| Show Selected | Image | Part No. | Indiv. Part No. | Manufacturer | Price | Availability | Quantity | Series | Data Sheet | RoHS | Manufacturer | Type | Colour | Material | Form of Delivery | Length of Shrink Tubing | Dimension: Length | Dimension: Width | Dimension: Height | Cable Ø min. | Cable Ø max. | Operating Temperature Min. | Operating Temperature Max. | Flammability | Approvals |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
01 |  | Manufacturers Part No. 1427BCGM16(1427BCGM16) Hammond 1427BCG Screwed cable gland brass, nickel-plated M16 x 1,5 silver 4mm 8mm New | Customer Part No. Customer Project No. | 4 Pcs. Planned Delivery Time Ø 2 Weeks Available (from stock) | (at least 1 or mul. of 1) | Hammond | Screwed cable gland | silver | brass, nickel-plated | 27.0 mm | 4.0 mm | 8.0 mm | -40.0 °C | 100.0 °C | UL | ||||||||||
02 | | Manufacturers Part No. 1427BCGM32(1427BCGM32) Hammond 1427BCG Screwed cable gland brass, nickel-plated M32 x 1,5 silver 18mm 25mm New | Customer Part No. Customer Project No. | 2 Pcs. Planned Delivery Time Ø 2 Weeks Available (from stock) | (at least 1 or mul. of 1) | Hammond | Screwed cable gland | silver | brass, nickel-plated | 39.0 mm | 18.0 mm | 25.0 mm | -40.0 °C | 100.0 °C | UL | ||||||||||
03 | | Manufacturers Part No. 1427BCGPG13(1427BCGPG13) Hammond 1427BCG Screwed cable gland brass, nickel-plated PG13 silver 6mm 12mm New | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 2 Weeks Available on order | (at least 1 or mul. of 1) | Hammond | Screwed cable gland | silver | brass, nickel-plated | 30.0 mm | 6.0 mm | 12.0 mm | -40.0 °C | 100.0 °C | UL | ||||||||||
04 | | Manufacturers Part No. 1427BCGPG16(1427BCGPG16) Hammond 1427BCG Screwed cable gland brass, nickel-plated PG16 silver 10mm 14mm New | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 2 Weeks Available on order | (at least 1 or mul. of 1) | Hammond | Screwed cable gland | silver | brass, nickel-plated | 31.0 mm | 10.0 mm | 14.0 mm | -40.0 °C | 100.0 °C | UL | ||||||||||
05 | | Manufacturers Part No. 1427BCGPG21(1427BCGPG21) Hammond 1427BCG Screwed cable gland brass, nickel-plated PG21 silver 13mm 18mm New | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 2 Weeks Available on order | (at least 1 or mul. of 1) | Hammond | Screwed cable gland | silver | brass, nickel-plated | 31.0 mm | 13.0 mm | 18.0 mm | -40.0 °C | 100.0 °C | UL | ||||||||||
06 | | Manufacturers Part No. 1427BCGPG29(1427BCGPG29) Hammond 1427BCG Screwed cable gland brass, nickel-plated PG29 silver 18mm 25mm New | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 2 Weeks Available on order | (at least 1 or mul. of 1) | Hammond | Screwed cable gland | silver | brass, nickel-plated | 39.0 mm | 18.0 mm | 25.0 mm | -40.0 °C | 100.0 °C | UL | ||||||||||
07 | | Manufacturers Part No. 1427BCGPG36(1427BCGPG36) Hammond 1427BCG Screwed cable gland brass, nickel-plated PG36 silver 22mm 32mm New | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 2 Weeks Available on order | (at least 1 or mul. of 1) | Hammond | Screwed cable gland | silver | brass, nickel-plated | 45.0 mm | 22.0 mm | 32.0 mm | -40.0 °C | 100.0 °C | UL | ||||||||||
08 | | Manufacturers Part No. 1427BCGPG42(1427BCGPG42) Hammond 1427BCG Screwed cable gland brass, nickel-plated PG42 silver 32mm 38mm New | Customer Part No. Customer Project No. | 1 Pcs. Planned Delivery Time Ø 2 Weeks Available (from stock) | (at least 1 or mul. of 1) | Hammond | Screwed cable gland | silver | brass, nickel-plated | 46.0 mm | 32.0 mm | 38.0 mm | -40.0 °C | 100.0 °C | UL | ||||||||||
09 | | Manufacturers Part No. 1427BCGPG48(1427BCGPG48) Hammond 1427BCG Screwed cable gland brass, nickel-plated PG48 silver 37mm 44mm New | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 2 Weeks Available on order | (at least 1 or mul. of 1) | Hammond | Screwed cable gland | silver | brass, nickel-plated | 48.0 mm | 37.0 mm | 44.0 mm | -40.0 °C | 100.0 °C | UL | ||||||||||
10 | | Manufacturers Part No. 1427BCGPG7(1427BCGPG7) Hammond 1427BCG Screwed cable gland brass, nickel-plated PG7 silver 3mm 4mm New | Customer Part No. Customer Project No. | 4 Pcs. Planned Delivery Time Ø 2 Weeks Available (from stock) | (at least 1 or mul. of 1) | Hammond | Screwed cable gland | silver | brass, nickel-plated | 24.0 mm | 3.0 mm | 4.0 mm | -40.0 °C | 100.0 °C | UL | ||||||||||
11 | | Manufacturers Part No. 1427BCGPG9(1427BCGPG9) Hammond 1427BCG Screwed cable gland brass, nickel-plated PG9 silver 4mm 8mm New | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 2 Weeks Available on order | (at least 1 or mul. of 1) | Hammond | Screwed cable gland | silver | brass, nickel-plated | 27.0 mm | 4.0 mm | 8.0 mm | -40.0 °C | 100.0 °C | UL | ||||||||||
12 | | Manufacturers Part No. 1427NCGM12B(1427NCGM12B) Hammond 1427NCG Screwed cable gland Nylon M12 x 1,5 black 3mm 7mm New | Customer Part No. Customer Project No. | 10 Pcs. Planned Delivery Time Ø 2 Weeks Available (from stock) | (at least 1 or mul. of 1) | Hammond | Screwed cable gland | black | Nylon | 29.0 mm | 3.0 mm | 7.0 mm | -40.0 °C | 100.0 °C | UL UL 94 V2 | ||||||||||
13 | | Manufacturers Part No. 1427NCGM12G(1427NCGM12G) Hammond 1427NCG Screwed cable gland Nylon M12 x 1,5 gray 3mm 7mm New | Customer Part No. Customer Project No. | 10 Pcs. Planned Delivery Time Ø 2 Weeks Available (from stock) | (at least 1 or mul. of 1) | Hammond | Screwed cable gland | gray | Nylon | 29.0 mm | 3.0 mm | 7.0 mm | -40.0 °C | 100.0 °C | UL UL 94 V2 | ||||||||||
14 | | Manufacturers Part No. 1427NCGM16B(1427NCGM16B) Hammond 1427NCG Screwed cable gland Nylon M16 x 1,5 black 4mm 8mm New | Customer Part No. Customer Project No. | 10 Pcs. Planned Delivery Time Ø 2 Weeks Available (from stock) | (at least 1 or mul. of 1) | Hammond | Screwed cable gland | black | Nylon | 30.0 mm | 4.0 mm | 8.0 mm | -40.0 °C | 100.0 °C | UL UL 94 V2 | ||||||||||
15 | | Manufacturers Part No. 1427NCGM16G(1427NCGM16G) Hammond 1427NCG Screwed cable gland Nylon M16 x 1,5 gray 4mm 8mm New | Customer Part No. Customer Project No. | 11 Pcs. Planned Delivery Time Ø 2 Weeks Available (from stock) | (at least 1 or mul. of 1) | Hammond | Screwed cable gland | gray | Nylon | 30.0 mm | 4.0 mm | 8.0 mm | -40.0 °C | 100.0 °C | UL UL 94 V2 | ||||||||||
16 | | Manufacturers Part No. 1427NCGM16LB(1427NCGM16LB) Hammond 1427NCG Screwed cable gland Nylon M16 x 1,5 black 5mm 10mm New | Customer Part No. Customer Project No. | 10 Pcs. Planned Delivery Time Ø 2 Weeks Available (from stock) | (at least 1 or mul. of 1) | Hammond | Screwed cable gland | black | Nylon | 33.0 mm | 5.0 mm | 10.0 mm | -40.0 °C | 100.0 °C | UL UL 94 V2 | ||||||||||
17 | | Manufacturers Part No. 1427NCGM16LG(1427NCGM16LG) Hammond 1427NCG Screwed cable gland Nylon M16 x 1,5 gray 5mm 10mm New | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 2 Weeks Available on order | (at least 1 or mul. of 1) | Hammond | Screwed cable gland | gray | Nylon | 33.0 mm | 5.0 mm | 10.0 mm | -40.0 °C | 100.0 °C | UL UL 94 V2 | ||||||||||
18 | | Manufacturers Part No. 1427NCGM20B(1427NCGM20B) Hammond 1427NCG Screwed cable gland Nylon M20 x 1,5 black 6mm 12mm New | Customer Part No. Customer Project No. | 10 Pcs. Planned Delivery Time Ø 2 Weeks Available (from stock) | (at least 1 or mul. of 1) | Hammond | Screwed cable gland | black | Nylon | 36.0 mm | 6.0 mm | 12.0 mm | -40.0 °C | 100.0 °C | UL UL 94 V2 | ||||||||||
19 | | Manufacturers Part No. 1427NCGM20G(1427NCGM20G) Hammond 1427NCG Screwed cable gland Nylon M20 x 1,5 gray 6mm 12mm New | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 2 Weeks Available on order | (at least 1 or mul. of 1) | Hammond | Screwed cable gland | gray | Nylon | 36.0 mm | 6.0 mm | 12.0 mm | -40.0 °C | 100.0 °C | UL UL 94 V2 | ||||||||||
20 | | Manufacturers Part No. 1427NCGM20LB(1427NCGM20LB) Hammond 1427NCG Screwed cable gland Nylon M20 x 1,5 black 10mm 14mm New | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 2 Weeks Available on order | (at least 1 or mul. of 1) | Hammond | Screwed cable gland | black | Nylon | 37.0 mm | 10.0 mm | 14.0 mm | -40.0 °C | 100.0 °C | UL UL 94 V2 | ||||||||||
21 | | Manufacturers Part No. 1427NCGM20LG(1427NCGM20LG) Hammond 1427NCG Screwed cable gland Nylon M20 x 1,5 gray 10mm 14mm New | Customer Part No. Customer Project No. | 0 Pcs. Available (from stock) | (at least 1 or mul. of 1) | Hammond | Screwed cable gland | gray | Nylon | 37.0 mm | 10.0 mm | 14.0 mm | -40.0 °C | 100.0 °C | UL UL 94 V2 | ||||||||||
22 | | Manufacturers Part No. 1427NCGM25B(1427NCGM25B) Hammond 1427NCG Screwed cable gland Nylon M25 x 1,5 black 13mm 18mm New | Customer Part No. Customer Project No. | 0 Pcs. Planned Delivery Time Ø 2 Weeks Available on order | (at least 1 or mul. of 1) | Hammond | Screwed cable gland | black | Nylon | 42.0 mm | 13.0 mm | 18.0 mm | -40.0 °C | 100.0 °C | UL UL 94 V2 | ||||||||||
23 | | Manufacturers Part No. 1427NCGM25G(1427NCGM25G) Hammond 1427NCG Screwed cable gland Nylon M25 x 1,5 gray 13mm 18mm New | Customer Part No. Customer Project No. | 10 Pcs. Planned Delivery Time Ø 2 Weeks Available (from stock) | (at least 1 or mul. of 1) | Hammond | Screwed cable gland | gray | Nylon | 42.0 mm | 13.0 mm | 18.0 mm | -40.0 °C | 100.0 °C | UL UL 94 V2 | ||||||||||
24 | | Manufacturers Part No. 1427NCGM32B(1427NCGM32B) Hammond 1427NCG Screwed cable gland Nylon M32 x 1,5 black 18mm 25mm New | Customer Part No. Customer Project No. | 10 Pcs. Planned Delivery Time Ø 2 Weeks Available (from stock) | (at least 1 or mul. of 1) | Hammond | Screwed cable gland | black | Nylon | 48.0 mm | 18.0 mm | 25.0 mm | -40.0 °C | 100.0 °C | UL UL 94 V2 | ||||||||||
25 | | Manufacturers Part No. 1427NCGM32G(1427NCGM32G) Hammond 1427NCG Screwed cable gland Nylon M32 x 1,5 gray 18mm 25mm New | Customer Part No. Customer Project No. | 10 Pcs. Planned Delivery Time Ø 2 Weeks Available (from stock) | (at least 1 or mul. of 1) | Hammond | Screwed cable gland | gray | Nylon | 48.0 mm | 18.0 mm | 25.0 mm | -40.0 °C | 100.0 °C | UL UL 94 V2 |
