AWLP 26/3,2-T
Assmann WSW IDC PCB connector AWLP_3,2-T 26 Pole Pitch2,54mm verzinnt gray
Enter your company's part number here. Your part number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
Enter your personal project number here to assign the item to a project. Your part project number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
570 Pcs. in stock
Planned delivery time
Ø 2 Weeks
Life Cycle Status
The life cycle indicates which market phase the item is in. We distinguish between:
• Active (green)
• NRND = Not Recommended for New Designs (yellow)
• LTB = Last Time Buy (yellow)
• EOL = End of Life (red)
Active
Available (from stock)
Data Sheet
ECAD Model
Prices
Manufacturer bundle 80 Pcs.
Manufacturer's packaging unit (Mfr. PU) means the smallest original packaging unit of the manufacturer.
Price per 1 Pcs.
Quantity and Options
(at least 10 or multiple of 10)
All prices net plus VAT. We do not deliver to private customers.
Fact Sheet
- Type
- IDC PCB connector
- Connector Contact
- IDC
- Series
- AWLP_3,2-T
- Colour
- gray
- Insulating body
- Polybutylenterephthalat (PBT) 30% GF
- Number of poles
- 26
- Pitch
- 2.54 mm
- Class of Inflammability
- UL 94 V-0
- Operating Temperature Max.
- 105 °C
- Rated current
- 3 A
- Operating Temperature Min.
- -40 °C
- RoHS-Conform
Specifications
Open all
Dimensions and Weights
- Dimension: Length
- 38.42 mm
- Dimension: Width
- 6 mm
- Dimension: Height
- 5 mm
- Height (incl. pins)
- 8.3 mm
- Pitch
- 2.54 mm
Operating conditions
- Operating Temperature Min.
- -40 °C
- Operating Temperature Max.
- 105 °C
Technical Features
- Rated current
- 3 A
- Solderability
- 245 °C / 5 s °C / s
- Test voltage
- 1,000 V AC
- Insulation resistance
- 5.000 mOhm
- Contact resistance
- 20 mOhm
Mechanical Features
- Insulating body
- Polybutylenterephthalat (PBT) 30% GF
- Contact Surface Input
- verzinnt
Safety/Certifications
- Class of Inflammability
- UL 94 V-0
Other Products
All Products of the Series
