Results (841)
RoHS compliant
Datasheet
New
In stock
Sale
Not discontinued
| Show Selected | Image | Part No. | Indiv. Part No. | Manufacturer | Price | Availability | Quantity | Series | Data Sheet | RoHS | Manufacturer | Type | Product Family | Contact Type | Specifications | Housing | Alignment | Number of poles | Pitch | Contact Material Input | Contact Surface Input | Housing material | Colour | Coding | Locking Type | Connector Contact | Connector Material | Connector Coating | Dimension: Width | Dimension: Height | Dimension: Depth | Operating Temperature Min. | Operating Temperature Max. | Rated current | Rated voltage DC |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
376 |  | Manufacturers Part No. 2EDGVC-5.08-06P-14-100A(H)(2EDGVC-5.08-06P-14) DEGSON Box Header 2EDGVC-5.08 Pin Box Header 1-row straight 6 Pole Pitch5,08mm green Copper verzinnt | Customer Part No. Customer Project No. | 840 Pcs. Planned Delivery Time Ø 2 Weeks Available (from stock) | (at least 10 or mul. of 10) | DEGSON | Box Header | Pin | Box Header | 1-row | straight | 6 | 5.08 mm | Copper | verzinnt | Polyamide (PA) 66 | green | Solder | Copper | Tinned | 32.48 mm | 16.0 mm | 8.6 mm | -40.0 °C | 105.0 °C | 20.0 A | |||||||||
377 | | Manufacturers Part No. STL950/3G-5.0-V-GRUEN(STL950WV3) PTR HARTMANN Box Header STL950 Pin Box Header 1-row vertical 3 Pole Pitch5mm green Copper alloy | Customer Part No. Customer Project No. | 1.710 Pcs. Available (from stock) | (at least 10 or mul. of 10) | PTR HARTMANN | Box Header | STL950/..G-5.0-V-GREEN | Pin | Box Header | 1-row | vertical | 3 | 5.0 mm | Copper alloy | Polyamide (PA) 66 | green | codable | THT | Copper alloy | 16.2 mm | 15.9 mm | 8.4 mm | -40.0 °C | 105.0 °C | 12.0 A | |||||||||
378 | | Manufacturers Part No. 2EDGVC-5.0-05P-14-100A(H)(2EDGVC-5.0-05P-14) DEGSON Box Header 2EDGVC-5.0 Pin Box Header 1-row straight 5 Pole Pitch5,0mm green Copper verzinnt | Customer Part No. Customer Project No. | 2.590 Pcs. Planned Delivery Time Ø 10 Weeks Available (from stock) | (at least 10 or mul. of 10) | DEGSON | Box Header | Pin | Box Header | 1-row | straight | 5 | 5.0 mm | Copper | verzinnt | Polyamide (PA) 66 | green | Solder | Copper | Tinned | 27.0 mm | 16.0 mm | 8.6 mm | -40.0 °C | 105.0 °C | 20.0 A | |||||||||
379 | | Manufacturers Part No. STL950/6G-5.0-V-GRUEN(STL950WV6) PTR HARTMANN Box Header STL950 Pin Box Header 1-row vertical 6 Pole Pitch5mm green Copper alloy | Customer Part No. Customer Project No. | 1.170 Pcs. Available (from stock) | (at least 10 or mul. of 10) | PTR HARTMANN | Box Header | STL950/..G-5.0-V-GREEN | Pin | Box Header | 1-row | vertical | 6 | 5.0 mm | Copper alloy | Polyamide (PA) 66 | green | codable | THT | Copper alloy | 31.2 mm | 15.9 mm | 8.4 mm | -40.0 °C | 105.0 °C | 12.0 A | |||||||||
380 | | Manufacturers Part No. 2EDGVC-5.08-02P-14-100A(H)(2EDGVC-5.08-02P-14) DEGSON Box Header 2EDGVC-5.08 Pin Box Header 1-row straight 2 Pole Pitch5,08mm green Copper verzinnt | Customer Part No. Customer Project No. | 120 Pcs. Available (from stock) | (at least 10 or mul. of 10) | DEGSON | Box Header | Pin | Box Header | 1-row | straight | 2 | 5.08 mm | Copper | verzinnt | Polyamide (PA) 66 | green | Solder | Copper | Tinned | 12.16 mm | 16.0 mm | 8.6 mm | -40.0 °C | 105.0 °C | 20.0 A | |||||||||
381 | | Manufacturers Part No. DG332K-5.0-02P-12-00A(H)(DG332K-5.0-02P-12) DEGSON PCB connector DG332K-5.0 Socket Box Header 1-row 90° 2 Pole Pitch5mm Blue Copper alloy vernickelt | Customer Part No. Customer Project No. | 175 Pcs. Planned Delivery Time Ø 2 Weeks Available (from stock) | (at least 25 or mul. of 25) | DEGSON | PCB connector | Socket | Box Header | 1-row | 90° | 2 | 5.0 mm | Copper alloy | vernickelt | Polybutylenterephthalat (PBT) | Blue | Screw | Copper alloy | Nickel-plated | 10.0 mm | 10.8 mm | 13.4 mm | -30.0 °C | 120.0 °C | 12.0 A | |||||||||
382 | | Manufacturers Part No. STLZ950/2G-5.08-H-GRUEN(STLZ950WH2) PTR HARTMANN Box Header STLZ950 Pin Box Header 1-row horizontal 2 Pole Pitch5,08mm green Copper alloy | Customer Part No. Customer Project No. | 3.980 Pcs. Available (from stock) | (at least 10 or mul. of 10) | PTR HARTMANN | Box Header | STLZ950/..G-5.08-H-GREEN | Pin | Box Header | 1-row | horizontal | 2 | 5.08 mm | Copper alloy | Polyamide (PA) 66 | green | codable | THR | Copper alloy | 11.36 mm | 11.9 mm | 12.0 mm | -40.0 °C | 105.0 °C | 12.0 A | |||||||||
383 | | Manufacturers Part No. STLZ950/6G-5.08-H-GRUEN(STLZ950WH6) PTR HARTMANN Box Header STLZ950 Pin Box Header 1-row horizontal 6 Pole Pitch5,08mm green Copper alloy | Customer Part No. Customer Project No. | 0 Pcs. Available (from stock) | (at least 10 or mul. of 10) | PTR HARTMANN | Box Header | STLZ950/..G-5.08-H-GREEN | Pin | Box Header | 1-row | horizontal | 6 | 5.08 mm | Copper alloy | Polyamide (PA) 66 | green | codable | THR | Copper alloy | 31.68 mm | 11.9 mm | 12.0 mm | -40.0 °C | 105.0 °C | 12.0 A | |||||||||
384 | | Manufacturers Part No. STLZ950/4G-5.08-H-GRUEN-HC(STLZ950WH4-HC) PTR HARTMANN Box Header STLZ950 Pin Box Header 1-row horizontal 4 Pole Pitch5,08mm green Copper alloy | Customer Part No. Customer Project No. | 620 Pcs. Planned Delivery Time Ø 5 Weeks Available (from stock) | (at least 10 or mul. of 10) | PTR HARTMANN | Box Header | STLZ950/..G-5.08-H-GREEN-HC | Pin | Box Header | 1-row | horizontal | 4 | 5.08 mm | Copper alloy | Polyamide (PA) 66 | green | codable | THR | Copper alloy | 21.52 mm | 11.9 mm | 12.0 mm | -40.0 °C | 105.0 °C | 16.0 A | |||||||||
385 | | Manufacturers Part No. STLZ950/3G-5.08-H-GRUEN(STLZ950WH3) PTR HARTMANN Box Header STLZ950 Pin Box Header 1-row horizontal 3 Pole Pitch5,08mm green Copper alloy | Customer Part No. Customer Project No. | 1.030 Pcs. Available (from stock) | (at least 10 or mul. of 10) | PTR HARTMANN | Box Header | STLZ950/..G-5.08-H-GREEN | Pin | Box Header | 1-row | horizontal | 3 | 5.08 mm | Copper alloy | Polyamide (PA) 66 | green | codable | THR | Copper alloy | 16.44 mm | 11.9 mm | 12.0 mm | -40.0 °C | 105.0 °C | 12.0 A | |||||||||
386 | | Manufacturers Part No. STLZ950/3G-5.08-V-GRUEN(STLZ950WV3) PTR HARTMANN Box Header STLZ950 Pin Box Header 1-row vertical 3 Pole Pitch5,08mm green Copper alloy | Customer Part No. Customer Project No. | 690 Pcs. Available (from stock) | (at least 10 or mul. of 10) | PTR HARTMANN | Box Header | STLZ950/..G-5.08-V-GREEN | Pin | Box Header | 1-row | vertical | 3 | 5.08 mm | Copper alloy | Polyamide (PA) 66 | green | codable | THT | Copper alloy | 16.44 mm | 15.9 mm | 8.4 mm | -40.0 °C | 105.0 °C | 12.0 A | |||||||||
387 | | Manufacturers Part No. STLZ950/5G-5.08-H-GRUEN(STLZ950WH5) PTR HARTMANN Box Header STLZ950 Pin Box Header 1-row horizontal 5 Pole Pitch5,08mm green Copper alloy | Customer Part No. Customer Project No. | 3.250 Pcs. Available (from stock) | (at least 10 or mul. of 10) | PTR HARTMANN | Box Header | STLZ950/..G-5.08-H-GREEN | Pin | Box Header | 1-row | horizontal | 5 | 5.08 mm | Copper alloy | Polyamide (PA) 66 | green | codable | THR | Copper alloy | 26.6 mm | 11.9 mm | 12.0 mm | -40.0 °C | 105.0 °C | 12.0 A | |||||||||
388 | | Manufacturers Part No. STLZ950/4G-5.08-V-GRUEN(STLZ950WV4) PTR HARTMANN Box Header STLZ950 Pin Box Header 1-row vertical 4 Pole Pitch5,08mm green Copper alloy | Customer Part No. Customer Project No. | 0 Pcs. Available (from stock) | (at least 10 or mul. of 10) | PTR HARTMANN | Box Header | STLZ950/..G-5.08-V-GREEN | Pin | Box Header | 1-row | vertical | 4 | 5.08 mm | Copper alloy | Polyamide (PA) 66 | green | codable | THT | Copper alloy | 21.52 mm | 15.9 mm | 8.4 mm | -40.0 °C | 105.0 °C | 12.0 A | |||||||||
389 | | Manufacturers Part No. 115-3-072-0-MTF-XS0(115-3-072-0-MTF) Binder MPE Socket connector 115-3 Socket Header 2-row straight 72 Pole Pitch2,54mm black Copper alloy verzinnt | Customer Part No. Customer Project No. | 735 Pcs. Available (from stock) | (at least 5 or mul. of 5) | Binder MPE | Socket connector | 115 | Socket | Header | 2-row | straight | 72 | 2.54 mm | Copper alloy | verzinnt | High Temperature Thermoplast (TP) | black | no | Solder | Copper alloy | Tinned | 91.44 mm | 10.1 mm | 5.08 mm | -55.0 °C | 125.0 °C | 3.0 A | 150.0 V DC | ||||||
390 | | Manufacturers Part No. STLZ950/7-5.08-V-P2.6-BK-HTR(STLZ950/7-V-BK-HTG) PTR HARTMANN Box Header STLZ950 Pin Box Header 1-row vertical 7 Pole Pitch5,08mm black Copper alloy | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 5 Weeks Available on order | (at least 140 or mul. of 140) | PTR HARTMANN | Box Header | STLZ950/..-5.08-V-P2.6-BK-HT | Pin | Box Header | 1-row | vertical | 7 | 5.08 mm | Copper alloy | Polyphthalamid (PPA) | black | codable | THR | Copper alloy | 35.56 mm | 15.9 mm | 8.4 mm | -40.0 °C | 105.0 °C | 12.0 A | |||||||||
391 | | Manufacturers Part No. STLZ950/8-5.08-V-P2.6-BK-HTR(STLZ950/8-V-BK-HTG) PTR HARTMANN Box Header STLZ950 Pin Box Header 1-row vertical 8 Pole Pitch5,08mm black Copper alloy | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 5 Weeks Available on order | (at least 140 or mul. of 140) | PTR HARTMANN | Box Header | STLZ950/..-5.08-V-P2.6-BK-HT | Pin | Box Header | 1-row | vertical | 8 | 5.08 mm | Copper alloy | Polyphthalamid (PPA) | black | codable | THR | Copper alloy | 40.64 mm | 15.9 mm | 8.4 mm | -40.0 °C | 105.0 °C | 12.0 A | |||||||||
392 | | Manufacturers Part No. STLZ950/3-5.08-V-P2.6-BK-HTR(STLZ950/3-V-BK-HTG) PTR HARTMANN Box Header STLZ950 Pin Box Header 1-row vertical 3 Pole Pitch5,08mm black Copper alloy | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 5 Weeks Available on order | (at least 140 or mul. of 140) | PTR HARTMANN | Box Header | STLZ950/..-5.08-V-P2.6-BK-HT | Pin | Box Header | 1-row | vertical | 3 | 5.08 mm | Copper alloy | Polyphthalamid (PPA) | black | codable | THR | Copper alloy | 15.24 mm | 15.9 mm | 8.4 mm | -40.0 °C | 105.0 °C | 12.0 A | |||||||||
393 | | Manufacturers Part No. STLZ950/6-5.08-V-P2.6-BK-HTR(STLZ950/6-V-BK-HTG) PTR HARTMANN Box Header STLZ950 Pin Box Header 1-row vertical 6 Pole Pitch5,08mm black Copper alloy | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 5 Weeks Available on order | (at least 140 or mul. of 140) | PTR HARTMANN | Box Header | STLZ950/..-5.08-V-P2.6-BK-HT | Pin | Box Header | 1-row | vertical | 6 | 5.08 mm | Copper alloy | Polyphthalamid (PPA) | black | codable | THR | Copper alloy | 30.48 mm | 15.9 mm | 8.4 mm | -40.0 °C | 105.0 °C | 12.0 A | |||||||||
394 | | Manufacturers Part No. STLZ950/10-5.08-V-P2.6-BK-HT(STLZ950/10-V-BK-HT) PTR HARTMANN Box Header STLZ950 Pin Box Header 1-row vertical 10 Pole Pitch5,08mm black Copper alloy | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 5 Weeks Available on order | (at least 50 or mul. of 50) | PTR HARTMANN | Box Header | STLZ950/..-5.08-V-P2.6-BK-HT | Pin | Box Header | 1-row | vertical | 10 | 5.08 mm | Copper alloy | Polyphthalamid (PPA) | black | codable | THR | Copper alloy | 50.8 mm | 15.9 mm | 8.4 mm | -40.0 °C | 105.0 °C | 12.0 A | |||||||||
395 | | Manufacturers Part No. STLZ950/7F-5.08-V-P2.6-BK-HT(STLZ950/7F-V-BK-HT) PTR HARTMANN Box Header STLZ950 Pin Box Header 1-row vertical 7 Pole Pitch5,08mm black Copper alloy | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 5 Weeks Available on order | (at least 50 or mul. of 50) | PTR HARTMANN | Box Header | STLZ950/..F-5.08-V-P2.6-BK-HT | Pin | Box Header | 1-row | vertical | 7 | 5.08 mm | Copper alloy | Polyphthalamid (PPA) | black | codable | THR | Copper alloy | 45.72 mm | 15.9 mm | 8.4 mm | -40.0 °C | 105.0 °C | 12.0 A | |||||||||
396 | | Manufacturers Part No. STLZ950/3F-5.08-V-P2.6-BK-HT(STLZ950/3F-V-BK-HT) PTR HARTMANN Box Header STLZ950 Pin Box Header 1-row vertical 3 Pole Pitch5,08mm black Copper alloy | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 5 Weeks Available on order | (at least 100 or mul. of 100) | PTR HARTMANN | Box Header | STLZ950/..F-5.08-V-P2.6-BK-HT | Pin | Box Header | 1-row | vertical | 3 | 5.08 mm | Copper alloy | Polyphthalamid (PPA) | black | codable | THR | Copper alloy | 25.4 mm | 15.9 mm | 8.4 mm | -40.0 °C | 105.0 °C | 12.0 A | |||||||||
397 | | Manufacturers Part No. STLZ950/7G-5.08-V-P2.6-BK-HT(STLZ950/7G-V-BK-HT) PTR HARTMANN Box Header STLZ950 Pin Box Header 1-row vertical 7 Pole Pitch5,08mm black Copper alloy | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 5 Weeks Available on order | (at least 100 or mul. of 100) | PTR HARTMANN | Box Header | STLZ950/..G-5.08-V-P2.6-BK-HT | Pin | Box Header | 1-row | vertical | 7 | 5.08 mm | Copper alloy | Polyphthalamid (PPA) | black | codable | THR | Copper alloy | 36.76 mm | 14.6 mm | 8.4 mm | -40.0 °C | 105.0 °C | 12.0 A | |||||||||
398 | | Manufacturers Part No. STLZ950/5F-5.08-V-P2.6-BK-HT(STLZ950/5F-V-BK-HT) PTR HARTMANN Box Header STLZ950 Pin Box Header 1-row vertical 5 Pole Pitch5,08mm black Copper alloy | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 5 Weeks Available on order | (at least 100 or mul. of 100) | PTR HARTMANN | Box Header | STLZ950/..F-5.08-V-P2.6-BK-HT | Pin | Box Header | 1-row | vertical | 5 | 5.08 mm | Copper alloy | Polyphthalamid (PPA) | black | codable | THR | Copper alloy | 35.56 mm | 15.9 mm | 8.4 mm | -40.0 °C | 105.0 °C | 12.0 A | |||||||||
399 | | Manufacturers Part No. STLZ950/10G-5.08-V-P2.6-BK-HT(STLZ950/10G-V-BKHT) PTR HARTMANN Box Header STLZ950 Pin Box Header 1-row vertical 10 Pole Pitch5,08mm black Copper alloy | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 5 Weeks Available on order | (at least 50 or mul. of 50) | PTR HARTMANN | Box Header | STLZ950/..G-5.08-V-P2.6-BK-HT | Pin | Box Header | 1-row | vertical | 10 | 5.08 mm | Copper alloy | Polyphthalamid (PPA) | black | codable | THR | Copper alloy | 52.0 mm | 14.6 mm | 8.4 mm | -40.0 °C | 105.0 °C | 12.0 A | |||||||||
400 | | Manufacturers Part No. STLZ950/3G-5.08-V-P2.6-BK-HT(STLZ950/3G-V-BK-HT) PTR HARTMANN Box Header STLZ950 Pin Box Header 1-row vertical 3 Pole Pitch5,08mm black Copper alloy | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 5 Weeks Available on order | (at least 200 or mul. of 200) | PTR HARTMANN | Box Header | STLZ950/..G-5.08-V-P2.6-BK-HT | Pin | Box Header | 1-row | vertical | 3 | 5.08 mm | Copper alloy | Polyphthalamid (PPA) | black | codable | THR | Copper alloy | 16.44 mm | 14.6 mm | 8.4 mm | -40.0 °C | 105.0 °C | 12.0 A |
