DSAB0804-150MZ
Acroparts Technology Inductors SMD throttle DSAB0804 3A 15µH -20-20% 12,95mm 9,4mm 5,21mm strapped
Manufacturer Part No.
DSAB0804-150MZ
Schukat Part No.
DSAB0804-150KZ
Manufacturer
Enter your company's part number here. Your part number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
Enter your personal project number here to assign the item to a project. Your part project number will be referenced on your receipts, such as the order confirmation, invoice or delivery note.
980 Pcs. in stock
Planned delivery time
Ø 9 Weeks
Life Cycle Status
The life cycle indicates which market phase the item is in. We distinguish between:
• Active (green)
• NRND = Not Recommended for New Designs (yellow)
• LTB = Last Time Buy (yellow)
• EOL = End of Life (red)
Active
Available (from stock)
Data Sheet
ECAD Model
Prices
Manufacturer bundle 750 Pcs.
Manufacturer's packaging unit (Mfr. PU) means the smallest original packaging unit of the manufacturer.
Price per 1 Pcs.
Quantity and Options
(at least 10 or multiple of 10)
All prices net plus VAT. We do not deliver to private customers.
Fact Sheet
- Kind
- throttle
- Inductance
- 15 µH
- Inductance tolerance
- -20 %
- Nominal resistance
- 0,046 Ohm
- Rated current
- 3 A
- Housing
- SMD
- Dimension: Length
- 12.95 mm
- Dimension: Width
- 9.4 mm
- Dimension: Height
- 5.21 mm
- RoHS-Conform
Specifications
Open all
Dimensions and weights
- Dimension: Length
- 12.95 mm
- Dimension: Width
- 9.4 mm
- Dimension: Height
- 5.21 mm
Operating conditions
- Operating Temperature Min.
- -40 °C
- Operating Temperature Max.
- 125 °C
Technical features
- Inductance
- 15 µH
- Inductance tolerance
- -20 %
- Test frequency
- 100 kHz
- Nominal resistance
- 0,046 Ohm
- Rated current
- 3 A
- Resonant frequency, min.
- 27 MHz
