Manufacturer Part No.
1035438
Schukat Part No.
IPA-200-M19
Manufacturer
Enter your company's part number here. Your part number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
Enter your personal project number here to assign the item to a project. Your part project number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.

8 Pcs. in stock

Next Stock Receipt
Week 48/2024
12 Pcs.
Planned delivery time
Ø 3 Weeks
Life Cycle Status
The life cycle indicates which market phase the item is in. We distinguish between: • Active (green) • NRND = Not Recommended for New Designs (yellow) • LTB = Last Time Buy (yellow) • EOL = End of Life (red)
Active
Available (from stock)
Replacement / Follow-up View entire series
Data Sheet
ECAD Model
Downloads

Prices

Manufacturer bundle 12 Pcs.
Manufacturer's packaging unit (Mfr. PU) means the smallest original packaging unit of the manufacturer.
Price per 1 Pcs.

Quantity and Options

(at least 1 or multiple of 1)
All prices net plus VAT. We do not deliver to private customers.

Fact Sheet

Type
Universal Cleaner
RoHS-Conform

Specifications

Open all

General

Manufacturer
  • CRC
Type
  • Universal Cleaner
Series
  • KONTAKT IPA
Product group
  • R2263 CRC Electronic Sprays: Special Cleaner
Application
  • Cleaner

Packaging (ml)
  • 200 ml
Features
  • - High purity alcohol cleaner for optical surfaces
    - of isopropyl alcohol contained (isopropanol) evaporates absolutely no residue after application
    - particularly suitable for the removal of dirt on optical components, sensors and magnetic heads
    - Universally applicable due to the high material compatibility
    - Drying time: drys within minutes, approx. evaporation rate 11 (ether = 1)
    - Flammability: flash point at less 0°C, highly flammable
    - Documents in 19 languages

Safety/Certifications

Directions
  • KONTAKT IPA comes in an aerosol with an optional extension tube, making precision dosing possible. The aerosol can be sprayed up-side-down enabling the cleaning of hard to reach area’s. Do not spray directly on video or audio heads but wipe with cleaning substances soaked with KONTAKT IPA. Do not allow the liquid to run inside the head drums. KONTAKT IPA can also be used to clean optical glass, but not for plastic lenses and plastic mirrors, and the like… Surface mirrors, for example in reflex cameras or laser systems must not be treated with this product. In case of doubt, consult the manufacturer of optical components. When used in serial production, compatibility of KONTAKT IPA with plastics like polystyrene or polycarbonate should be tested. All source of ignition should be removed when using the highly flammable isopropanol. Do not spray on energized equipment.. A safety data sheet (MSDS) according to EU directive 91/155/EEC and amendments is available for all CRC products.

Hazardous Substances/Goods

UN number
  • 1950 - Pressurised gas pack

Documents

KONTAKT IPA - Kontakt chemie - Europe-sds_germany-German-2-BDS000792AE.pdf
KONTAKT IPA - Kontakt chemie - Europe-sds_germany-German-2-BDS000792AE.pdf
