8 Pcs. in stock
Planned delivery time
Ø 20 Weeks
Life Cycle Status
The life cycle indicates which market phase the item is in. We distinguish between:
• Active (green)
• NRND = Not Recommended for New Designs (yellow)
• LTB = Last Time Buy (yellow)
• EOL = End of Life (red)
Active
Available (from stock)
Data Sheet
ECAD Model
Prices
Manufacturer bundle 8 Pcs.
Manufacturer's packaging unit (Mfr. PU) means the smallest original packaging unit of the manufacturer.
Price per 1 Pcs.
Quantity and Options
(at least 1 or multiple of 1)
All prices net plus VAT. We do not deliver to private customers.
Fact Sheet
- Type
- Microcontroller Development Board
- Flash
- 16 MB
- PSRAM
- 8 MB
- Interface
- ADC
CAN
DAC
Ethernet
I/O
I2C
RS-232/RS-422/RS-485
USB - RoHS-Conform
Specifications
Open all
Operating conditions
- Operating Temperature, min. (TA)
- -40 °C
- Operating Temperature, max. (TA)
- 85 °C
Electrical Properties
- Supply Voltage Min.
- 24 V
- Supply Voltage Max.
- 24 V
- Program Memory Size
- 2,048 KB
- Memory Size
- 1,024 KB
- Flash
- 16 MB
- PSRAM
- 8 MB
- Interface
- ADC
- CAN
- DAC
- Ethernet
- I/O
- I2C
- RS-232/RS-422/RS-485
- USB
- Contained Module/Controller
- STM32H747XI
- CPU Architecture
- Armv7
- Number of Processor Core
- 2
- Transmission Protocol
- IEEE 802.11 b/g/n
- Bluetooth
- Bluetooth LE v5.0
- Transmission Frequency
- 2.4 GHz
