAC | Customer Part No. Customer Project No. | 360 Pcs. Planned Delivery Time Ø 2 Weeks Available (from stock) | (at least 5 or mul. of 5) | WAGO | Box header | Pin | Box Header | 1-row | angled | 5 | 2.5 mm | Electrolytic copper | verzinnt | Polyamide (PA) 66 | light gray | Solder | Electrolytic copper | Tinned | no | 6.0 A | -60.0 °C | 100.0 °C | 2500.0 V AC | ||||||||||
309 | | Manufacturers Part No. 733-372(733-372) WAGO Box header 733 Pin Box Header 1-row angled 12 Pole Pitch2,5mm light gray 160VAC | Customer Part No. Customer Project No. | 295 Pcs. Planned Delivery Time Ø 2 Weeks Available (from stock) | (at least 5 or mul. of 5) | WAGO | Box header | Pin | Box Header | 1-row | angled | 12 | 2.5 mm | Electrolytic copper | verzinnt | Polyamide (PA) 66 | light gray | Solder | Electrolytic copper | Tinned | no | 6.0 A | -60.0 °C | 100.0 °C | 2500.0 V AC | ||||||||||
310 | | Customer Part No. Customer Project No. | 700 Pcs. Planned Delivery Time Ø 2 Weeks Available (from stock) | (at least 100 or mul. of 100) | WAGO | Encoding element | Accessories | white | |||||||||||||||||||||||||||
311 | | Manufacturers Part No. 2EDGKB-5.08-02P-14-1000A(H)(2EDGKB-5.08-02P-14) DEGSON PCB connector 2EDGKB-5.08 Spring Header Latching lug 1-row 90° 2 Pole Pitch5,08mm green 320VAC | Customer Part No. Customer Project No. | 310 Pcs. Planned Delivery Time Ø 2 Weeks Available (from stock) | (at least 10 or mul. of 10) | DEGSON | PCB connector | Spring | Header | Latching lug | 1-row | 90° | 2 | 5.08 mm | Copper alloy | verzinnt | Polyamide (PA) 66 | green | Screw-cage clamp | Copper alloy | Tinned | no | 1.0 mm² | 28.0 AWG | 2.5 mm² | 12.0 AWG | 18.0 A | -40.0 °C | 105.0 °C | 4000.0 V AC | |||||
312 | | Manufacturers Part No. 2EDGKB-5.08-04P-14-1000A(H)(2EDGKB-5.08-04P-14) DEGSON PCB connector 2EDGKB-5.08 Spring Header Latching lug 1-row 90° 4 Pole Pitch5,08mm green 320VAC | Customer Part No. Customer Project No. | 800 Pcs. Planned Delivery Time Ø 2 Weeks Available (from stock) | (at least 10 or mul. of 10) | DEGSON | PCB connector | Spring | Header | Latching lug | 1-row | 90° | 4 | 5.08 mm | Copper alloy | verzinnt | Polyamide (PA) 66 | green | Screw-cage clamp | Copper alloy | Tinned | no | 1.0 mm² | 28.0 AWG | 2.5 mm² | 12.0 AWG | 18.0 A | -40.0 °C | 105.0 °C | 4000.0 V AC | |||||
313 | | Manufacturers Part No. 2EDGKB-5.08-05P-14-1000A(H)(2EDGKB-5.08-05P-14) DEGSON PCB connector 2EDGKB-5.08 Spring Header Latching lug 1-row 90° 5 Pole Pitch5,08mm green 320VAC | Customer Part No. Customer Project No. | 1.080 Pcs. Planned Delivery Time Ø 2 Weeks Available (from stock) | (at least 10 or mul. of 10) | DEGSON | PCB connector | Spring | Header | Latching lug | 1-row | 90° | 5 | 5.08 mm | Copper alloy | verzinnt | Polyamide (PA) 66 | green | Screw-cage clamp | Copper alloy | Tinned | no | 1.0 mm² | 28.0 AWG | 2.5 mm² | 12.0 AWG | 18.0 A | -40.0 °C | 105.0 °C | 4000.0 V AC | |||||
314 | | Manufacturers Part No. 2EDGKB-5.08-06P-14-1000A(H)(2EDGKB-5.08-06P-14) DEGSON PCB connector 2EDGKB-5.08 Spring Header Latching lug 1-row 90° 6 Pole Pitch5,08mm green 320VAC | Customer Part No. Customer Project No. | 1.290 Pcs. Planned Delivery Time Ø 10 Weeks Available (from stock) | (at least 10 or mul. of 10) | DEGSON | PCB connector | Spring | Header | Latching lug | 1-row | 90° | 6 | 5.08 mm | Copper alloy | verzinnt | Polyamide (PA) 66 | green | Screw-cage clamp | Copper alloy | Tinned | no | 1.0 mm² | 28.0 AWG | 2.5 mm² | 12.0 AWG | 18.0 A | -40.0 °C | 105.0 °C | 4000.0 V AC | |||||
315 | | Manufacturers Part No. 2EDGKB-5.0-02P-14-1000A(H)(2EDGKB-5.0-02P-14) DEGSON PCB connector 2EDGKB-5.0 Spring Header Latching lug 1-row 90° 2 Pole Pitch5mm green 320VAC | Customer Part No. Customer Project No. | 1.490 Pcs. Planned Delivery Time Ø 10 Weeks Available (from stock) | (at least 10 or mul. of 10) | DEGSON | PCB connector | Spring | Header | Latching lug | 1-row | 90° | 2 | 5.0 mm | Copper alloy | verzinnt | Polyamide (PA) 66 | green | Screw-cage clamp | Copper alloy | Tinned | no | 1.0 mm² | 28.0 AWG | 2.5 mm² | 12.0 AWG | 18.0 A | -40.0 °C | 105.0 °C | 4000.0 V AC | |||||
316 | | Manufacturers Part No. 2EDGKB-5.0-05P-14-1000A(H)(2EDGKB-5.0-05P-14) DEGSON PCB connector 2EDGKB-5.0 Spring Header Latching lug 1-row 90° 5 Pole Pitch5mm green 320VAC | Customer Part No. Customer Project No. | 500 Pcs. Planned Delivery Time Ø 10 Weeks Available (from stock) | (at least 10 or mul. of 10) | DEGSON | PCB connector | Spring | Header | Latching lug | 1-row | 90° | 5 | 5.0 mm | Copper alloy | verzinnt | Polyamide (PA) 66 | green | Screw-cage clamp | Copper alloy | Tinned | no | 1.0 mm² | 28.0 AWG | 2.5 mm² | 12.0 AWG | 18.0 A | -40.0 °C | 105.0 °C | 4000.0 V AC | |||||
317 | | Manufacturers Part No. 832-1103(832-1103) WAGO PCB connector 832 Spring Header 1-row straight 3 Pole Pitch10,16mm light gray 1.000VAC | Customer Part No. Customer Project No. | 20 Pcs. Planned Delivery Time Ø 5 Weeks Available (from stock) | (at least 5 or mul. of 5) | WAGO | PCB connector | Spring | Header | 1-row | straight | 3 | 10.16 mm | Electrolytic copper | versilbert | Polybutylenterephthalat (PBT) | light gray | Cage clamp | Electrolytic copper | Silver-plated | no | 18.0 AWG | 4.0 AWG | 76.0 A | -60.0 °C | 120.0 °C | 8000.0 V AC | ||||||||
318 | | Manufacturers Part No. 832-1104(832-1104) WAGO PCB connector 832 Spring Header 1-row straight 4 Pole Pitch10,16mm light gray 1.000VAC | Customer Part No. Customer Project No. | 5 Pcs. Planned Delivery Time Ø 5 Weeks Available (from stock) | (at least 5 or mul. of 5) | WAGO | PCB connector | Spring | Header | 1-row | straight | 4 | 10.16 mm | Electrolytic copper | versilbert | Polybutylenterephthalat (PBT) | light gray | Cage clamp | Electrolytic copper | Silver-plated | no | 18.0 AWG | 4.0 AWG | 76.0 A | -60.0 °C | 120.0 °C | 8000.0 V AC | ||||||||
319 | | Manufacturers Part No. STLZ950/3-5.08-V-GRUEN(STLZ951-V3) PTR HARTMANN Box header STLZ950 Pin Box Header 1-row vertical 3 Pole Pitch5,08mm green Copper alloy | Customer Part No. Customer Project No. | 820 Pcs. Planned Delivery Time Ø 5 Weeks Available (from stock) | (at least 10 or mul. of 10) | PTR HARTMANN | Box header | Pin | Box Header | 1-row | vertical | 3 | 5.08 mm | Copper alloy | Polyamide (PA) 66 | green | Solder | Copper alloy | 12.0 A | -40.0 °C | 105.0 °C | 4.0 V AC | |||||||||||||
320 | | Manufacturers Part No. 832-1105(832-1105) WAGO PCB connector 832 Spring Header 1-row straight 5 Pole Pitch10,16mm light gray 1.000VAC | Customer Part No. Customer Project No. | 10 Pcs. Planned Delivery Time Ø 5 Weeks Available (from stock) | (at least 5 or mul. of 5) | WAGO | PCB connector | Spring | Header | 1-row | straight | 5 | 10.16 mm | Electrolytic copper | versilbert | Polybutylenterephthalat (PBT) | light gray | Cage clamp | Electrolytic copper | Silver-plated | no | 18.0 AWG | 4.0 AWG | 76.0 A | -60.0 °C | 120.0 °C | 8000.0 V AC | ||||||||
321 | | Manufacturers Part No. 832-1202(832-1202) WAGO Pin header 832 Pin Box Header 1-row horizontal 2 Pole Pitch10,16mm light gray 1.000VAC | Customer Part No. Customer Project No. | 0 Pcs. Available (from stock) | (at least 5 or mul. of 5) | WAGO | Pin header | Pin | Box Header | 1-row | horizontal | 2 | 10.16 mm | Electrolytic copper | versilbert | Polybutylenterephthalat (PBT) | light gray | Cage clamp | Electrolytic copper | Silver-plated | no | 18.0 AWG | 4.0 AWG | 76.0 A | -60.0 °C | 120.0 °C | 8000.0 V AC | ||||||||
322 | | Manufacturers Part No. 832-1203(832-1203) WAGO Pin header 832 Pin Box Header 1-row horizontal 3 Pole Pitch10,16mm light gray 1.000VAC | Customer Part No. Customer Project No. | 20 Pcs. Planned Delivery Time Ø 5 Weeks Available (from stock) | (at least 5 or mul. of 5) | WAGO | Pin header | Pin | Box Header | 1-row | horizontal | 3 | 10.16 mm | Electrolytic copper | versilbert | Polybutylenterephthalat (PBT) | light gray | Cage clamp | Electrolytic copper | Silver-plated | no | 18.0 AWG | 4.0 AWG | 76.0 A | -60.0 °C | 120.0 °C | 8000.0 V AC | ||||||||
323 | | Manufacturers Part No. STLZ950/3-5.08-H-GRUEN(STLZ951-H3) PTR HARTMANN Box header STLZ950 Pin Box Header 1-row horizontal 3 Pole Pitch5,08mm green Copper alloy | Customer Part No. Customer Project No. | 800 Pcs. Planned Delivery Time Ø 5 Weeks Available (from stock) | (at least 10 or mul. of 10) | PTR HARTMANN | Box header | Pin | Box Header | 1-row | horizontal | 3 | 5.08 mm | Copper alloy | Polyamide (PA) 66 | green | Solder | Copper alloy | 12.0 A | -40.0 °C | 105.0 °C | 4.0 V AC | |||||||||||||
324 | | Manufacturers Part No. 832-1204(832-1204) WAGO Pin header 832 Pin Box Header 1-row horizontal 4 Pole Pitch10,16mm light gray 1.000VAC | Customer Part No. Customer Project No. | 20 Pcs. Planned Delivery Time Ø 5 Weeks Available (from stock) | (at least 5 or mul. of 5) | WAGO | Pin header | Pin | Box Header | 1-row | horizontal | 4 | 10.16 mm | Electrolytic copper | versilbert | Polybutylenterephthalat (PBT) | light gray | Cage clamp | Electrolytic copper | Silver-plated | no | 18.0 AWG | 4.0 AWG | 76.0 A | -60.0 °C | 120.0 °C | 8000.0 V AC | ||||||||
325 | | Manufacturers Part No. STLZ950/3G-5.08-V-GRÜN-HC(STLZ950WV3-HC) PTR HARTMANN Box header STLZ950 Pin Box Header 1-row vertical 3 Pole Pitch5,08mm green Copper alloy | Customer Part No. Customer Project No. | 480 Pcs. Planned Delivery Time Ø 5 Weeks Available (from stock) | (at least 10 or mul. of 10) | PTR HARTMANN | Box header | Pin | Box Header | 1-row | vertical | 3 | 5.08 mm | Copper alloy | Polyamide (PA) 66 | green | Solder | Copper alloy | 16.0 A | -40.0 °C | 105.0 °C | 4.0 V AC |
