MLP1-230L-W/RS
CITEL Overvoltage protection Typ 2/3 10KA IP20
Enter your company's part number here. Your part number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
Enter your personal project number here to assign the item to a project. Your part project number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
10 Pcs. in stock
Planned delivery time
--- Life Cycle Status
The life cycle indicates which market phase the item is in. We distinguish between:
• Active (green)
• NRND = Not Recommended for New Designs (yellow)
• LTB = Last Time Buy (yellow)
• EOL = End of Life (red)
EOL 08.05.2024
Discontinued by manufacturer without replacement
Data Sheet
ECAD Model
Prices
Manufacturer bundle 4 Pcs.
Manufacturer's packaging unit (Mfr. PU) means the smallest original packaging unit of the manufacturer.
Price per 1 Pcs.
Quantity and Options
(at least 1 or multiple of 1)
All prices net plus VAT. We do not deliver to private customers.
Fact Sheet
- Type
- Typ 2/3
- Maximum discharge current
- 10 KA
- Protection Class IP
- IP20
- Protection level L/N
- 1.5 kV
- Protection level L/PE
- 1.5 kV
- RoHS-Conform
Specifications
Open all
Operating conditions
- Operating Temperature Min.
- -40 °C
- Operating Temperature Max.
- 85 °C
- Disconnection and AC line cut-off
- Protected phases
- I
Input
- Nominal input voltage
- 230 V
- Input voltage min. AC
- 230 V
- Input voltage max. AC
- 277 V
- Maximum discharge current
- 10 KA
- Connection type, input
- Strand
Output
- Load current max.
- 2.5 A
- Connection type, output
- Strand
- Protection level L/N
- 1.5 kV
- Protection level L/PE
- 1.5 kV
Safety/Certifications
- Protection class
- I
- Protection Class IP
- IP20
- Approvals
- CE
- EN
- IEC
- UL
- Standards (safety)
- EN 61643-11
- IEC 61643-11
- UL 1449
Documents
I_MLP_int_N130901_f.pdf
I_MLP_int_N130901_f.pdf
